12mm/0.47in Silicone Neon Diffuser

2021 Latest Silicone Neon Tube Catalog Download

How to quickly find the neon tube you need?

First confirm the width of your LED strip; if the width of the LED strip is 12mm, please purchase an LED neon tube in the 13mm PCB Wide Neon Tube series;

After confirming the scope of the installation space, select the appropriate size of the LED neon tube; Each model contains a dimensional drawing to describe its width; height and internal structure;

Then determine the light-emitting direction of the LED neon tube (top or side emitting determines the bending direction of the LED strip) and light-emitting angle (120°/180°/270°/360°);

Finally, determine the length of the LED neon tube, the type of end caps; and purchase LED mounting brackets for long-distance installation.

What LED Strip Widths Are Available?

What are LED neon lights?

How to make led neon lights?


Anti-glare Silicone Sleeve Flexible LED Channel For 12mm LED Light Strips - 05*15mm 120° Top Emitting
(0)
Model:FLNLT-T0515

Anti-glare Silicone Sleeve Flexible LED Channel For 12mm LED Light Strips - 05*15mm 120° Top Emitting

  • Length:1m/2m/5m
  • External Width:15mm/0.59in
  • External Height:5mm/0.20in
  • PCB Width:12mm/0.47in
  • Beam Angle:120°
  • Waterproof Rating:IP67
  • Lighting Direction:Top Lighting
  • Cutting Mark:Yes
Various Options In Stock
$2.98
Flat silicone led diffuser for 12mm led strip lighting, no glare lighitng, 05*15mm size, you can choose the transparent diffuser surface or the milky white  diffuser surface to diffused lighting, and this silicone led profile can be installed with red adhesive back tape.    The light refracted from the led strip lighting through the conduction of silicone diffuser to produce the...
Flexible Silicone LED Channel For 12mm LED Strips - 12*20mm 120° Side Emitting
(0)
Model:FLNLT-TT1220

Flexible Silicone LED Channel For 12mm LED Strips - 12*20mm 120° Side Emitting

  • Length:1m/2m/5m
  • Color: White
  • External Width: 12mm/0.47"
  • External Height: 20mm/0.78"
  • PCB Width: 12mm
  • Beam Angle: 120°
  • Waterproof Rating: IP67
  • Lighting Direction: Side lighting
Various Options In Stock
$7.99
Flexible silicone led channel with side emitting light, wide 12mm, 20mm in height, used for 12mm led strip lights, made of  food grade silicone material, the silicone led diffuser channel is soft and bendable, it  has good light transmittance and a large light-emitting angle,  waterproof grade is IP67 and above,  does not change yellow or crack, suitable for indoor and...
Flex Silicone LED Light Channel Dome Top 270° Side Emitting 12*25mm
(0)
Model:FLNLT-T1225

Flex Silicone LED Light Channel Dome Top 270° Side Emitting 12*25mm

  • Length: 1m/2m//5m
  • External Width:12mm/0.47in
  • Inner Width:13mm/0.51in
  • External Height:25mm/0.98in
  • PCB Width:12mm/0.47in
  • Beam Angle:270°
  • Waterproof Rating:IP67
  • Lighting Direction:Side Lighting
Various Options In Stock
$9.99
Dome top silicone led channel with side emitting light, used for 12mm led strip lights installed inside, made of  food grade silicone material, the silicone led diffuser channel is soft and flexible and bendable,  has good light transmittance and a large light-emitting angle,  waterproof grade is IP67 and above,  does not change yellow or crack, suitable for outdoor...
Dome Top Silicone Sleeve With Open Bottom For 12mm LED Strip - 15*23mm 180° Side Emitting
(0)
Model:FLNLT-YT1523

Dome Top Silicone Sleeve With Open Bottom For 12mm LED Strip - 15*23mm 180° Side Emitting

  • Length:1m/2m/5m
  • External Width: 14.6mm/0.57"
  • External Height: 23mm/0.91"
  • Inner Width: 12.8mm/0.5"
  • PCB Width: 12mm
  • Beam Angle: 180°
  • Waterproof Rating: IP67
  • Lighting Direction: Side lighting
Various Options In Stock
$9.99
Flexible silicone sleeve for 12mm/10mm led strip lights, dome top diffuser surface, 180-degree large light-emitting angle, open bottom, easy installation. M ade of high quality food grade silicone material, this silicone led channel has  good light transmittance,  the light refracted from the light source through the conduction of silicone diffusion to produce an ultimate lighting...
Silicone LED Strip Diffuser With White Flange For 12mm LED Light Strip - 16*16mm 120 ° Top Emitting
(0)
Model:FLNLT-NB1616

Silicone LED Strip Diffuser With White Flange For 12mm LED Light Strip - 16*16mm 120 ° Top Emitting

  • Length:1m/2m/5m
  • External Width: 20mm/0.79"
  • External Height: 16mm/0.63"
  • Inner Width: 13mm/0.51"
  • PCB Width: 12mm
  • Beam Angle: 120°
  • Waterproof Rating: IP67
  • Lighting Direction: Top lighting
Various Options In Stock
$6.98
Silicone led strip diffuser with white flange to cover the gap when installed with the rigid bar  aluminum channel , and the white flange can play a role in decorative lines, this silicone led diffuser is to diffused light for 12mm led strip lights, suitable for led linear lighting projects.      Length 5m/2m/1m External Width 16mm/0.63in Inner...
White Silicone Tube LED Strip Light Channel 120° Side Emitting 16*17mm
(0)
Model:FLNLT-T1617

White Silicone Tube LED Strip Light Channel 120° Side Emitting 16*17mm

  • Length: 1m/2m//5m
  • External Width: 16mm/0.63in
  • Inner Width: 13mm/0.51in
  • External Height: 17mm/0.67in
  • PCB Width: 12mm/0.47in
  • Beam Angle: 120°
  • Waterproof Rating: IP67
  • Lighting Direction: Side Lighting
Various Options In Stock
$8.99
Side emitting silicone led strip light channel for 12mm led strip lighting, the light refracted from the LEDs through the conduction of silicone diffuser to produce  good lighting effect, no glare lighting,  has good light transmittance and a large light-emitting angle , the combination of high-density or medium-density LED light strips and the LED flexible silicone tube can...
Dome Top Silicone LED Diffuser Cover For 12mm LED Strip Lights - 25*20mm 180° Top Emitting
(0)
Model:FLNLT-DT1820

Dome Top Silicone LED Diffuser Cover For 12mm LED Strip Lights - 25*20mm 180° Top Emitting

  • Length:1m/2m/5m
  • Type: Silicone Diffuser Cover
  • External Width: 25mm/0.98"
  • External Height: 18mm/0.7"
  • PCB Width: 12mm
  • Beam Angle: 180°
  • Waterproof Rating: IP67
  • Lighting Direction: Top lighting
Various Options In Stock
$5.98
Dome top silicone led diffuser for 12mm led strip lights to get soft and linear lighting, large illumination area. You should put the silicone led diffuser cover into the  aluminum channel  to complete the whole lighting, the strip wire is through the end cap hole to connect the led controller or led power supply. You can use this silicone led diffuser cover to diffuse led strip...
Bendable Silicone LED Light Diffuser Outdoor LED Channel 120° Top Emitting 20*10mm
(0)
Model:FLNLT-T2010-S

Bendable Silicone LED Light Diffuser Outdoor LED Channel 120° Top Emitting 20*10mm

  • Length: 1m/2m//5m
  • External Width: 20mm/0.79in
  • Inner Width: 13.5mm/0.53in
  • External Height: 10mm/0.39in
  • PCB Width: 12mm/0.47in
  • Beam Angle: 120°
  • Waterproof Rating: IP67
  • Lighting Direction: Top lighting
Various Options In Stock
$5.99
20*10mm silicone led light diffuser for 10mm led strip lighting, you can match this silicone led chanenl with single color led strip lights or color changing led strip lights for your home decor, wall decor, or outdoor decorations. Made of high quality food grade silicone material, the led silicone tube  has good light transmittance and a large light-emitting angle,  does not...
Silicone LED Light Channel Diffuser White Edge Without Bottom 120° Top Emitting 20*10mm
(0)
Model:FLNLT-WS2010

Silicone LED Light Channel Diffuser White Edge Without Bottom 120° Top Emitting 20*10mm

  • Length:1m/2m/5m
  • External Width:20mm/0.79in
  • Inner Width:13.5mm/0.53in
  • External Height:10mm/0.39in
  • PCB Width:10mm/0.39in; 12mm/0.47in
  • Beam Angle:120°
  • Lighting Direction:Top Lighting
  • Waterproof Rating:IP67
Various Options In Stock
$5.98
Flat top silicone led light strip diffuser with white flange to diffused lighting for 10mm/12mm led lights strips. You should put the silicone led diffuser into the  aluminum channel  to complete your whole lighting installation, this installation method is suitable for linear lighting projects.     Length 5m/2m/1m External Width 20mm/0.79in Inner...
Silicone LED Channel Diffuser 180° Large Beam Angle Top Emitting 20*14mm
(0)
Model:FLNLT-T2014-T

Silicone LED Channel Diffuser 180° Large Beam Angle Top Emitting 20*14mm

  • Length:1m/2m/5m
  • External Width:20mm/0.79in
  • Inner Width:13mm/0.51in
  • External Height:14mm/0.55in
  • PCB Width:12mm/0.47in
  • Beam Angle:180°
  • Waterproof Rating:IP67
  • Lighting Direction:Top Lighting
Various Options In Stock
$8.99
Silicone le d channel diffuser with three sides illumination for 12mm led strip lights,  large light-emitting angle,  the light refracted from the led light source through the conduction of silicone diffuser to produce  good lighting effect , the combination of high-density or  medium-density LED light strips and the soft silicone tube can almost achieve the dotless...
Silicone LED Diffuser Channel Flexible 120° Top Emitting 20*14mm
(0)
Model:FLNLT-T2014-S

Silicone LED Diffuser Channel Flexible 120° Top Emitting 20*14mm

  • Length:1m/2m/5m
  • External Width:20mm/0.79in
  • Inner Width:13mm/0.51in
  • External Height:14mm/0.55in
  • PCB Width:12mm/0.47in
  • Beam Angle:120°
  • Waterproof Rating:IP67
  • Lighting Direction:Top Lighting
Various Options In Stock
$8.99
Silicone led diffuser channel for 12mm led strip lighting, top emitting led light, the light refracted from the led light source through the conduction of silicone diffuser to produce  good lighting effect .  The combination of high-density or medium-density LED light strips and the soft silicone tube can almost achieve the dotless effect.    Made of high quality...
Silicone LED Flex Neon Tube Light Waterproof 120° Top Emitting 20*14mm
(0)
Model:FLNLT-TAB2014

Silicone LED Flex Neon Tube Light Waterproof 120° Top Emitting 20*14mm

  • Length:1m/2m/5m
  • External Width:20mm/0.79in
  • Inner Width:13mm/0.51in
  • External Height:14mm/0.55in
  • PCB Width:10mm/0.39in, 12mm/0.47in
  • Beam Angle:120°
  • Lighting Direction:Top Lighting
  • Waterproof Rating:IP67
Various Options In Stock
$7.99
Silicone led diffuser for 10mm or 12mm wide led strip lighting, 20*14mm size, the light refracted from the light source through the conduction of silicone diffusion to produce the ultimate lighting effect which is more artistic and practical.   The LED flexible neon tube has two main functions, the first is that the light-emitting angle is large, the combination of bright LED...
Silicone LED Strip Diffuser Channel For 12/10mm Flexible LED Strip Lights - 20*14mm 180° Three Sides Emitting
(0)
Model:FLNLT-TAB2014-L

Silicone LED Strip Diffuser Channel For 12/10mm Flexible LED Strip Lights - 20*14mm 180° Three Sides Emitting

  • Length:1m/2m/5m
  • External Width: 20mm/0.79"
  • External Height: 14mm/0.55"
  • PCB Width: 12/10mm
  • Color: White
  • Beam Angle: 180°
  • Waterproof Rating: IP67
  • Lighting Direction: Top lighting
Various Options In Stock
$8.99
Silicone led diffuser channel with great flexibility for 10mm or 12mm wide led strip lighting, 20*14mm size, the light refracted from the led light source through the conduction of silicone diffuser to produce the ultimate lighting effect which is more artistic and practical.   The flexible silicone led channel has two main functions, the first is that the large light-emitting angle...
Black Silicone LED Diffuser Flexible LED Strip Light Channel Top Emitting 20*20mm
(0)
Model:FLNLT-CT2020

Black Silicone LED Diffuser Flexible LED Strip Light Channel Top Emitting 20*20mm

  • Length:1m/2m/5m
  • External Width:20mm/0.79in
  • Inner Width:13.5mm/0.53in
  • External Height:20mm/0.79in
  • PCB Width:12mm/0.47in
  • Beam Angle:120°
  • Waterproof Rating:IP67
  • Lighting Direction:Top Lighting
Various Options In Stock
$12.99
Check this 20*20mm waterproof led silicone tube with black finished for 12mm led strip lights . The different internal structures of neon led silicone tubes focus on different ways of using neon led strips. This neon silicone tube diffuses the upward LED light from the bottom LED light strip and bents along the back of the strip. Good bending performance.  Made of food-grade...
Black Silicone LED Strip Tube Flexible LED Channel 120° Top Emitting 20*20mm
(0)
Model:FLNLT-T2020-B

Black Silicone LED Strip Tube Flexible LED Channel 120° Top Emitting 20*20mm

  • Length: 1m/2m//5m
  • External Width: 20mm/0.79in
  • Inner Width: 13.5mm/0.53in
  • External Height: 20mm/0.79in
  • PCB Width: 12mm/0.47in
  • Beam Angle: 120°
  • Waterproof Rating: IP67
  • Lighting Direction: Top lighting
Various Options In Stock
$12.99
Silicone led strip diffuser flexible led tube with all black finish, top emits the inside led strip lighting,  20*20mm outer size, the inside led strip width can not exceed 13mm. This soft silicone led channel is IP67 waterproof for the led strip light, can be used outdoors.      What is a LED neon tube? LED flexible neon tube is also known as two-color tube, the product...
Black Surface Silicone LED Strip Diffuser For 12/10mm LED Lights Strips - 20*20mm 120° Top Emitting
(0)
Model:FLNLT-BTL2020

Black Surface Silicone LED Strip Diffuser For 12/10mm LED Lights Strips - 20*20mm 120° Top Emitting

  • Length: 1m/2m//5m
  • External Width:20mm/0.79in
  • Inner Width:13.5mm/0.53in
  • External Height:20mm/0.79in
  • PCB Width:12mm/10mm
  • Beam Angle:120°
  • Lighting Direction:Top Lighting
  • Waterproof Rating:IP67
Various Options In Stock
$8.99
This black silicone diffuser with flange for 10mm or 12mm led strip lighting is designed to use with aluminum channel , suitable for led linear lighting. The led strip light is pasted in the aluminum channel, and then cover the strip light with this silicone diffuser to get a soft and linear led lighting effect. And the black diffuser surface can decorate your home lighting or wall lighting...
Flexible Silicone Channel For 12/10mm LED Light Strips - 20*20mm 120° Top Emitting
(0)
Model:FLNLT-BTL2020-W

Flexible Silicone Channel For 12/10mm LED Light Strips - 20*20mm 120° Top Emitting

  • Length:1m/2m/5m
  • Inner Width: 13.5mm/0.53"
  • External Width: 20mm/0.79"
  • External Height: 20mm/0.79"
  • PCB Width: 10/12mm
  • Beam Angle: 120°
  • Waterproof Rating: IP67
  • Lighting Direction: Top lighting
Various Options In Stock
$8.99
This white silicone tube diffuser with flange for 10mm or 12mm led strip lights is designed to use with rigid aluminum channel , suitable for led linear lighting. The led strip light is pasted on the bottom of the aluminum channel, and then cover the strip with this silicone led diffuser to get a soft and dotless lighting effect.    Model:  FLNLT-BTL2020-W Tube...
Flexible Silicone LED Neon Lighting Tubes 120° Top Emitting 20*20mm
(0)
Model:FLNLT-ET2020

Flexible Silicone LED Neon Lighting Tubes 120° Top Emitting 20*20mm

  • Length:1m/2m/5m
  • External Width:20mm/0.79in
  • Inner Width:13mm/0.51in
  • External Height:20mm/0.79in
  • PCB Width:12mm/0.47in
  • Beam Angle:120°
  • Waterproof Rating:IP67
  • Lighting Direction:Top Lighting
Various Options In Stock
$7.99
Square silicone led tube for 10mm led strip lights to be installed inside, made of  high quality food grade silicone material, this silicone led diffuser channel is flexible and bendable,  has good light transmittance and a large light-emitting angle, it  does not change yellow or crack, waterproof grade is IP67 and above,  so you can use this silicone led channel for...
Flexible Silicone LED Profile With Flange For 10/12mm LED Strip Lights - 20*20mm 120° Top Emitting
(0)
Model:FLNLT-T2020-WF

Flexible Silicone LED Profile With Flange For 10/12mm LED Strip Lights - 20*20mm 120° Top Emitting

  • Length:1m/2m/5m
  • Color: White
  • External Width: 27mm/1.06"
  • External Height: 20mm/0.79"
  • PCB Width: 10/12mm
  • Beam Angle: 120°
  • Waterproof Rating: IP67
  • Lighting Direction: Top lighting
Various Options In Stock
$8.99
Silicone led profile for 10mm or 12mm led strip lights to be installed inside, the white flange can cover the recessed gap and decorate your places with white lines.    Made of  high quality food grade silicone material, this led silicone profile is flexible and bendable,  has good light transmittance and a large light-emitting angle, it  does not change yellow or...
Silicone Diffuser Outdoor LED Strip Light Channel 120° Top Emitting 20*20mm
(0)
Model:FLNLT-YT2020

Silicone Diffuser Outdoor LED Strip Light Channel 120° Top Emitting 20*20mm

  • Length:1m/2m/5m
  • External Width:20mm/0.79in
  • Inner Width:13.5mm/0.53in
  • External Height:20mm/0.79in
  • PCB Width:12mm/0.47in
  • Beam Angle:120°
  • Waterproof Rating:IP67
  • Lighting Direction:Top Lighting
Various Options In Stock
$11.99
Silicone led strip light channel for 12mm led light strips to create soft and linear light effect, top emitting led light,  the light refracted from the led strip lighting through the conduction of silicone diffuser,  the combination of high-density or medium-density LED light strips and the soft silicone tube can almost achieve the dotless effect.    Made  of high...
