Single Color Dimmer Series
(0)Model:WIFI-BT-WB5
WB5 WIFI & Bluetooth 5in1 Tuya LED Controller
- Model: WB5
- Input Voltage: DC12-24V
- Load Current: 6A/Channel
- Total Current: 15A
- Output power: 12V<180W, 24V<360W
- RF: 2.4Ghz
- Suitable for: SC/CCT/RGB/RGBW/RGBCCT
- Support: APP/RC/Amazon Alexa
WIFI/Bluetooth/Zigbee Mesh 5 in 1(Single Color&CCT&RGB&RGBW&RGB+CCT) LED Controller is our newly developed high-ed controller, controlled by Tuya Smart Life APP directly, also 3G/4G long distance control and support third party voice control( need Tuya Bluetooth Mesh Gateway). The controller has auto-transmitting and auto-synchronizing function and with brightness, CCT,...
(0)Model:RL-DIM-1-B
DC12-24V Black LED Dimmer Touch Switch For Single Color LED Light Strips
- Voltage: DC12V-24V
- Size: 18mm diameter
- Max Current: 6A
- Output Channel: 1
- Max Power: 12V72W, 24V144W
- Color: Black
- Function: Switch&Dimmer
- Waterproof Rating: IP20
Black mental touch led dimmer light switch for low voltage single color led strip lights with DC12V or DC24V. The color ring of the led light dimmer switch can be seen in a dark environment. Comes with male connector and female connector to connect to led strip lighting and led transfromer, this black touch led dimmer switch is simple to use. Short press the mental touch switch to...
(0)Model:RL-DIM-1
DC12-24V LED Dimmer Touch Switch For Single Color LED Strip Lights
- Voltage: DC12V-24V
- Size: 16mm diameter
- Max Current: 6A
- Output Channel: 1
- Max Power: 12V72W, 24V144W
- Color Ring: Blue, Red, Yellow
- Function: Switch&Dimmer
- Waterproof Rating: IP20
Mental touch dimmer switch for led lights with single color, suitable for 12V led strip lights and 24V led strip lights. When the touch light switch connects to the power, the color ring can be seen in the dark environment. Short press the touch switch to turn on or turn off the led strip lighting, long press to dimmer the led lighting from 5%-100% brightness. Do not touch the edge of the...
(0)Model:PIR-1
DC12-24V PIR Motion Sensor LED Light Switch Human Body Induction
- Voltage: DC12V-24V
- Product Type: Human Body Induction
- Induction Method: Infrared
- Induction Range: 120°
- Induction Distance: 5m/16ft
- Delay Time: 10-300s
- Max Current: 6A
- Waterproof Rating: IP20
This PIR sensor smart light switch can freely turn the led light on/off automatically, and the built-in light sensor can recognize day and night. Mainly used to control LED lights and LED strips. Adjust the light to be soft and stable without flickering. Easy to install and use. Standards and Certifications Product...
(0)Model:DIM-BT-30A
DC5V - 24V 30A APP Control RF Remote Bluetooth Hardwired LED Dimmer
- Voltage: DC5-24V
- Control: Bluetooth4.0
- APP: HappyLighting
- Mobile: IOS6.0+Android4.3
This is a wireless smart LED dimmer with Bluetooth 4.0 technology for DC5-24V single color led strip lights , scan the code to download the APP "HappyLighitng" to dim LED strip lighting, easy to use, 0-100% light brightness adjustable. Bluetooth controller makes the LED light control more convenient and more humanized. Single color LED lights can be remotely controlled by an...
(0)Model:DIM-WX30A
DC5V - 24V 30A Smartphone Control Bluetooth Hardwired LED Light Dimmer
- Voltage: DC5-24V
- Current: Max 30A
- Control: Bluetooth Applet
- Size: L85×W62×H35mm
Bluetooth light dimmer controller for DC5-24V single color led strip lights , scan the code to enter the control page of the wechat applet, easy to use, touch to adjust the LED strip lighting, 0-100% light brightness adjustable. Stable control and long control distance, with power-off memory function, this LED dimmer can achieve multiple synchronization. Bounce, breathing, strobe dynamic...
(0)Model:RF203
RF203 2.4G Remote Control Multi-function 1 Channel Dimmer, Touch 8-key Controller
- Operating Voltage: 5/12/24v
- Operating Current(a): 16
- Control Type: IR
- Waterproof Rating: IP33
- Output Channel: 4
- Shell: Metal
This 2.4G controller is newly introduced wireless high-power LED controller of our company. It equips with touch remote control, touch remote control adopts high precision capacitance touch control technology, you can select the color you need by one button. It is convenient and easy. Each controller has a globally unique address code, in order to prevent confusion caused by controlling repeated...
(0)Model:CONSC-RF-12
RF Remote Control LED Dimmer For Single Color LED Strip Lights
- Operating Voltage(v): 12/24
- Operating current(a): 12
- Control Type: IR
- Waterproof Rating: IP65
- Output Channel: 3
- Shell: Plastic
We combined the mini LED controller with RF remote, a more convenient way to realize the best visual effect of your LED strip. This mini LED light dimmer is tiny in its size, make it easy to be concealed .Through connecting with LED strip lights, the accompanied RF remote will be able to control strip to achieve different functions such as dynamic mode, dynamic speed level and brightness...
(1)Model:LN-SPIR-1CH-LV
LN-SPIR-1CH-LV 1 Channel Human Body Induction Switch, Infrared Detection Controller
- Operating Voltage:DC12-24V
- WT: -20-60℃
- Output: 1 Channel
- Induction Angle: 60°
- Output Current:<6A
- Delay Time:1-10 min
The human body induction switch is an infrared detection controller that uses infrared detection to control the load switch. The user can install the human body sensor in an appropriate environment according to actual needs. Standards and Certifications Technical Parameters Working Temperature: -20-60℃ Power Supply Voltage: DC12-24V...
(0)Model:DM110
DM110 DC12V-24V 1 Channel Inverter Dimmer, Multi-function Dimmer
- Voltage:DC12-24V
- Control Type: Touch
- Waterproof Rating: IP54
- Output Channel: 1
- Output Current: 30A
Mechanically turn the dimmer button, you can turn the knob on the dimmer to adjust the brightness of the lamp from 0% to 100%, the frequency of the dimmer is around 1,000, so it is only used for home lighting, if you use For photography lighting, please choose a dimmer with a frequency higher than 20000, such as model V1-K How to Use: Firstly connect the load wire, following by the power wire;...
(0)Model:CONSC-DIM
DC12-24V 30A LED Knob Dimmer, PWM Dimming Controller For LED Stirp Light
- Output Voltage: DC12-24V
- Power:Max.610W
- Output:30A
- Dimmer Type:PWM
The dimmer uses the PWM circuit knob control to adjust the brightness of mostD12V or DC24V LED products from 0 to 100%. It has no effect on the lamps and solves the trouble of too bright and dazzling luminous characters. It can be adjusted according to your I like to adjust the brightness at will, but the brightness cannot exceed the original brightness of the lamp. It is suitable for the...
(0)Model:CONSC-HPDIM
DC5-24V 30A Single Color LED High Power Dimmer
- Output Voltage: DC5-24V
- Output:30A
- Dimmer Type:PWM
The dimmer uses the PWM circuit knob control to adjust the brightness of mostD12V or DC24V LED products from 0 to 100%. It has no effect on the lamps and solves the trouble of too bright and dazzling luminous characters. It can be adjusted according to your I like to adjust the brightness at will, but the brightness cannot exceed the original brightness of the lamp. It is suitable for the...
(0)Model:DIM-M1+RF
DC5-24V 30A PWM Knob Dimmer Controller With RF Remote Control For Single Color LED Strip Light
- Output Voltage: DC5-24V
- Output:30A
- Dimmer Type:PWM
The dimmer uses the PWM circuit knob control to adjust the brightness of most DC5V, D12V or DC24V LED products from 0 to 100%. It has no effect on the lamps and solves the trouble of too bright and dazzling luminous characters. It can be adjusted according to your I like to adjust the brightness at will, but the brightness cannot exceed the original brightness of the lamp. The dimmer can be...
(0)Model:DC5V-USB-MINI-SC
DC5V Mini Single Color LED Strip Light Controller With 3-Button Dimmer Input And Output USB Connector
- Voltage: DC5V
- Connector type: USB
- Power: 30W
- Material: ABS
- Light color: single color
The dimmer adopts three-key dimming with 7-level dynamic mode; 10-level speed regulation; 10-level brightness adjustment. The dynamic model can only adjust the speed but not the brightness. In the dynamic mode, press the button to switch to the static model. The input and output are all MINI single color controllers with a USB interface. Standards and Certifications ...
(0)Model:MLD-5A
Original DC 5~24V Single Color LED Mini Dimmer Controller with Dynamic Modes
- Voltage: DC 5~24V
- Output: 5A/Channel
- Output Power: 25~120W
- Output:1 Channel
- Remote Control : In-line
- Dim Control: Touch Control
- Amps Per Channel:5A/CH
Original single color mini LED dimmer can dim any 5~24V DC LED product from 10%-100% using Pulse Width Modulation (PWM) circuit push button control from stepped intensity adjustment. 5 dynamic flashing modes with adjustable speeds. Maximum load is 5 Amps - holding Speed/Bright button turns LEDs ON/OFF. Retains last setting when power is cycled. Attached 4" power input and controller output...
(0)Model:CONRGB-BT-02
DC5~24V Max 12A, Bluetooth 4.0 WIFI Control Via IOS Android Smart Phone Tablet PC, For Single Color, CCT and RGB LED Light Strips or Modules
- Operating Voltage(v): 12/24
- Operating current(a): 12
- Control Type: Bluetooth
- Applied to: SC RGB Lights
- Frequency: 2.4GHz
- Output Channel: 3
- Control Source: M/P IR/RC
- Shell: Plastic
Product Description: RGBW Bluetooth LED controller is a universal RGBW controller controlled by mobile phones. It adopts Bluetooth 4.0 technology and the most advanced PM (pulse width modulation) control technology; it can control all 5-wire 4 loops (common anode) LED full-color lighting products , Such as: LED module, LED strip light, LED light box, etc.; has the advantages of...
(0)Model:LED-ACCESSORIES-001
Touching Type Sensor Detector Switch for LED Strip 5-24V DC 3A LED Strip lights
- Voltage: DC5-24V
- Load Current:3A
The LED touch sensor switch is small in size, ultra-thin, easy to hide, and easy to install. The touch switch can load LED lamps and various electrical appliances, with high stability, long service life and easy connection. Scope of application: 1.LED lamps 2. LED light strip 3. Wardrobe LED cabinet light 4. Various electrical appliances Instruction: 1. In the case of an outage,...
(0)Model:V5-L(WT)
V5-L(WT) WiFi & RF Tuya Push Dimming 5 in1 LED Controller Amazon ECHO Voice Control
- Input voltage: 12-48VDC
- Output voltage: 5*DC12-48V
- Input current: 30.5A
- Output type: Constant voltage
- Input signal: Tuya APP + RF 2.4GHz + Push Dim
- Control distance: 30m
- Dimming range: 0-100%
- Operation temperature: -30~+55"C
Product Features ● 5 in 1 function, used for control RGB, RGBW, RGB+CCT, color temperature or single color LED strip. ● DC12-48V input, 5 channel constant voltage output. ● Tuya APP cloud control, support on/off, RGB color, color temperature and brightness adjust, delay turn on/off light, timer run, scene edit and music play function. ● Voice control, support amazon ECHO and...
(0)Model:V5-L(WB)
V5-L(WB) 12-48VDC 5CH*6A Bluetooth & RF Tuya Push Dimming 5 in1 LED Controller
- Input voltage: 12-48VDC
- Output voltage: 5*DC12-48V
- Input current: 30.5A
- Output type: Constant voltage
- Input signal: Tuya APP + RF 2.4GHz + Push Dim
- Control distance: 30m
- Dimming range: 0-100%
- Operation temperature: -30~+55"C
Product Features ● 5 in 1 function, used for control RGB, RGBW, RGB+CCT, color temperature or single color LED strip. ● DC12-48V input, 5 channel constant voltage output. ● Tuya APP cloud control, support on/off, RGB color, color temperature and brightness adjust, delay turn on/off light, timer run, scene edit and music play function. ● Voice control, support amazon ECHO and...
(0)Model:V1-K
DC12-24V 20A 1CH*20A 12-24VDC CV 2,000Hz Dimming Controller V1-K For Quad Row LED Strips
- Input voltage: DC12-24V
- Input current: 20A
- Output power: 240W/480W Max.
- Output type: Constant voltage
- Dimming level: 100 levels
- Dimming curve: Logarithmic or linear
Features ● Rotary dimmer with the digital numeric display, visible dimming level. ● Match with Skydance’s 2.4G single-zone or multiple zones dimming remote control optional. ● 0-100% dimming smoothly without any flash. ● High load current up to 20A. ● Logarithmic or linear dimming curve selectable. ● PWM frequency 250Hz, 500Hz, 2kHz, or 8kHz selectable. ● Over-heat /...
