RF Remote Control RGB
(0)Model:V3-C
RF Series V3-C Mini Hardwired High Power 18A 3 Button RGB Light Controller
- Input Voltage: 12-24VDC
- Output Current: 3x6A/3x5A
- Output Power: 216-432W/180-360W
- Control Mode: 3 buttons+RF
- PWM Frequency: 500/2K/8K/16K
- Size: L90xW40xH28mm
A high power mini RGB light controller to control DC12-24V LED RGB lights. This V3-C with 3 control buttons, on/off, color, brightness, mode, speed are adjustable. Short press "Mode/Speed" to change 10 dynamic modes, long press for 2s to adjust 10 levels speed. Short press "Color/Brightness" to change 24 static RGB colors, long press for 1-6s to adjust 256 levels brightness...
(0)Model:CONSC-RF163
DC12-24V Universal LED Built-in 24 Patterns Wireless Outdoor Waterproof Controller with 17Keys RF Remote For RGB LED Strips Lights or Modules
- Working temperature: -20-60℃
- Power supply voltage: DC12-24V
- Output current: <4A(each channel)
- Output power:: 12V<144W, 24V<288W
Overview: RF controller adopts the advanced micro control unit, with 433MHz wireless signal to do the controlling. It is used for controlling a variety of lamp whose source of light is LED. For instance, point source of light, flexible light strip, wall washer lamp, glass curtain wall light and so on. It has many advantages such as low price, easy connection, simplicity to use and others, etc....
(0)Model:M3-W
Outdoor Waterproof IP67 RGB LED Controller With RF Remote
- Voltage: DC12-24V
- Current: Max 6A
- Remote Control: 433MHz
- IP Grade: IP67
Use this RGB controller for your outdoor lighting, RF wireless remote control RGB color changing LED lights, with IP67 protection grade, water-resistance. You can put it outside, and use it to control your RGB led strip lights , RGB led module string lights , etc. It comes with a RF remote, easy operation. DC12V/DC24V input, max current 6A, max power 72W for 12 volt lights, 144W for...
(0)Model:RF163
RF163 DC12V-24V 3 Channel Wireless IP65 Waterproof Controller, Low Voltage RGB Controller
- Voltage:DC12-24V
- WT: -20-60℃
- Output: 3 channels
- Connection Method:Common
- Waterproof Rating:IP65
The controller uses an advanced computer control chip and is controlled by a 433MHz wireless signal. It is used to control various lamps with LED as the light source, such as point light source, soft light bar, wall washer, glass curtain wall lamp, etc.; Convenient wiring, easy to use, easy to operate and other advantages; according to the actual needs of customers can achieve gradual, gradual...
(0)Model:T3-5A
DC12V-24V CV Receiving controller T3-5A
- Input voltage: DC12V-24V
- current load: Max 15A
- Output power: 180W/360W
- Work temp: -30℃~ 55℃
- Control button: 8 touch button
- size: L211×W40×H30mm
T3-5A CV Receiving controller Input voltage: DC12V-DC24V Max current load : 5A×3CH Max 15A Max output power : 180W/360W(12V/24V) Control button: 8 touch button Compatible remote control: workable with T3, T3M, T3X remote control Working temperature: -30℃～55℃ Dimension: L211×W40×H30mm Package size : L215×W42×H32mm Weight (G.W.) : 180g ...
(0)Model:BC-350RF
DC12V-DC24V Constant Voltage RGB Controller BC-350RF
- Input voltage: DC12V-24V
- Scale Level:4096 level X3
- Remote Distance: 30m
- Output Current:6A/3CH
- Output power:220W(12V)/440W(24V)
- size:L176×W46×H30(mm)
It is a universal high-performance power controller for entire color changing which adopted PWM (Pulse-Width-Modulation) controlling technology. Controls all common anode 4-pin 3-loop full color LED lights such as: RGB full color LED module, LED strip, LED SMD tape and so on. It can be controlled by the remote within the effective area no matter the direction and obstacles. Feature...
(0)Model:LT-3600
LT-3600,RGB Controller, High-end RGB Multi-Function LED Controller for DC12V 24V LED Strips, Warranty 5 Years
- voltage: DC12V~DC24V
- Max current load: 18A
- power: 216W/432W
- Function Mode: 16 modes
- working temp.: -30℃~55℃
- size: L211×W40×H30(mm)
- Warranty: 5 years
- Weight: 200g
LT-3600 is a multi-functional RGB LED controller, adopt advanced PWM( Pulse-Width Modulation) control technique, built-in 16 modes. Smooth changing effect, without flicker; PC engineering plastic shell, exquisite appearance; The controller has 8 keys, which are used for choosing ON/OFF,PAUSE,MODE+/-, SPEED+/-. It can adapt to DC5-24V input, suitable for most conventional RGB LED products,...
(0)Model:LT-3600RF
LT-3600RF, 6A*3CH, LED Light Fittings, RGB Controller for 12 volt led light strips, 5 Warranty
- Input voltage: DC12~24V
- Max current load: 18A
- power: 216W/432W
- Remote Distance: 100m
- size: L211×W40×H30
- Lifespan(hours): 16 modes
- Warranty: 5 years
LT-3600RF LED controller is a universal RGB controller for entire color changing, which adopted the most advanced PWM (Pulse-Width Modulation) controlling technology at present. PC engineering plastic panel with T-Touch/soft-touch function button and exquisite appearance. Widely controlled for RGB full color LED module, LED strip, LED SMD tape and all resistance of the current limit LED lighting...
(0)Model:T3-CV
Receiving controller T3-CV
- Input voltage: DC5~24V
- Max current load: Max 18A
- output power: 90~432W
- Working tem: -30℃～55℃
- size: L175×W44×H30(mm)
- Weight (G.W.): 150g
T3 is the 2.4 GHZ RF wireless synchronization RGB controller which adopts multiple global initiate technology. The control system consists of two parts, The RF remote control and receiver; realize the signal synchronization on Unlimited touch wheel for color selection, unique LED state light for sync change indicated, user can simply know the LED working state from distance by checking the remote...
(0)Model:V3-K (V4-K)
V3-K 3CH*4A DC12-24V Constant Voltage 4 Knob RGB Controller
- Input Voltage: DC12-24V
- Output Voltage: 3*DC12-24V
- Input Current:12.5A
- Output Power:3X(48-96)W
- Waterproof Rating:IP20
- Output Type:Constant voltage
This V3-K controller has been upgraded to new version V4-K . For customers who select V3-K, we will send V4-K instead. Features ● RGB constant voltage LED RF controller, can also be used as a RGB RF remote. ● 4 knob dimming, digital numeric display and easy key operation. ● Match with RF 2.4G single zone or multiple zone RGB remote control optional. ● 256 levels 0-100% dimming...
(0)Model:BC-390RF
DC12V-24V Constant Voltage RGB Controller BC-390RF
- Input voltage: DC12V-24V
- Scale Level:4096 level X3
- size:L165xW56xH30mm
- Max Current load: 8A/CHx3
LED controller is a universal RGB controller for entire color changing, which adopted high-performance single-chip and the most advanced PWM (Pulse-Width-Modulation) controlling technology. It can control all 4-pin 3-loop LED RGB full-color lights such as LED module, LED strip, LED SMD tape, and high power LED projector, wall-washer, flood light, underwater lamp etc. Adopt Flame retardant PC ABS...
(0)Model:BC-361-4A
DC12V-DC24V Constant Voltage RGB Controller BC-361-4A
- Input voltage: DC12V-24V
- size:L125xW45xH36(mm)
- Remote Distance: 30m
- Max current load:4A/CH×3
- Driving LEDs:144W (12V)/288W (24V)
- Scale levels: 4096 scale/CH×3
This Constant Voltage Multi-function RGB Controller is a universal RGB controller for entire color changing, which adopted high-performance microchip and the most advanced PWM (Pulse-Width Modulation) controlling technology at present. It can control all 4-pin 3-loop LED RGB full-color lights. This series with RF remote controller and it is available only within the valid range. Feature...
(0)Model:CONRGB-RF-13
DC5/12/24V Max 15A 5A3CH, Home control High Quality Warranty 5 years LTECH Constant LED RGB Wireless RF Remote Controller For Led Strips - Replaced by LT-3600RF
- Brand: LETCH
- Operating Voltage(v): 9~24
- Operating current(a): 18
- Control Type: Touch / IR
- Applied to: RGB Lights
- Frequency: 2.4GHz
- Output Channel: 3
- Shell: Plastic
This Ltech RGB controller has been discontinued, it's replaced by LT-3600RF now. If you still order this model, we will send you LT-3600RF. This is DC9~24V 7-keys 15A 3channel touch infrared controller adopts the advanced micro-control unit,it is used for controlling a variety of lamp. It has power-fail memory, synchronized indicator light show and other functions. At the same...
(0)Model:M7+M4-5A
RGB Controller M7+M4-5A
- Input voltage: DC12-24V
- Current Load: Max 20A
- Output Power: 480W
- Work temp: -30℃~ 55℃
Extended new series products are based on the Mini series controllers, increase RGBW 4CH control, workable for dimming, Color temperature, RGB and RGBW. And the output power of receiver is higher. 4096 / road grey scale (most of them is 256 in the market), high grayscale performance is more outstanding, the light is more gentle, dynamic changing modes become more rich and colorful.With innovative...
(0)Model:F4-CC
12~48Vdc Wireless receiver F4-CC
- Input voltage: DC12V-48V
- Output Voltage: 3~46Vdc
- Output power: Max 193.2W
- Output Current: 1050mA×4CH
- size: L178×W48×H33(mm)
F4-CC CC Receiver Input voltage 12~48Vdc Output Voltage 3~46Vdc Output Current CC 350/700/1050mA×4CH Output Power -1.05W~48.3W×4CH Max 193.2W Working Temperature -30℃~55℃ Package size L178×W48×H33(mm) Weight (G.W.) 165g LED Dimmer F4-CC
(0)Model:F4-3A
DC5-24V Wireless receiver F4-3A
- Input voltage: DC5-24V
- Max current load: Max12A
- Output power: 288W
- Remote Distance: 50m
- size: L125×W33×H20mm
F4-3A Receiving controller Working Frequency 2.4GHz Input voltage: DC5V~DC24V Max current load : 3A x4CH Max 12A Max output power: 60W/144W/288W(5V/12V/24V) Remote Distance: 50m (line of sight) Working temperature: -30℃～55℃ Dimensions : L125×W33×H20mm Package size: L127×W35×H24mm Weight (G.W.): 60g LED Dimmer F4-3A
(0)Model:F4-5A
DC5-24V Wireless receiver F4-5A
- Input voltage: DC5-24V
- Frequency: RF 2.4GHz
- Max current load: Max 20A
- Remote Distance: 50m
- size: L175×W44×H30mm
- output power: 480W
Dimming, CT, RGB, RGBW LED lights can be controlled. Compatible with F series remote. Compatible with EX series touch panel. Compatible with WiFi-106 gateway. LED Dimmer F4-3A
(0)Model:M3+M4-5A
RGB Controller M3+M4-5A
- Voltage: DC12-24V
- Frequency: 433.92 MHz
- Remote Distance: 40-50m
- Working Temp: -30 ~55 ℃
M series LED controller is compatible with 8 kinds remotes of different function (patent technology) . which means using one receiver could experience single color/CT dimming, RGB/RGBW adjustment to meet customers' different lighting requirements. With the RF remote, speed/brightness adjustment. customise color and lighting changing modes selection could all be achieved CV...
(0)Model:R4-5A
DC5-24V R4-5A CV Zone Receiving controller
- voltage: DC5V-24V
- Frequency: RF 2.4GHz
- Remote Distance: 50M
- Work temp: -30℃~ 55℃
- output powe: 480W
- size: L175×W44×H30
Working Frequency: 2.4GHz Input voltage: DC5V~DC24V Max current load: 5A x4CH Max 20A Max output power :100W/240W/480W(5V/12V/24V) Remote Distance :50m (Distance of cross-eyed) Working temperature: -30℃～55℃ Dimensions :L175×W44×H30mm Package size :L178×W48×H33mm Weight (G.W.) :150g Products Specifications R4-5A
(0)Model:CONRGB-RF-04
DC5-12/24V Max 12A 4A3CH, LED RGB MINI Wireless RF Infrared Controller For RGB LED Light Strips or Modules
- Operating Voltage(v):12/24
- Operating current(a):12
- Control Type: IR
- Applied to: RGB Lights
- Waterproof Rating: IP33
- Output Channel: 3
Our Mini LED controller kit is with such a purpose. This time, we combined the mini controller with RF remote, providing a more convenient way to realize the best visual effect of your RGB strip. About the Mini Controller: this mini controller is tiny in its size(easy to be concealed) but great in its function. Through connecting with this controller, it will be able to control the LED RGB strips...
