Single Zone Series
8 productsIdeal for Low-Voltage Residential & Commercial LED Strip Lighting
The BinColor Single-Zone Touch Panel Controller Series features low-voltage, DC-powered in-wall touch panels designed for direct control of DC12–24V constant voltage LED strip lights. Covering single-color dimmable (DIM), tunable white (CCT), RGB, and RGBW lighting, these LED wall panel controllers provide intuitive touch operation such as on/off control, color and color temperature adjustment, dynamic lighting modes, preset lighting scenes, and delayed shutoff, with selected models also offering a matching wireless handheld remote for added convenience.
- - Single-Color DIM: Up to 4 single-color output channels for brightness control.
- - CCT Tunable White: Up to 2 CCT output channels for warm white and cool white adjustment.
- - RGB: 1 RGB LED strip output for full-color lighting control.
- - RGBW: 1 RGBW LED strip output for full-color control with an additional dedicated white channel.
These direct-wired LED strip touch panel controllers are ideal for traditional residential and commercial lighting installations where users prefer convenient wall-mounted controls without complicated wireless receiver wiring or smart home network configuration. They are suitable for bedrooms, living rooms, kitchens, under-cabinet lighting, display cabinets, retail spaces, offices, and decorative accent lighting.
FAQ About Single Zone Series Touch Panel Controllers
Direct answers to technical questions about wiring, voltage limits, and mounting BinColor single-zone low-voltage wall controllers.
Each BinColor single-zone touch panel controller for LED strip lights supports up to 4A per output channel with a total limit of 16A across all channels. On a 12V circuit, a 4-channel model like the P1 dimmer or P4 RGBW panel handles up to 192W (48W per channel). On a 24V circuit, the maximum load doubles to 384W (96W per channel). If your connected LED tape light draws more than 16A total, you must split the run and use a power repeater rather than pulling additional current through the panel's internal PCB traces.
A standard US single-gang rectangular junction box will not fit this touch panel controller for LED strip lights without an adapter plate or an 86-type mud ring. The BinColor P series uses an 86 mm by 86 mm square glass faceplate designed around an 86-type square backbox with 60 mm screw mounting centers. For North American job sites, installers either frame in a European-style 86-box or mount a standard single-gang box horizontally with an aftermarket square-to-rectangular wall plate adapter to cover the opening neatly.
You must install an external power repeater when your LED strip lights draw more than the panel's 16A maximum rating. Wire the output terminals from your P-series wall panel into the signal input terminals of a RGBW signal amplifier, and feed the amplifier from a separate 12V or 24V power supply. The amplifier reads the PWM dimming signal from the wall glass and mirrors it synchronously across the secondary strip run without routing extra current through the wall controller.
The BinColor P2 touch panel controller is built specifically for tunable white LED strip lights with two independent output channels for warm white and cool white chips. The glass touch wheel allows you to sweep color temperature smoothly between 2700K and 6500K while dedicated touch keys raise and lower master brightness. If you also need mobile handheld control from across the room, choose the P2+T2 bundle, which pairs a 2.4GHz wireless handheld remote to the wall panel right out of the box.
Yes, selecting the bundled models (P1+T1, P2+T2, P3+T3, or P4+T4) lets you control your LED strip lights using the wall glass and a wireless handheld remote at the same time. The wall station houses a built-in 2.4GHz RF receiver. Adjusting brightness, color, or scene modes on the handheld remote updates the lighting instantly, and touching the glass wall interface overrides or fine-tunes the output with zero signal collision.
You can mount the controller up to 15 meters (50 feet) away on a 24V circuit, provided you calculate wire gauge correctly to keep line loss under 3%. On a 12V system, keep the distance between the wall controller and the start of your LED strip lights under 5 meters (16 feet) when using 18 AWG cable, because 12V draws twice the current of 24V for identical wattage. If you are planning an extensive installation across separate rooms, check our guide on choosing controllers to map run lengths against voltage rails.
Yes, you can connect up to four distinct single-color runs to the P1 touch panel controller for LED strip lights because it features four parallel negative output channels. All four channels share the same brightness commands from the touch slider, dimming your toe-kick, under-cabinet, and ceiling cove lighting in complete synchronization. Just verify that the combined electrical draw of all four runs stays within the panel's 16A total rating.
Every BinColor P-series touch panel controller for LED strip lights includes non-volatile power-loss memory that retains your operating state. When AC mains power drops out and later returns to your DC power supply, the touch panel automatically boots back up to the exact brightness level, color temperature, or static RGB hue that was active before the interruption, so you do not need to walk to the wall switch to re-adjust your lights.
