LED Touch Panel Controller

17 products

SuperLightingLED offers the LeyNew LED Touch Panel Controller Series for users and projects that prefer convenient in-wall touch panel control for residential and commercial indoor lighting.

Designed primarily for controlling low-voltage DC12V and DC24V flexible LED strips, including single-color, CCT tunable white, and RGB lighting, as well as compatible 0-10V dimmable lighting systems, these wired wall-mounted touch panels provide an intuitive and elegant way to manage everyday lighting.

Featuring sleek tempered glass panels and responsive capacitive touch technology, LeyNew controllers combine practical lighting functions with a modern wall switch appearance.

Available in European-style and American-style panel dimensions, the series offers installation options for different interior environments, wall boxes, and regional switch preferences.

Whether controlling bedroom LED strip lighting, living room accent lights, kitchen cabinet lighting, or commercial indoor illumination, these touch panel controllers provide convenient local operation without relying on a smartphone app or wireless remote.

What Are In-Wall LED Touch Panel Controllers?

In-wall LED touch panel controllers are wired lighting control devices designed to be integrated into wall switch positions, providing direct touch operation of connected LED lighting.

Unlike handheld remote controls or app-based wireless controllers, these panels offer a fixed and easily accessible control point for everyday lighting adjustments.

Most models feature tempered glass surfaces and capacitive touch interfaces, allowing users to switch lights on or off, adjust brightness, select colors, or change color temperature by touching the corresponding control areas.

Depending on the model, the panel can function as a low-voltage PWM LED controller or a dedicated 0-10V lighting dimmer. This makes the LeyNew touch panel series suitable for both decorative LED strip lighting and compatible architectural lighting installations.

For projects requiring more advanced lighting control capabilities, explore our BinColor Touch Panel Controller Series, which expands beyond conventional wired touch control to offer multi-zone DMX512 integration and 2.4GHz RF wireless control for both constant-voltage (CV) LED strips and constant-current (CC) lighting fixtures.

How to Connect and Wire LeyNew LED Touch Panel Controllers

The connection method depends on the lighting technology controlled by the selected touch panel.

For low-voltage DC12V/24V LED strip applications, first connect a compatible constant-voltage power supply to the controller's DC power input. Then connect the LED strip's common positive terminal to the controller's V+ output and the corresponding negative channel wires to the designated output terminals.

TM08U RGB LED Strip Light Panel Wiring Diagram

For single-color strips, use the single output channel; for CCT strips, connect the warm-white and cool-white channels; for RGB strips, connect the red, green, and blue channels respectively. Once powered, the wall panel can directly control the connected LED strip through its capacitive touch interface.

For 0-10V dimming applications, use a dedicated model such as the TM016. Connect the panel's AC L and N input terminals to the specified AC90-240V power supply. Connect its switched AC output L and N to the compatible 0-10V dimmable driver's mains input, and connect the panel's V+ and V- terminals to the driver's corresponding 0-10V dimming signal inputs. The dimmable driver then supplies the operating power to the connected LED fixture while responding to the panel's analog dimming signal.

Frequently Asked Questions About LED Touch Panel Controllers

Direct technical answers on wiring, wall box sizing, protocol compatibility, and load limits for our glass touch panel controllers.

An LED touch panel controller mounts directly into a wall junction box to replace handheld remotes and traditional toggle switches with a capacitive glass interface. Instead of switching AC line power, it sits between your 12V or 24V DC power supply and your low-voltage LED strip lights. It regulates brightness, color temperature, or RGB color mixing using pulse-width modulation (PWM) or dedicated control protocols like 0-10V. Because it wires directly to your DC circuit, you eliminate dead remote batteries and signal dropouts across the room.

A standard 86-type touch panel controller is built for square 86 mm × 86 mm European or Asian back-boxes with 60 mm screw spacing, so it will not bolt directly into a rectangular North American single-gang electrical box. Standard US single-gang mud rings feature 83.3 mm vertical screw hole centers. To install an 86-type panel in a US wall, you must either frame in an 86 mm square flush-mount back box, use a surface-mount 86 enclosure, or fit a custom adapter plate onto your existing single-gang junction ring.

No, a low-voltage LED touch panel controller cannot take 120V AC line power directly, and connecting it to mains AC voltage will burn out the circuit board instantly. You must install a constant-voltage AC-to-DC power supply before the wall panel. Feed 120V AC into the driver, and run the secondary 12V or 24V DC output directly to the panel's power input terminals.

An erratic or frozen LED touch controller is almost always caused by an interrupted capacitive auto-calibration cycle during initial boot. High-precision capacitive touch chips scan baseline surface capacitance the exact second DC power is switched on. If your fingers touch the glass faceplate or if the glass front is unclipped while powering up, the sensor calibrates to the wrong capacitance baseline. Cut the DC power for 10 seconds, ensure the glass is firmly seated, and restore power without touching the front panel.

Yes, pairing a specialized touch panel controller like our TM016 with your commercial LED panel lighting lets you control 0-10V dimmable drivers directly from a glass wall faceplate. Standard constant-voltage dimmers output 12V-24V PWM, which is meant for flexible tape, not commercial recessed troffers. The TM016 delivers an active 0-10V low-voltage sink/source control signal over a two-conductor control pair run straight to the ballast or fixture driver, providing smooth 0% to 100% dimming without line-voltage hum.

Overloading an LED touch panel controller past its rated limit—typically 4A per channel or 8A combined load—causes the internal MOSFET switching transistors to overheat, trigger thermal shutdown, or melt. For example, 15 meters of high-density 24V RGBW tape drawing 240W exceeds an 8A panel's safe 192W threshold. Instead of overloading the wall panel, keep the panel as a low-load control head and feed its output into a power repeater amplifier. That expands your circuit capacity cleanly without overloading the wall station.
