Smart Home(Bluetooth Mesh)
(0)Model:SP-GW-BLE
Super Panel Whole House Intelligence
- Power Supply: AC100-240V
- Speaker: AAC 1813
- Microphone: Dual Microphone Array
- Master Control: Quad-core Processor
- Terminal Box: 86 and EU type
Product Introduction Super Panel is a central control panel that integrates all of your connected devices to control the entire smart home. Based on 5G speed with cloud computing, it has the powerful intelligent gateway function with Bluetooth 5.0 SIG Mesh technology and is compatible with Wi-Fi, Bluetooth 5.0 SIG Mesh, and Ethernet. Support button, touch, and mobile App control. Multiple...
(0)Model:RELAY-BLE01
RELAY-BLE01 Bluetooth Smart Light Switch Module For AC High Voltage
- Wireless: Bluetooth 5.0
- Voltage: AC100-240V
- Power: ≤400VA / 800W
- Channel: 1CH
- Size: 80x35x23mm
Bluetooth switch module is an intelligent control device that directly connects to AC power (e.g. 110V or 240V) and supports remote switching, dimming, timing, etc. It is commonly used in intelligent transformation of lighting systems in homes and commercial premises without additional low-voltage wiring. RELAY-BLE01 smart module switch is compatible with SIG Mesh protocol, which...
(0)Model:GC-DAM-PRO
Bluetooth 5.0 Sig Mesh Wireless LED Control Module GC-DAM-PRO
- Protocol : Bluetooth 5.0 SIG Mesh
- Output Signal: DMX/ DALI/ 0-10V
- Working Voltage: 100 ~ 240Vac
- DALI Output: 12Vdc (Max.90mA)
- Product Size: 84×35×23(mm)
- Working Temperature: -20°C ~ 55°C
Product Characteristics GC-DAM-PRO is a lightweight Bluetooth module with high networking capacity, which crafted with V0 flame retardant PC materials from SAMSUNG/COVESTRO, elevating your lighting experience. Integrating DMX, DALI and 0-10V outputs into a single port, with the support of a DALI bus power supply, our led module can streamline your lighting control. This light control module can...
(0)Model:LM-150-24-G1B2
150W 24VDC CV Bluetooth Smart LED Driver LM-150-24-G1B2
- Input Voltage: 220-240Vac
- output Voltage: 24Vdc
- Output Power: Max. 150W
- Control Mode: Bluetooth 5.0 Mesh, Push DIM
- Output Current: Max. 12.5A
- Dimensions: 352×43×30mm
Product Introduction Intelligent LED Driver (Constant Voltage) Adopt SAMSUNG/COVESTRO V0 flame resistant polycarbonate protectivehousings with small size and light weight.Bluetooth 5.0 Mesh with high networking capability are reliable and stable. With soft-on and fade-in dimming function enhancing visual comfort. T-PWM dimming technology allows continuous and flicker-free images underhigh-speed...
(0)Model:LM-150-24-G2B2
150W 24VDC CV Tunable White LED Driver LM-150-24-G2B2
- Input Voltage: 220-240Vac
- Output Voltage: 24Vdc
- Output Power: Max. 150W
- Output Current: Max. 12.5A
- Control Mode: Bluetooth 5.0 Mesh, Push DIM
- Dimensions: 352×43×30mm(L×W×H)
Product Introduction telligent Tunable White LED Driver (Constant Voltage) Adopt SAMSUNG/COVESTRO V0 flame resistant polycarbonate protective housings with small size and light weight. Bluetooth 5.0 Mesh with high networking capability are reliable and stable. With soft-on and fade-in dimming function enhancing visual comfort. T-PWM dimming technology allows continuous and...
(0)Model:UB1
Intelligent Touch Panel UB1 (Bluetooth + DMX / Programmable)
- Control mode: DIM
- Input voltage: 12-24VDC
- Wireless protocol: Bluetooth 5.0
- Output signals: DMX 512
- Zones: 4
- Dimensions : 120×75×30(mm)
Product Introduction The Intelligent Touch Panel is an American base wall switch, integrating Bluetooth h 5.0 SIG Mesh protocol and DMX signals. It is a simple but elegant design with a CNC aviation aluminum frame and 2.5D tempered glass. The panel is suitable for multi-scene and multi-zone lighting control applications. Working with Bluetooth systems makes it t more convenient and...
(0)Model:UB4
RGBW Intelligent Touch Panel UB4 (Bluetooth + DMX / Programmable)
- Zones: 4
- Control mode: RGBW
- Input voltage: 12-24VDC
- Output signals: DMX 512
- Wireless protocol: Bluetooth 5.0
- Dimensions: 120×75×30(mm)
Product Introduction The Intelligent Touch Panel is an American base wall switch, integrating Bluetooth h 5.0 SIG Mesh protocol and DMX signals. It is a simple but elegant design with a CNC aviation aluminum frame and 2.5D tempered glass. The panel is suitable for multi-scene and multi-zone lighting control applications. Working with Bluetooth systems makes it t more convenient and...
(0)Model:UB5
RGBWY Intelligent Touch Panel UB5 (Bluetooth + DMX / Programmable)
- Input voltage: 12-24VDC
- Wireless protocol: Bluetooth 5.0
- Output signals: DMX 512
- Zones: 4
- Dimensions : 120×75×30(mm)
- Control mode: RGBWY
The Intelligent Touch Panel is an American base wall switch, integrating Bluetooth h 5.0 SIG Mesh protocol and DMX signals. It is a simple but elegant design with a CNC aviation aluminum frame and 2.5D tempered glass. The panel is suitable for multi-scene and multi-zone lighting control applications. Working with Bluetooth systems makes it t more convenient and intelligent. If you just...
(0)Model:UB2
Tunable White Intelligent Touch Panel UB2 (Bluetooth + DMX / Programmable)
- Control mode: CT
- Zones: 4
- Input voltage: 12-24VDC
- Wireless protocol: Bluetooth 5.0
- Output signals: DMX 512
- Dimensions: 120×75×30(mm)
Product Introduction The Intelligent Touch Panel is an American base wall switch, integrating Bluetooth h 5.0 SIG Mesh protocol and DMX signals. It is a simple but elegant design with a CNC aviation aluminum frame and 2.5D tempered glass. The panel is suitable for multi-scene and multi-zone lighting control applications. Working with Bluetooth systems makes it t more convenient and...
(0)Model:RC4-BLE
Bluetooth LED Remote RC4-BLE
- Working Voltage: 3Vdc
- Wireless Protocol: Bluetooth 5.0
- Dimensions: 40×150×13(mm)
- Control mode: DIM
Product Introduction Bluetooth LED remote adopts Bluetooth 5.0 SIG Mesh technology with low power consumption. Work with Bluetooth wireless LED driver to simultaneously control different types of light fixtures in multiple zones. You can turn lights on / off, set the dim level, change color temperature and colors of lights with one remote. Simple and flexible operations put you in easy control of...
(0)Model:SE-12-100-400-W1B
Intelligent LED Driver，12W CC Dimmable Driver SE-12-100-400-W1B
- Input voltage: 100-240VAC
- Efficiency: >80%
- Output Voltage: 9-42Vdc
- Current Accuracy: ±5%
- Frequency: 50/60Hz
Intelligent LED Driver (Constant Current) Adopt SAMSUNG/COVESTRO V0 flame-resistant polycarbonate protective housings with small size and lightweight. Bluetooth 5.0 Mesh with high networking capability is reliable and stable. Soft-on and fade-in function provides the soft-start time from 0s to 99s that enhances visual comfort Adjust brightness levels when lights are turned on or go...
(0)Model:SE-20-250-1000-W2B2
Intelligent Tunable White LED Driver，20W CC Tunable White LED Driver SE-20-250-1000-W2B2
- Input voltage: 100-240VAC
- Efficiency: >83%
- Current Accuracy: ±5%
- Frequency: 50/60Hz
- Weight: 200g
Intelligent Tunable White LED Driver (Constant Current) Adopt SAMSUNG/COVESTRO V0 flame-resistant polycarbonate protective housings with small size and lightweight. Bluetooth 5.0 Mesh with high networking capability is reliable and stable. Adjust brightness levels when lights are turned on or go to the brightness level adjusted last time. T-PWM dimming technology allows continuous...
(0)Model:ST-75-24-W1B
75W 24VDC CV Bluetooth Smart LED Driver ST-75-24-W1B
- Input Voltage: 100-240Vac
- output Voltage: 24Vdc
- Output Power: Max. 75W
- Output Current: 3.125A
- Dimensions: L143*W58*H32 (mm)
- Control Mode: Dimming
Product Introduction Bluetooth Smart LED Driver adopts Bluetooth 5.0 Mesh technology with low power consumption. You can easily control the smart LED driver with App, and it enables you to connect your Bluetooth remotes and Bluetooth smart wireless switches for dimming, color temperature adjustment and color changing. You'll able to remotely control your lighting...
(0)Model:ST-75-24-W3B
75W 24VDC CV RGB Bluetooth Smart LED Driver ST-75-24-W3B
- Input Voltage: 100-240Vac
- output Voltage: 24Vdc
- Output Power: Max. 75W
- Output Current: 1.04A×3CH
- Control Mode: RGB
- Wireless Protocol Type: Bluetooth 5.0
Product Introduction Bluetooth Smart LED Driver adopts Bluetooth 5.0 Mesh technology with low power consumption. You can easily control the smart LED driver with App, and it enables you to connect your Bluetooth remotes and Bluetooth smart wireless switches for dimming, color temperature adjustment, and color changing. You'll able to remotely control your lighting by LTECH Super Panel and...
(0)Model:ST-75-24-W2B
75W 24VDC CV Tunable White Bluetooth Smart LED Driver ST-75-24-W2B
- Input Voltage: 100-240Vac
- output Voltage: 24Vdc
- Output Power: Max. 75W
- Output Current: 1.56A×2CH
- Control Mode: Color temperature
- Dimensions: L143 W58 H32 (mm)
Product Introduction Bluetooth Smart LED Driver adopts Bluetooth 5.0 Mesh technology with low power consumption. You can easily control the smart LED driver with App, and it enables you to connect your Bluetooth remotes and Bluetooth smart wireless switches for dimming, color temperature adjustment, and color changing. You'll able to remotely control your lighting...
