8-Zone RGB+CCT Remote Controller FUT089-B

[ VIDEO: Watch on YouTube ]

Product Features

This product adopts a worldwide used 2.4GHz frequency, GFSK control method, with the features of low power consumption, long-distance transmitting, strong anti-interference, and fast communication rate; can control specified Mi-Light smart light with color, color temperature, saturation, and brightness changes.

Product Parameters

Product Name: 8-Zone RGB+CCT Remote Controller

Model No.: FUT089-B

Working Temperature: -20 -60℃

Voltage: 3V(2*AAA Battery)

Transmission Frequency: 2400-2483.5MHz

Modulation Method: GFSK

Transmitting Power: 6dBm

Control Distance: 30m

Standby Power: 20uA

Size: 47*19*153mm

Attention

1. 8-zone remote controller only controls specified Mi-Light products; not all Mi-Light series can work on this remote controller.

2. In the use of the remote, if the indicated lamp blinking quickly, pls change the battery in time. Pls don’t use the poor quality batteries to avoid the leaking of battery liquid to damage the remote controller.

3. Please keep your finger off the touch ring when installing the batteries, to improve its sensitivity, and use the remote ( 3 seconds later ) after the batteries are installed. Please reinstall the batteries, if the focus ring is found low-sensitivity.

4. This 2.4GHz remote control system is a precise electronic product; don’t use it in humid, high temperature, dust, and high voltage environment; Saving it at indoor, dry, and no static electricity environment.

5. Pls don’t use the remote controller on the wide-range metal or strong electromagnetic wave area, otherwise, it will badly affect the controlling distance.

FUT089-B
