| Select Controller type: | Master Controller (Base), Sub Controller (Base) |
|---|---|
| Select Input Voltage: | DC12V (Base) |
| Availability | In Stock |
| Condition | Brand New |
Upgrade your vehicle’s ambiance with the CY-HC Series Bluetooth Controller. Specifically engineered for automotive retrofits, this intelligent car lighting system allows for effortless synchronization across multiple zones without complex wiring. Whether you are running RGBIC (addressable) chase effects or classic RGB color-changing strips, this controller provides stable, music-synced performance directly from your smartphone.
• Stable 12V to 5V Step-Down: Designed for cars; takes standard 12V vehicle power and converts it to a stable 5V output for your LED strips.
• Smart Main/Sub Auto-Sync: Features a unique wireless ecosystem where the Master (CY-HC5V168) and Sub (CY-HC5V188) units pair automatically via Bluetooth for perfectly synchronized lighting across the entire vehicle.
• Multi-Channel Versatility: Expand your setup with ease—the Master unit supports dual-channel RGBIC or single-channel RGB, while the Sub-units offer expanded connectivity for doors, footwells, or underglow with dual-channel RGBIC or dual-channel RGB.
• Dual Compatibility: Versatile output supports both 5V RGBIC for dynamic chasing effects and standard 5V RGB for smooth, solid color transitions.
• Audio-Reactive Music Mode: Integrated high-sensitivity mic allows the light strips to dance to the beat of your music, creating an immersive driving environment.
Both the main controller and the sub-controller utilize XH series proprietary connectors, which are incompatible with common JST connectors.
Connect car RGBIC led strip to the 3-pin addressable port; Connect car RGB led strip to the 4-pin color-changing port.
Pairing: Turn on your phone's Bluetooth and open the compatible App "LED Lamp".
Pro-Tip: To ensure maximum product longevity and stability, please ensure your connected LED strips do not exceed a continuous draw of 1.5A per controller.
|
Feature
|
Master Controller (CY-HC5V168)
|
Sub Controller (CY-HC5V188)
|
|
Input Voltage
|
DC 12V
|
DC 12V
|
|
Output Voltage
|
DC 5V
|
DC 5V
|
|
Output Channels
|
2×RGBIC or 1×RGB
|
2×RGBIC or 2×RGB
|
| Connection | XH2.54 for LEDs, XH2.0 for power | XH2.54 for LEDs, XH2.0 for power |
|
Max Current
|
2A (Peak)
|
2A (Peak)
|
|
Recommended Load
|
1.5A (Continuous)
|
1.5A (Continuous)
|
|
Connectivity
|
Bluetooth (App Control)
|
Auto-Connect Bluetooth
|
|
Working Temp
|
-20°C to +60°C
|
-20°C to +60°C
|
