| Select Connector Type: | 2-pin Bare Wire (Base), Waterproof Wires, Waterproof Fast Connectors |
|---|---|
| Select Length: | 16.4ft (5 meters) (Base) |
| Select Light Color : | Warm White(3000K) (Base), Daylight White(6000K) (Base), Natural White(4000K) (Base) |
| Select Operating Voltage: | 12VDC (Base), 24VDC (Base) |
| Select Waterproof Rating: | Outdoor Silicone Tube IP67 - Adhesive Back (Base) |
| Availability | In Stock |
| Condition | Brand New |
Achieve brilliant, indirect illumination in challenging outdoor environments with our Waterproof Side Emitting LED Strip. This high-density strip packs 600 bright 335 SMD LEDs onto a 16.4ft roll, projecting light sideways (parallel to the mounting surface) for perfect edge-lighting and accent effects. Its unique IP67 rating is achieved via a hollow, transparent silicone tube that encases the bare strip, providing robust protection against water and dust while maintaining superior flexibility compared to fully potted strips. This design makes it ideal for architectural highlighting, signage, and creating clean, uniform lines of light where traditional forward-facing strips won't fit. Available in three shades of white and both 12V and 24V options, it's a versatile solution for professional-grade outdoor lighting projects.
Features 600 LEDs per 5-meter roll (120/m) that emit light from the edge of the strip, creating a bright, uniform glow ideal for edge-lighting acrylic, cove lighting, and signage.
Encased in a hollow silicone tube, this strip offers excellent IP67 protection for outdoor use without sacrificing the flexibility needed for curved installations.
Utilizes compact 335 SMD LEDs to deliver high brightness from a slim profile, ensuring powerful illumination for accent and task lighting applications.
Choose between 12VDC or 24VDC operation and select from Daylight White (6000K), Natural White (4000K), or Warm White (3000K) to match your project's ambiance. Solid colors are also available.
The strip can be cut every 3/6 LEDs, allowing you to tailor the length precisely for your needs. Optional waterproof connectors simplify installation.
| Parameter | Details |
|---|---|
| Model | FSLSR-IP67-335X600 |
| LED Type | 335 SMD |
| Emitting Direction | Side View |
| LED Quantity | 600 LEDs per 16.4ft (120 LEDs/m) |
| Operating Voltage | 12VDC or 24VDC |
| Power Consumption | 48W per 16.4ft (9.6W/m) |
| Luminous Flux | Approx. 6-7 lm per LED |
| Light Color Options | Daylight White (6000K), Natural White (4000K), Warm White (3000K) |
| CRI (Ra) | 80+ |
| Beam Angle | 120° |
| Strip Length | 16.4ft (5 meters) |
| Strip Dimensions | Width: 10mm, Height: 4mm |
| Cuttable Unit | Every 3/6 LEDs |
| Waterproof Rating | IP67 (Silicone Tube, Hollow) |
| Operating Temperature | -20°C to 50°C (-4°F to 122°F) |
| Backing | Adhesive Tape |
Q: How is this IP67 strip different from an IP68 one?
A:This IP67 strip uses a hollow silicone tube, making it highly flexible and resistant to water jets and temporary immersion. IP68 strips are typically solid-filled (potted) and are suitable for continuous submersion, but are much more rigid.
Q: Can I cut this waterproof strip and reconnect it?
A:Yes, you can cut the strip on the designated cut lines. To maintain the waterproof rating, you must seal the cut end with a silicone end cap and adhesive, and use IP67-rated waterproof connectors for any joins.
Q: What is the difference between the 12V and 24V versions?
A:The 24V version is more efficient for longer runs as it suffers from less voltage drop, meaning brightness will stay more consistent over the length of the strip. For a single 5m roll, both perform similarly.
Q: What power supply do I need for one full 16.4ft roll?
A:The strip consumes 48 watts. We recommend a 12V or 24V power supply (matching your strip's voltage) with a rating of at least 60 watts to provide a safe 20% power buffer.
Q: How can I tell which wire is the positive side of the LED strip?
A:The PCB of the strip is typically marked with a '+' symbol for the positive connection and a '-' symbol for the negative connection near the solder pads or connector.
