| Select Kit: | LED sheet + controller, LED sheet + controller + power supply, LED sheet (Base) |
|---|---|
| Select Power: | 42W (Base) |
| Select Size: | 490mm x 245mm (19.2" x 9.6") (Base) |
| Select Waterproof Rating: | IP20 Indoor Use (Base), IP54 For Damp Environments |
| Availability | In Stock |
| Condition | Brand New |
This is our first pixel thin LED sheeting with a black PCB, and it’s also a configurable LED light sheet that you can draw signs. SM16703 IC chips are installed on it to display RGB color-changing effects. This sheet light works under DC24V voltage, offering high bright and uniform illumination. (42W per sheet)
We provide WIFI addressable controllers, easy to connect. The brightness can be adjusted on the APP to show single or multi-color glow. For professional text and animation display, we recommend using the WLED programmable controller.
The flexible led sheet programmable has an ultra-thin profile and is very soft. It can be easily bent into different shapes by hand to fit curved surfaces and table corners. One LED panel sheet consists of 32 modules, each of which can be cut into individual units with scissors. You can also seamlessly splice several LED light sheets together using the on-board connectors or soldering. The back of the trimmable LED sheet is designed with a 3M adhesive backing for quick and long-lasting installation.
RGB pixels can display thousands of colors and can also be mixed to produce white light. However, this white light is bluish to the naked eye. If an accurate or tunable white backlighting sheet is required, check out our category. All LED sheets are of excellent quality, with 2 years warranty.
1. 24V flexible bendable LED sheet light, paper-thin, with double-layer black PCB.
2. Super bright illumination, addressable RGB color, controlled by SM16703 pixels.
3. Can display single color, color-changing, text and animation via controller.
4. Can be easily cut with scissors to create smaller segments.
5. Linkable via four on-board connectors, illuminating expansive areas.
6. 3M adhesive backing for convenient installations.
7. Available in IP20 non-waterproof and IP54 splash-proof.
(IP54 is sprayed with a thin transparent silicone layer, without affecting light’s color)
8. Shipped with accessories. Please refer to the picture below.
If select kit, you will receive SP530E WiFi addressable controller and LRS-100-24 meanwell power supply with an AC plug.
For details, please refer to the PDF below.
| LED Strip Type: | Ultra Bright SM16703 RGB Addressable Flex LED Sheet for Backlighting (FLS-24V-5050-ARGBX192) |
| LED Chip: | SMD 5050 |
| IC Type: | SM16703 |
| Pixels: | 32 Pixels |
| Input Voltage: | 24V DC |
| Product Size: | L19.2 "x W9.6"X0.3" (490mm*245mm*8mm) |
| Light Color: | RGB+IC |
| Current: | 1.75A |
| LED Quantity: | 192 LEDs per sheet (148 LEDs per square foot) |
| Working Power: | 42W per sheet (32.56 watts per square foot) |
| Cut Unit: | 6 LEDs (2.41”X2.41”/ 61.25mm* 61.25mm) |
| Lifespan: | 50,000+hours |
| Beam Pattern: | 120 degrees |
| IP Rating: | Non-waterproof IP20/ Splash-proof IP54 |
| Lumen: | 23LM per LED |
| Warranty: | 2 years |
