| Select Kit: | LED Strips (Base), LED Strips + Controller + Power Adapter, LED Strips + Power Adapter |
|---|---|
| Select LED Quantity: | 528Chips/m - 10mm/0.39in, 384Chips/m - 8mm - Only White (Base) |
| Select Length: | 16.4ft (5 meters) (Base) |
| Select Light Color : | Warm White(3000K) (Base), Red(620-630nm), Green(515-525nm), Blue(465-475nm), Natural White(4000K) (Base), Ice Blue, Warm White(2700K) (Base), Daylight White( 6500K) (Base), Golden Yellow |
| Select Operating Voltage: | 12VDC (Base), 24VDC (Base) |
| Select Waterproof Rating: | Non-Waterproof IP20 - Adhesive Back (Base), Underwater IP68 - Adhesive Back, Outdoor Silicone Tube IP67 - Adhesive Back |
| Availability | In Stock |
| Condition | Brand New |
COB stands for chip-on-board, the LED chip is placed directly on the PCB board, sealed by a sealing layer, and showing different colors through different sealing layers, which is our super density series LED product.
This flexible FOB LED Strip Lights is the newest production in 2020. This versatile LED Strip Light is in 14.4W/M (4.39Watts foot). This LED Strip has very High-Density Lighting with 384/528 diodes per meter or (195/ft). It is cuttable every 0.98"(25mm) for 12, 2"(50mm) 24VDC. The FPCB width of this led strip light is 10/8mm. And the COB width is 6mm. It is very suitable for aluminum profiles in a smaller size. Because of LED high density, the light through PC cover is fairly uniform without spot. If you seek a higher density, we can customize for you. We PCB factory will make a quick response.
• 384Chips/m Type: 8mm PCB width, warm white 2700K to 6500K daylight (No colored lights);
• 480Chips/m Type: 8mm PCB width, all color options;
• 528Chips/m 10mm Type: all color options;
• 528Chips/m 6mm Type: 3000K, 4000K, 6500K white, and colorful lights.
Product Specification
| LED Strip Type: | Flexible COB LED Strip Lights |
| LED Chip: | On board |
| Input Voltage: | DC12/24V |
| Color: | 1800K-6500K warm yellow amber to daylight white, red, green, blue, ice blue, pink-purple |
| Color Rendering Index: | Ra>90 |
| Beam Angle: | 180° |
| LED Quantity: | 384 chips/m, 528 chips/m |
| Luminous Flux: | 760-950 Lumens/m @2700K, 800-1000 Lumens/m @3000K, 840-1050 Lumens/m @4000K, 880-1100 Lumens/m @6500K |
| Power: | 8-10W/m, 10-12W/m, 14-16W/m |
| PCB Width: | 8mm, 10mm (IP67 & IP68 will be wider by 2-3mm) |
| Length: | 5m 16.4-ft |
| Cut Length: | DC12V 0.98"(25mm), DC24V 2"(50mm) |
| Lifespan: | 30,000+hours |
| Working Temperature: | -20℃ ~ +45℃ |
| Waterproof Rating: | IP20, IP67, IP68 |
How to choose LED strip lights kit?
You can choose the controller or power supply or controller plus power option for this COB LED strip. Of course, only the COB LED light is also completely possible. The difference is whether you need to control the LED brightness change of the COB strip and whether you can supply power to the light strip.
In the following table, we list for you which products you will get if you choose the kit. If you have other needs, please check our product categories.
|
LED Strip |
Power | Voltage | Kit |
| 5m/16.4Ft COB Strip | 40-60W / Roll | DC12V |
Controller: V1 + RT1 Power supply: 12V 72W power supply adapter |
| DC24V |
Controller: V1 + RT1 Power supply: 24V 72W power supply adapter |
If you have any requirements for other types of the LED Controller, you can visit our Single Color Dimmer Series.
Don't know how to choose the correct LED power supply, please read the following article: How to calculate power for led strip lights?
When you purchase the LED power supply, please read the following article: How to choose led strip light power supply?
