The controller adopts the widely used 2.4GHz wireless technology with the features of low power consumption, long signal transmitting, and strong anti-interference, etc. The controller has an auto-transmitting and auto-synchronizing function. Widely used on the controlling of hotel lighting and home lighting.
Miboxer LED Light&Controller
Sponsors
Sponsors
DMX512 Wireless
(0)Model:FUTD01
FUTD01 DMX 512 LED Transmitter
- Voltage: DC5V/500mA
- Frequency:2400-2483.5MHz
- Modulation Method : GFSK
- Power : 6dBm
- Distance: 30m
- Size: 188*47*23mm
Product Name: DMX 512 LED Transmitter Model No.: FUTD01 Voltage: DC5V-500mA Frequency: 2400-2483.5MHz Transmitting Method: GFSK Power: 6dBm Distance: 30m Size: 188*47*23mm Specifications Download Product Description
(0)Model:FUT039S-P
Waterproof RGB+CCT LED Controller (2.4G) FUT039S-P
- Input Voltage: 12-24VDC
- Output Current: 6A/Channel
- Total Output: Max 12A
- IP Rate: IP66
- Control Distance: 30m
- RF: 2.4GHz
Product Description • 2.4G RF Remote controllable • 16 Millions of colors to choose • Color temperature adjustable • Brightness and saturation controllable • Signal transmitting function make control distance limitless • Support PWM high frequency (8KHz) / Low frequency (500Hz) switched • DMX512 Controllable (Need DMX512 LED transmitter) • IP66 waterproof...
(0)Model:FUT012
FUT012 9W DMX512 RGB+CCT LED Bulb ( The Upgraded Version of FUTD04， FUTD03)
- voltage: AC86~265V
- Kelvin: 2700~6500K
- Luminous Flux: 850LM
- Luminous Efficiency: 95LM/W
- CRI: >80
- Beam Angle: 220°
- Control Distance: 30m
- Size: Φ74*137mm
Product Name: 9W RGB+CCT LED Bulb Model No: FUT012 Power: 9W Voltage: AC86~265V / 50~60Hz Kelvin: 2700~6500K Luminous Flux: 850LM Luminous Efficiency: 95LM/W CRI: >80 PF: >0.5 Lifespan: 50000 Hours Beam Angle: 220° Control Distance: 30m Size: Φ74*137mm
(1)Model:FUT039UP
FUT039M Upgraded 2.4GHz RGB+CCT LED Strip Controller
- Voltage: DC12V-24V
- Output : 6A/Channel
- Control Distance : 30m
- Total Output Max: 12A
- Transmitting power: 6dBm
- Output connection: Common anode
Product Parameters Product Name: 2.4GHz RGB+CCT LED Strip Controller Model No.: FUT039M (Upgraded) Working Voltage: DC12V~24V Working Temperature: -20~60°C Output Max: 6A/Channel Total Output Max:12A RF: 2.4GHz Transmitting power: 6dBm Control Distance: 30m Output connection: Common anode Product Description
(0)Model:FUTD03
FUTD03 8W DMX512 RGB+CCT LED Light Bulb For led strip light ( Using New Version of FUT012 to Replace )
- Voltage: AC86-265V
- Power: 8W
- Kelvin: 2700-6500K
- Luminous Flux: 500-550LM
- Efficiency: 70LM/W
- Control Distance: 30m
- Beam Angle: 230°
- PF: >0.65
Product Name: 8W DMX512 RGB+CCT LED Light Bulb ( Using New Version of FUT012 to Replace ) Model No: FUTD03 Power: 8W Voltage: AC86-265V / 50-60Hz Kelvin: 2700-6500K Luminous Flux: 500-550LM Luminous Efficiency: 70LM/W CRI: >80 Base Type: E26 / E27 / B22 Beam Angle: 230° PF: >0.65 Material: Aluminum+PC Cover Control Distance: 30m Size: Φ68.5*120mm ...
(0)Model:FUT039S
2.4GHz RGB+CCT LED Controller - Replaced By FUT037S+
- Working Voltage: DC12V/24V
- Output Max: 6A/Channel
- Total Output Max: 12A
- RF: 2.4GHz
FUT039S RGBCCT controller has been upgraded to FUT037S+ 3in1 (RGB+RGBW+RGBCCT) led controller. If you still order this item, we will send you FUT037S+. The controller adopts the widely used 2.4GHz wireless technology with the features of low power consumption, long signal transmitting, and strong anti-interference, etc. The controller has auto-transmitting and...
(0)Model:FUTD04
FUTD04 9W DMX512 RGB+CCT LED Light Bulb ( Using New Version of FUT012 to Replace )
- voltage: 85-265VAC
- Kelvin: 2700-6500K
- Luminous Flux: 850LM
- Efficiency: 95LM/W
- Base Type: 220°
- Material: Aluminum+PC
- size: Φ74*137mm
- CRI: >80
Product Name: 9W DMX512 RGB+CCT LED Light Bulb Model No : FUTD04 Power : 9W Voltage : AC86-265V 50/60Hz Kelvin: 2700-6500K Luminous Flux : 850LM Luminous Efficiency : 95LM/W CRI: >80 PF : >0.5 Base Type : E26 / E27 / B22 Beam Angle : 220° Material: Aluminum+PC Cover Control Distance : 30m Size : Φ74*137mm Application Areas: houses,...
(0)Model:FUTD02
FUTD02 DMX512 RGB+CCT Strip Controller ( Replaced By FUT039UP)
- Voltage: DC12V/24V
- Output: Max. 6A/Channel
- Control Distance: 30m
- Size: 85*45*22.5mm
Product Name: DMX512 RGB+CCT Strip Controller Model No.: FUTD02 Voltage: DC12V-24V Output: Max. 6A/Channel, Total output Max.10A Control Distance: 30m Size: 85*45*22.5mm The FUTD02 Controller has been discontined, but there are the replacements, after you place the order, we will send you the FUT039 or FUT039UP , they have the same functions. Product Description
(0)Model:FUT039P
RGB+CCT LED Controller (20A High Current Output) FUT039P
- Input Voltage: DC12~36V
- Output Current: 10A/Channel
- Total Output: Max 20A
- Control Distance: 30m
- RF: 2.4GHz
- Working Temperature: -10~40℃
Product Description • 2.4G RF Remote controllable • 16 Millions of colors to choose • Color temperature adjustable • Brightness and saturation controllable • Signal transmitting function make control distance limitless • Support PWM high frequency (8KHz) / Low frequency (500Hz) switched • DMX512 Controllable (Need DMX512 LED transmitter) Product...
