Spec Sheet - FSLSR-12V-5630X150

Select Length:	16.4ft (5 meters) (Base)
Select Light Color :	Warm White(3000K) (Base), Daylight White(6000K) (Base), Cool White(7000K) (Base), Red(620-630nm) (Base), Green(515-525nm) (Base), Blue(465-475nm) (Base), Yellow(585-595nm) (Base)
Select PCB Width:	10mm (0.39in) (Base)
Select Waterproof Rating:	Non-Waterproof IP20 - Adhesive Back (Base), Surface Glued IP65 - Adhesive Back, Outdoor Silicone Tube IP67 - With Brackets, Underwater IP68 - Adhesive Back
Availability	In Stock
Condition	Brand New

Universal single color super bright 5630 SMD(SMD: Surface Mounted Devices) Waterproof optional Flexible LED Tape strips, Epistar chip, 150LEDs/16.4ft, 16.4ft(5 meters) Per Reel By Sale.

Our brightest super flexible LED Solid Color light Strips soft and easy bent for installation. Available in 5 meters (197 in) flexible light strips with adhesive backing and can be stuck just about anywhere. can be cut into 3-LED segments, so you could cut a different length for your project and request. This LED Light strip is perfect for retail shops, supermarkets, museums, galleries, photography or any indoor applications where presentation, appearance, and depth of color are critical, Suitable for the average home lighting as well as lighting professionals. High color rendering index (+95 CRI) enhances vibrant colors more than traditional LEDs nearly matching the color quality of incandescents. 12V DC operation. Dimmable - Connect LED Smart Dimmers.

Standards and Certifications

DC12V waterproof

Product Specification

LED Strip Type: SMD 5630 150PCS/16.4ft

LED Chip: Super bright Chip

Working Temperature: -4°F (-20°C) ~ 122°F (50°C)

Storage Temperature: -40°F (-40°C) ~ 176°F (80°C)

Light Color: Warm White, Daylight White,Cool White, Red, Green, Blue, Amber (optional)

Dimension: 16.4ft/roll, every 3 PCS LED can be cut

LED Quantity: 30 LEDs per 1meter (3.28 ft)

Lifespan: 50,000+hours

Warantty: 3 years

Dimensions: L500cm(196.8 in ) x W1.0cm(0.39 in ) x H0.25cm(0.10 in )

Input Voltage(V): 12V DC

Working Power: 3A 36W /16.4ft Max

Lamp Luminous Flux(lm): 20~22lm/LEDs 630lm/ft 192lm/m

Color Temperature CCT(White): Warm White(2800-3500k), Daylight White(5000-6500k), Cool White(7500-10000k)

Wavelength NM(RGBY): Red(620-630nm), Green(515-525nm), Blue(465-475nm), Yellow(585-595nm)

Beam Pattern: 120 degree

Water Proof: Non-waterproof; Waterproof IP65; Waterproof IP67; Waterproof IP68 Optional

CRI (Ra>): 95

Color Temperature And CRI

Choosing the correct color temperature lights for your project is very important, and as important as the brightness you choose.

Consider the look and feel you want your project to have.

What other color lights will be present? What material and color are the materials you wish to light?

LED strip color temperature

CRI (Color Rendering Index) is a measure of how well a particular light source renders vivid, natural color. Lamps, led tubes, or led bulbs with an index of greater than 90 are generally considered High CRI light sources, and will make food, jewels, or any other product come alive with bright, natural color.

CRI led strip

Waterproof Level Description

IP20 IP20 Non-waterproof (The PCB [Printed Circuit Board] surface of the bare, with a self-adhesive back, For Indoor);

IP65 IP65 Waterproof (Epoxy cover waterproof, PCB surface is encapsulated with plastic Gel, with self-adhesive 3M back, For Outdoor & Indoor);

IP67 IP67 Waterproof (Silicon sleeve waterproof, PCB is encapsulated with silicon tube, with a plastic fastener, better waterproof, For Outdoor);

IP68 IP68 Waterproof (Fully waterproof plastic irrigation, PCB both surface and back are encapsulated with plastic Gel, with a plastic fastener, the top level of waterproof, For Outdoor);

The waterproof grade of IP65, IP67, and IP68 will affect the color temperature due to the material problem, resulting in an increase of about 1000K. If you want to purchase the waterproof LED strips and have requirements on the color temperature, please note when placing the order. led strip waterproof level
