| Select Type: | 1A (Plastic Shell) (Base), 2A (Plastic Shell), 3A (Aluminum Shell), 5A (Aluminum Shell), 8A (Aluminum Shell), 10A (Aluminum Shell), 12A (Aluminum Shell), 15A (Enlarged Aluminum Shell), 20A (Enlarged Aluminum Shell), 6A (Aluminum Shell), 25A (Enlarged Aluminum Shell), 28A (Enlarged Aluminum Shell), 30A (Enlarged Aluminum Shell), 5A (75 Blue Shell), 11A (75 Blue Shell), 15A (75 Blue Shell), 16A (101 Blue Shell), 20A (75 Blue Shell), 21A (101 Blue Shell), 26A (101 Blue Shell), 30A (101 Blue Shell) |
|---|---|
| Availability | In Stock |
| Condition | Brand New |
The DC9-36V to DC12V Power Converter converts a direct current power source with a voltage range of 9 to 36 volts to a stable output of 12VDC. It is typically used in applications where a 12V power supply is required, such as in vehicles or boats, and other industrial equipment.
This DC Power Converter is available with multiple amp options from 1A to 30A, with 12W~360W output power.
1. Plastic Shell Power Converter: 280MV ripple, 13cm-14cm installation wire length, 58mm*40.5mm*22mm size, 10mA low power consumption, 100g.
2. Aluminum Shell Power Converter: 220MV ripple, 13cm-14cm installation wire length, 74mm*74mm*22mm size, 20mA low power consumption, 250g.
3. Enlarged Aluminum Shell Power Converter: 360MV ripple, 15cm installation wire length, 100mm*80mm*39mm size, 60mA low power consumption, 500g.
4. 75 Blue Shell Power Converter: 220MV ripple, 13cm-14cm installation wire length, 75mm*73mm*27mm size, 20mA low power consumption, 300g.
5. 101 Blue Shell Power Converter: 360MV ripple, 15cm installation wire length, 101mm*78mm*36mm size, 60mA low power consumption, 550g.
Features
IP67 waterproof
Efficiency >93%
With over-voltage, over-current, and short-circuit protections
| Current | Power (Plastic Shell) |
| 1A | 12V*1A=12W |
| 2A | 12V*2A=24W |
| Current | Power (Aluminum Shell) |
| 3A | 12V*3A=36W |
| 5A | 12V*5A=60W |
| 6A | 12V*6A=72W |
| 8A | 12V*8A=96W |
| 10A | 12V*10A=120W |
| 12A | 12V*12A=144W |
| Current | Power (Enlarged Aluminum Shell) |
| 15A | 12V*15A=180W |
| 20A | 12V*20A=240W |
| 25A | 12V*25A=300W |
| 28A | 12V*28A=336W |
| 30A | 12V*20A=360W |
| Current | Power (75 Blue Shell) |
| 5A | 12V*5A=60W |
| 11A | 12V*11A=132W |
| 15A | 12V*15A=180W |
| 20A | 12V*20A=240W |
| Current | Power (101 Blue Shell) |
| 16A | 12V*16A=192W |
| 21A | 12V*21A=252W |
| 26A | 12V*26A=312W |
| 30A | 12V*20A=360W |
Standards and Certifications
| Module Type: | Non-isolated module |
| Input Voltage: | DC9~36V |
| Output Voltage: | DC12V |
| Output Current: |
1A-30A |
| Output Power: | 12W-360W |
| Protect Grade: |
IP67 |
| Conversion Efficiency: | ≥93% |
| Operating Temperature: | -40°C~+85℃ (Industrial level) |
Note:
No reverse connection protection for the input, please wire carefully.
It cannot be used to charge batteries directly.
The selected power should be larger than the actual load of the equipment.
