Addressable Flex LED Pixel Panel

What is LED pixel display panel?

Flxible LED pixel display panel has a built-in protection resistor decoration, adopts a low-voltage drive introverted protection circuit design, and assembles multiple pixel matrices on a rigid printed PCB, which provides more space than neopixel ring; single LED addressable, and data transmission is through a specific timing protocol of the data line, matching the SPI/Arduino/Raspberrypi microcontroller to control the LED to display a variety of animations, digitals and other color chasing lighting effects, suitable for advertising sign lighting.

How to wire the LED pixel display panel?

LED pixel display panel is a 4-channel(+5V/DIN/GND/DOUT) addressable LED pixel panel,+5V interface connects to 5V power supply pin; DIN interface controls data signal input and external controller; GND interface connects signal ground and power ground; DOUT interface controls data signal output, connected to the DIN of the next panel. For a single LED pixel panel, we provide the extra JST connector, which can be connected to a Dream color addressable LED controller to control its lighting mode and color. When in use please note, it can be bent around a rigid or semi-rigid shape, but it cannot tolerate continuous and repeated bending.
