RGB/RGBW/RGBCCT LED Strip Amplifier
(0)Model:LN-ZJFJ-3CH-LV
LN-ZJFJ-3CH-LV 3 Channels LED Repeater Amplifier, RGB Amplifier
- Voltage:DC5V/12-24V
- WT:-20-60℃
- Output: 3 channels
- Connection Method:Common
- Output Current:<4A (each circuit)
RGB amplifiers are suitable for all voltage-controlled LED controllers of our company. RGB can accept PWM (pulse width modulation). Each additional RGB amplifier can be connected with twice the number of LEDs. In theory, countless RGB amplifiers can be connected. Standards and Certifications Technical Parameters ● Working...
(0)Model:AP100
AP100 DC12V-24V High-speed High-current Power Expander, Mode Programming LED Relay
- Output: 3 channel
- Connection Mode: Common
- Applied to: RGB strips
- Output Current: max 8A
- Delay Time:20NS
- Dimming Range: 0.1%-100%
Amplify the red, green, blue three group signal of 3 channel controller, improve the system with load capacity, and has minimal delay, but can keep synchronism in cascade. The outlet should be connected correctly according to the color shown in the wiring diagram. Can't be wrong attached, in order to avoid short-circuit. Standards and Certifications ...
(0)Model:AP103
AP103 DC5V-24V High-speed Large Current RGBW Power Amplifier
- Voltage:DC5-24V
- WT: -20-60℃
- Dimming Range:0.1%-100%
- Output Current:<32A
- Output Powe:5V: <160W, 24V: <768W
High-speed high-current power expander, suitable for PWM-controlled LED controller, can amplify the power of the LED controller, each additional expander can be connected to double to triple the number of LED lights, and can be cascaded, theory You can connect unlimited power expanders. It is convenient for the unified control of LED lamps with different voltages, high power and low power....
(0)Model:AP101
AP101 DC5-24V 1 Channel High-speed Power Amplifier, LED Power Amplifier
- Voltage:DC5-24V
- WT: -20-60℃
- Output: 1 Channel
- Connection Method:Common
- Output Current:Max 16A
Standards and Certifications Technical Parameters ● Working Temperature: -20-60℃ ●Input voltage: DC 5-24V ●Static power consumption: <1W ● Output current: Max 16A ● Output: 1 Channel ● Maximum output power: 380W/24V ● Output connection method: Common anode ● Dimensions: 83mm*79mm*33mm ● Delay time: 20NS ...
(0)Model:CONAMP-CCT-1
DC12/24V 6Ax2CH, LED 6 Ampere 3 Channel RGB Amplifier Iron shell Amplifier For Color Temperature LED Light Strips , CCT LED Lighting
- Voltage(v):12/24
- Operating current(a):18a max
- Applied to: CCT
- Waterproof Rating: IP20
- power: 216w/432w
- Shell: Ironclad
This LED 6 Ampere 3 Channel CCT color temperature Amplifier For Color Changing LED Lighting. Auto adaptation of 12~24V DC working voltage and with input polarity protection function. The newest PWM control technology , delicate light performance , no flicker. High power dimmer control MOS tube with stable and reliable performance , strong power-drive ability with max 18A. The input brightness...
(0)Model:CONAMP-RGB-1
DC5-24V 5x 3A each color RGB+CCT Led Strip Amplifier
- Voltage: DC5-24V
- WT:-20 ~ 60
- Usage:amplifier
- current: 5x 3A
- Lifespan: >50000hours
- Connecting Mode: Common anode
Specifications: Usage : RGB+CCT led strip amplifier Supply Voltage: DC5-24V Connecting Mode: Common anode Max. Output current: 5x 3A each color Working Temperature: -20 ~ 60 Long lifespan >50,000 hours Applications: The RGB+CCT amplifier applies to the voltage-controlled LED controller; it can receive PWM (Pulse Width Modulation). Each time add one RGB amplifier, the...
(0)Model:EC4
EC4 4CH*350mA/700mA DC12-48V CC Power Repeater
- voltage: DC12-48V
- Input signal:PWM
- Output Type:constant voltage
- Output Channels:4 Channels
- Waterproof Rating:IP20
Features ● 12-48V constant current power repeater. ● 4 channel, 350mA/750mA per channel. ● To receive PWM signal control. ● Power repeater in parallel to expand output unlimitedly. ● Apply to single color, dual color, RGB or RGBW constant current LED lamps. Safety & Warnings 1. The product shall be installed and serviced by a qualified person. 2. This product is...
(0)Model:EV3
DC12-36V 3CH Constant Voltage Power Repeater EV3 For RGB LED Strip
- voltage: 12-36VDC
- Load current:3CH, 6A/CH
- Output power:3 x (72-216)W
- W T: -30℃~55℃
- size:L175×W45×H27mm
Summary Used with various LED PWM constant voltage controller, expand output power of the controller to control more lamps. A controller can connect unlimited number of LED power repeaters in series or in parallel,and achieve the synchronous control effects. Standards and Certifications ...
(0)Model:CONAMP-RGBW-1
DC12/24V 6Ax4CH Max24A, PWM LED RGBW Data Signal Amplifier Aluminum shell For RGB+White SMD 3528 5050 LED Light Strip
- Operating Voltage(v): 12/24
- Applied to: RGBW/RGB
- Output Channel: 4
- Waterproof Rating: IP33
- Shell: Aluminum
This LED RGB 6A 4 Channel 24A series four channel RGB/RGBW amplifier. Maximum 6 Amps per channel/24 Amps total. Increases the load capability and extends the signal of universal RGB/RGBW controllers. Required if exceeding the maximum load capability of any universal RGB/RGBW controller. 12~24VDC operation. Standards and Certifications ...
(0)Model:EV3-X
DC5-24V 3CH 10A Constant Voltage Power Repeater EV3-X For RGB LED Strip
- voltage: DC5-24V
- power: 3 x (50-240)W
- Load current: 3CH, 10A/CH
- W T: -30℃~55℃
- size:L110×W74.5×H24.5mm
Summary Used with various LED PWM constant voltage controller, expand output power of the controller to control more lamps. A controller can connect unlimited number of LED power repeaters in series or in parallel,and achieve the synchronous control effects. Standards and Certifications ...
(0)Model:EV4
DC12-36V 4CH Constant Voltage Power Repeater EV4 For RGBW LED Lamp
- Input voltage: 12-36VDC
- Load current:4CH, 5A/CH
- Output power:4 x (60-180)W
- W T:-30℃~55℃
- size:L175×W45×H27mm
Summary Used with various LED PWM constant voltage controller, expand output power of the controller to control more lamps. 2.A controller can connect unlimited number of LED power repeaters in series or in parallel, and achieve the synchronous control effects. Standards and Certifications ...
(0)Model:CONAMP-WPRGB-1
DC12/24V 4Ax3CH, IP65 Waterproof RGB LED Repeater Amplifier Common Anode Fit For Color Change LED Light Strips
- Operating Voltage(v): 12/24
- Operating current(a): 12
- Applied to: RGB strips
- Waterproof Rating: IP65
- Output Channel: 3
- Shell: Aluminum
- Warranty: 3years
Working Temperature: -25~50 °C. Input Voltage :DC12-24V. Output Voltage :DC12-24V. Output Channel: 3 (RGB Common Anode). Output Current :4A (each channel) * 3 = 12A. Product Size: L42mm * W28mm * H16mm. Weight :50g. Waterproof :Yes (IP65) Standards and Certifications ...
(0)Model:CONAMP-WPRGB-2
DC12/24V 4Ax3CH, ABS shell Waterproof IP67 LED RGB Data Signal Amplifier Used to Extend Color Change LED Strip Lights
- Supply voltage: 5/12/24
- Applied to: RGB strips
- Output Channel: 3
- Waterproof Rating: IP67
- Shell: Plastic
RGB waterproof-Amplifier adjust to all the voltage-controlled LED controller of our company,it has waterproof function,RGB could accept PWM(Pulse Width Module) , Each one RGB amplifier can be added, the connecting number of LED will up to more than twice,countless RGB amplifiers could be connected in theory. Standards and Certifications ...
(0)Model:EV4-D
DC5-36V 4CH Din-rail Constant Voltage Power Repeater EV4-D For outdoor RGBW led light strip
- Input voltage: 5-36VDC
- Load current:4CH, 5A/CH
- Output power:4 x (24-180)W
- W T:-30℃~55℃
- size:L115×W48×H67mm
Summary Used with various LED PWM constant voltage controller, expand output power of the controller to control more lamps. A controller can connect unlimited number of LED power repeaters in series or in parallel,and achieve the synchronous control effects. Standards and Certifications ...
(0)Model:CONAMP-RGBCCT-1
DC5-24V 3Ax6CH, LED Mini Inline Amplifier Repeater Data Signal Amplifier For Single Color LED Light Strips.
- Type:Single Amplifier
- Working current:18A
- Voltage:DC5-24V
- Working power:144W
- Remote Distance:10-20M
This small compact LED amplifier will help boost the signal of your LED strip lights after the allotted run length. Supper mini, safe and easy to operate. Typically, you will only need this Single amplifier product if you are dimming your LED strip lights from an LED dimmer. This amplifier will carry the dimming signal (PWM) from the first run of LEDs to the second run. If you are not...
.jpg "DC12V-24V LED Power Repeater BC-960-5A")
(0)Model:BC-960-5A
DC12V-24V LED Power Repeater BC-960-5A
- Input voltage: DC12V-24V
- Max output power: 180W/360W
- Max load Current:5A×3CH
- size:L125xW45xH36mm
LED Power Repeater is suitable for all of our company's power-output style controllers’ power expansion, it accepts PWM control, the control quantity of LED lights would be twice as much by adding one more power repeater, unlimited quantity of power repeater to be connected theoretically. Also, the power repeater of constant voltage model and the constant current model could be...
(0)Model:CONAMP-RGB-1
DC5/12/24V 4Ax3CH, Mini LED RGB Amplifier 3CH Common Anode Fit For Color Change LED Light Strips
- Type: RGB Amplifier
- Color: White
- Craft materials: PVC
- Working current:12A
- Voltage: DC12V
- Working power: 144W
This DC5~24V small compact Mini series three channel RGB amplifier. Maximum 4 Amps per channel/12 Amps total. Used to increase the load capability and extend the signal of the universal RGB controllers. Required if exceeding the maximum load capability of any universal RGB controller. 12VDC operation. 2 x 4-pin RGB pigtail connectors included. Every add a amplifier, can connect double LED...
(0)Model:BC-960-8A
DC12V-24V LED Power Repeater BC-960-8A
- Input voltage: DC12V-24V
- Max out power: 288W/580W
- size:L165×W56×H36(mm)
- Max load Current:8A×3CH
LED Power Repeater is suitable for all of our company's power-output style controllers’ power expansion, it accepts PWM control, the control quantity of LED lights would be twice as much by adding one more power repeater, unlimited quantity of power repeater to be connected theoretically. Also, the power repeater of constant voltage model and the constant current model could be...
(0)Model:CONAMP-RGB-3
DC5V/12-24V common anode 3 channels RGB amplifier for RGB + White Flexible LED Strip Light
- Voltage: DC5V/12-24V
- Applied to: RGB strips
- Output: 3 channels
- Connection mode:common
- power consumption: <1W
RGB amplifier applies to all the voltage-controlled LED controller in our company,it can receives PWM(Pulse Width Modulation), each time add one RGB amplifier, the connecting number of led will be more than twice, in theory, numerous RGB amplifiers can be connected. Standards and Certifications Technical parameters ...
(0)Model:LT-3060-8A
CV Power Repeater LT-3060-8A
- Input signal: PWM
- Input voltage: DC5V~DC24V
- Max current: Max 24A
- power:120W/288W/576W
- Output signal : CV PWM
- Working tem: -30℃~65℃
Product Details Input signal : PWM Input voltage : DC5V~DC24V Max load current : 8A ×3CH Max 24A Max output power : 120W/288W/576W(5V/12V/24V) Output signal : CV PWM Working temperature: -30℃~65℃ Dimension: L148×W87×H23(mm) Package Size: L158×W94×H31(mm) Weight (G.W) : 380g LT-3060-8A
