CV LED Dimmer
18 productsBinColor PWM Constant Voltage (CV) LED Dimmers are designed for DC12-24V single-color constant voltage LED strip lights and compatible constant voltage LED lighting fixtures. They use PWM dimming technology to adjust LED brightness smoothly while maintaining a constant voltage supply suitable for the connected lighting products.
Available in various control configurations, including wireless remote control, push-button dimming, rotary knob adjustment, and touch-panel control, these LED strip dimmers offer flexible solutions for different residential and commercial lighting installations.
Depending on the model, you can choose from single-channel or multi-channel dimming options, with synchronized lighting control or independent zone adjustment. They are ideal for LED strip lighting in bedrooms, living rooms, kitchens, cabinets, display areas, and other applications requiring convenient manual brightness control.
Choose a CV dimmer according to your LED lighting voltage, total load current, and required number of control channels.
DC5-24V LED Dimmer BC-311RF - Wireless RF Control & 4096 Grey Scales
BinColor R3M 3-Channel Wireless Remote LED Strip Light Receiver
BinColor R4-2.4G Wireless 4-Channel LED Light Strip Receiver For PX Panel Remotes
FAQ About CV LED Dimmers
Direct answers to technical sizing, wiring, and integration questions on constant voltage pulse-width modulation dimmers from our engineering desk.
A CV LED dimmer controls light output by rapidly switching DC power on and off at a fixed voltage, typically between 500 Hz and 2000 Hz. Because the voltage amplitude stays flat (such as a steady 12V or 24V), the LEDs never drop below their forward conduction threshold. Brightness changes purely through duty cycle—the ratio of on-time to off-time within each cycle. This protects constant voltage LED strip lights from the color temperature shifting and uneven diode dropouts common to variable-voltage analog dimming.
Most units top out at 24V, but a CV LED dimmer like the BC-320-6A rotary dimmer accepts DC12V straight through DC48V on its terminal block. Long commercial linear runs often use 48V strips to push past 15 m from a single feed point without noticeable line loss. If you connect a 48V power source to a standard 12V-24V rated dimmer, the internal switching MOSFETs will exceed their breakdown rating and short-circuit immediately. Check the stamped input voltage on the casing before powering up.
To size a CV LED dimmer properly, multiply your DC power supply voltage by the channel amp rating, then apply an 80% continuous-load safety margin. On a 12V system with a 10A channel like our BC-321-10A, the nominal limit is 120W, giving a real-world working ceiling of 96W. Move that same 10A dimmer to a 24V system and your headroom doubles: 24V multiplied by 10A gives 240W, safe for continuous 192W operation. Always calculate total strip wattage from measured draw per meter rather than nominal packaging labels.
You wire a CV LED dimmer strictly on the secondary DC side between your non-dimmable driver and the LED strip lights. Take the DC positive and negative from your power supply into the DC input terminals on the dimmer, matching polarity exactly. Then wire the strip's common anode (+V) and channel cathode (-V) leads to the dimmer output screw terminals. Never wire a low-voltage CV dimmer into high-voltage 110V or 230V AC mains lines, as doing so burns out the logic board instantly.
Yes, our dual-protocol CV LED dimmer models like the P1X and P5X touch panels accept standard DMX512 digital bus inputs alongside local 2.4G wireless control. In commercial jobs where an architectural control desk needs to dim low-voltage accent lines, standard analog dimmers fail to respond.
Do not parallel two dimmer outputs together; instead, feed the output of your CV LED dimmer into multi-channel signal power amplifiers. The amplifier reads the high-frequency PWM switching signal from the primary dimmer and mirrors the exact duty cycle across extra 12V or 24V output channels connected to secondary power supplies. This lets you synchronize 50 m to 100 m of architectural cove lighting from one wall knob or remote without burning out the primary controller's copper traces.
A multi-zone CV LED dimmer set, such as our T6 and R4M platform, allows a single multi-channel RF sender to address up to four or eight independent zones. Each remote receiver syncs via a 2.4 GHz radio link that penetrates standard drywall up to 30 m away without direct line-of-sight. You can adjust your under-cabinet task strip on Zone 1, ceiling cove tape on Zone 2, and toe-kick accents on Zone 3 independently, or press the master button to dim the entire room together.
