| Select Kit: | LED Strips (Base), LED Strips + Controller + Power Supply, LED Strips + IP67(Controller + Power Supply) |
|---|---|
| Select LED Quantity: | 384 LEDs/m (Base), 480LEDs/m |
| Select Length: | 16.4ft (5 meters) (Base), 32.8ft (10meter) Roll, 49.2ft (15 meters) Roll, 65.6Ft (20 meters ) Roll |
| Select Light Color : | Warm White(3000K) (Base), Natural White(4000K) (Base), Daylight White(6000K) (Base) |
| Select Waterproof Rating: | Non-Waterproof IP20 - Adhesive Back (Base), Underwater IP68 - Adhesive Back, Waterproof IP67 - Adhesive Back |
| Availability | In Stock |
| Condition | Brand New |
What is COB? COB VS LED
COB stands for chip-on-board, the LED chip is placed directly on the PCB board, sealed by a sealing layer, and showing different colors through different sealing layers. The COB bedroom LED light strip has a linear luminescence and no light spot due to the linear sealing layer, which is the most obvious difference between COB and LED light strips. COB LED strips have the general characteristics of light strips, energy-saving, high flexibility(more flexible than LED strips), high CRI, can be cut, and the 3M adhesive design is easy to install.
|
• Super density 384 Chips per meter • 8mm/0.32in wide • 20m/65.6Ft without voltage drop, you can only power at one side, perfect for bedroom lighting design • 10W/m, 3W/Ft • DC24V safety voltage input • Warm White/ Natural White/ Daylight White optional • Under-cabinet lighting; bookshelf lighting • Waterproof Available |
How to choose LED strip lights options?
We provide multiple options for indoor or outdoor use, including the LED controller, LED power supply, if you purchase the LED power supply in the kit, we will also send you an extra AC plug, please read the following list to get detailed product:
| Length | Power | Kit for indoor use | Kit for outdoor use |
| 5m / 16.4Ft | 50W | ||
|
Controller: V1-L + R6-1 Power supply: 24V 100W MW |
Power supply: 24V 150W waterproof |
||
| 10m / 32.8Ft | 100W | ||
|
Controller: V1-L + R6-1 Power Supply: 24V 150W MW |
Power Supply: 24V 150W waterproof |
||
| 15m/49.2Ft | 150W | ||
|
Controller: V1-L + R6-1 Power Supply: 24V 200W MW |
Power Supply: 24V 200W waterproof |
||
| 20m/65.6Ft | 200W | ||
|
Controller: V1-L + R6-1 Power Supply: 24V 350W MW |
Power Supply: 24V 300W waterproof |
If you want to achieve APP control, you can purchase our Milight single color LED controller
When you purchase the LED power adapter, please read the following article: How to choose the correct LED power supply
For the waterproof LED controller, only including the LED controller, if you need the LED remote controller, you can purchase from the Skydance single color LED remote controller series
Product Specification
| LED Strip Type |
COB LED (COB Flexible led strip light specification  ) |
| LED Chip | Epistar Chip (COB Chip) |
| Input Voltage | DC24V |
| Power | 10W/m; 3W/Ft; 100 LM/W |
| Working Temperature | -20℃~+45℃ |
| Storage Temperature | -20℃~+60℃ |
| LED Color | Warm White(3000k), Nature White(4000K), Daylight White(6000K) |
| PCB Width | 8mm |
| LED Quantity | 384 Chips/m |
| Waterproof Rating | IP20 / IP67 |
| Cut Length | 31.25mm |
| PCB Color | White |
| Color Rendering Index | Ra>90 |
| Beam Angle | 180° |
| Length | 5m/16.4Ft; 10m/32.8Ft; 15m/49.2Ft; 20m/65.6Ft optional |
Don't know how to wire? please read the following article: How to wire the single color LED strip light
