| Select Input Voltage: | DC24V (Base), DC12V (Base) |
|---|---|
| Select Kit: | LED Strips + IP67(Power Supply), LED Strips + Power Supply, LED Strip (Base) |
| Select Length: | 16.4ft (5 meters) (Base) |
| Select PCB Width: | 10mm (0.39in) (Base) |
| Select Power: | 0.2W per LED (Base), 0.5W per LED |
| Select Waterproof Rating: | Non-Waterproof IP20 - Adhesive Back (Base), Surface Glued IP65 - Adhesive Back, Outdoor Silicone Tube IP67 - With Brackets, Underwater IP68 - Adhesive Back |
| Availability | In Stock |
| Condition | Brand New |
This 12V Ultra High Density UV LED Strip has a wavelength of 365nm. It is widely used in a variety of professional applications such as industrial curing, fluorescence detection and medical sterilization. Our 365nm UV LED strip has 240pcs 2835 LEDs per meter. This high-density LED bead arrangement can produce uniform UV radiation. Therefore, this 365nm LED black light strip can effectively disinfect and solidify.
This 365nm blacklight LED strip is five meters per roll. We offer two power options: 0.2W/LED and 0.5W/LED, meeting different energy efficiency requirements. The 365nm UV curing light strip is cut every three LEDs (12mm/0.47''), supporting user to cut it according to their needs. In addition, this filtered 365nm UV light can be bent to fit irregular mounting surfaces. The operating voltage of the 365nm UV LED light strip is 12VDC for safe operation.
The 365nm wavelength UV blacklight can accurately activate photoinitiators in glues, inks and other photosensitive materials, especially used in 3D printing, glue curing, industrial coating curing and other fields.
Please note that the "+" mark on the PCB of the 12V 365nm led light strip refers to the negative port, "-" on the PCB is positive port.
|
0.2W/LED vs 0.5W/LED: Although this 10mm high-density UVA light strip uses 0.2W and 0.5W UV LED beads, the total power of the 5-meter UV strip is not simply 0.2W / 0.5W multiplied by the number of LEDs. Due to resistance limitations and the inevitable voltage drop in LED series connections, the actual power of the entire light strip is between 60W and 120W (single-sided power input). Our engineering team is available to customize the power output of the UV LED strip light according to your requirements. Please contact us for customization. |
Features of the flexible UV light strip:
1. Powered by low voltage DC 12/24 volts, choose a 12V/24V meanwell power supply here. The model number of the power supply inside the kit we provide is LRS-200-12, LRS-200-24 or waterproof 12V 200W, waterproof 24V 200W.
2. 365nm wavelength, which is widely applied in glue curing, industrial coating curing and other fields.
3. 10mm width, ideal for compact installation spaces
4. The cut unit is 12mm/0.47'', every three LEDs can be cut.
5. The actual power due to voltage drop along the strip is not the same as the theoretical power.
Standards and Certifications
Product Specifications
| LED Strip Type: | 12V 365nm UV Lightstrip |
| Input Voltage: | DC12V, DC24V |
| Actual Power: | 60W/Roll for 0.2W, 120W/Roll for 0.5W |
| Light Color: | Purple UV Light |
| Wavelength: | 365nm |
| Cut: |
12.5mm/0.49'', 3 LEDs For DC12V; 25mm/0.98", 6 LEDs For DC24V |
| LED Quantity: | 240 LEDs per meter, 1200 LEDs/Roll |
| Lifespan: | 50,000+ hours |
| Dimensions: | L500cm*W1.0cm*H0.25cm |
| Waterproof Rating: | Non-Waterproof IP20, Waterproof Resistant IP65, Outdoor IP67 IP68 |
| Beam Pattern: | 120 degree |
How to power 12V UV led strip?
