RF & Tuya WiFi LED Controllers
.jpg "3 Button 5 to 24VDC Tuya WiFi RGB CCT LED Controller VD5(WT)")
(0)Model:VD5(WT)
3 Button 5 to 24VDC Tuya WiFi RGB CCT LED Controller VD5(WT)
- Input Voltage: 5-24VDC
- Output voltage: 5-24VDC
- Output current: 5CH, 1A/CH
- Input signal: WiFi + RF 2.4GHz + 3 button
- Dimming level: 256 levels
- Size: W120 x L43 x H27mm
- Gross weight: 0.057kg
- Material: Gas-phase Silica Gel
VD5(WT) is a WiFi and RF 5 channel RGB CCT LED controller with 3 buttons that make it simple to operate the light modes, brightness, color temperature. Also, through the Tuya app, this LED lights controller has remote control capabilities for users to control the RGB color, color temperature, and brightness adjustments in addition to features like scene editing, timer operations, delayed on/off,...
.jpg "6 Buttons Tuya Wifi LED RGBW Controller with RF control M5(WT)")
(0)Model:M5(WT)
6 Buttons Tuya Wifi LED RGBW Controller with RF control M5(WT)
- Input Voltage: DC12V-24V
- Output current:5CH,3A/CH
- PWM Frequency: 2000Hz (default)
- Dimming Curve: Logarithmic
- Output Power:5×(36-72)W
- Size: L162 x W42 x H26mm
- Output voltage: 5×(12-24)VDC
- Input signal: WiFi + RF 2.4GHz
M5(WT) is a 6 buttons LED controller which perfects for RGB, RGBW or RGB CCT LED lights. Integrating with the tuya smart life app cloud-based access control, this compact controller supports users to control light switch, adjust brightness, color temperature and RGB color changes. It can be set with five different lighting types to provide you with a different visual experience. Compatible with...
(0)Model:WT1
Tuya APP + RF 2.4GHz WiFi CCT 2CH LED Controller WT1
- Input voltage: DC12-36V
- Output Voltage: 2*(12-36)V
- Output Current: 2CH,5A/CH
- Output Power: 2*(60-180)w
- Waterproof Rating: IP20
- Dimming Range: 0-100%
Features Used for control single color or color temperature LED strip. DC power socket input and 2 channel constant voltage output. Tuya APP cloud control, support on/off, color temperature and brightness adjust,delay turn on/off light, timer run, scene and music play function. Voice control, support amazon ECHO and TmallGenie smart sperker. Match with RF 2.4G remote control optional. User need...
(0)Model:TWZS1/T6E
TWZS1 WiFi Tuya Zigbee Smart Home Control Wall Panel
- Input Voltage: 100-240VAC
- Screen: 4inch/480x480
- Store: 1GB RAM/8GB ROM
- Wireless Protoco: WiFi Zigbee
- Product Size: 86*86*36mm
- Working Temperature: 0℃~+40℃
Skydance TWZS1 (T6E) is a smart home control panel with capacitive touch screen, compatible with WiFi, Zigbee wireless protocols and Tuya eco devices. It integrates Zigbee gateway function, the controller devices can be used without an external zigbee gateway. By scanning code and binding, the smart panel automatically synchronises the group, scenes, and functions of LED lights in the Tuya/Smart...
(0)Model:WT5
WT5 UL Certified 5-in-1 LED Strip Controller (Tuya WiFi + RF)
- Input voltage: DC12-24V
- Output Voltage: 5*DC12-24V
- Output Current: 5CH, 3A/CH
- Output Power: 5 x (36-72)W
- Waterproof Rating: IP20
- Dimming Range: 0-100%
- UL Certified: Yes
WiFi & RF 5-in-1 LED Strip Light Controller WT5 UL Certified ● 5 in 1 function, used for control RGB, RGBW, RGB+CCT, color temperature or single color LED strip. ● DC power socket input and 5 channel constant voltage output. ● Tuya APP cloud control, support on/off, RGB color, color temperature and brightness adjust, delay turn on/off light, timer run, scene and music play function. ●...
(0)Model:WT-SPI
5-24VDC WiFi Tuya App & RF Remote 2CH/4CH RGB/RGBW SPI LED Controller WT-SPI
- Input voltage: 5-24VDC
- Input signal: Tuya APP + RF
- Output Signal: SPI(TTL)
- Pixel Dots: MAX.1000
- Output Channel: (DAT+CLK)x2
- Output Channel: DATx4
This is a Smart SPI Controller to control DC5V/DC12V/DC24V Addressable LED Strip Lights, available with Tuya smartphone APP control and R9 RF remote control. It is compatible with single-signal or dual-signal addressable RGB and RGBW IC chips. Output 2 channels dream color lighting, max control 1000 pixels. If you use it to control a 3-pin single-wire digital LED strip, the...
(0)Model:PB-12A-2(WT)
2CH 12W Smart Constant Current 150-450mA LED Driver (WiFi + RF) PB-12A-2(WT)
- Output Current: 150-450mA
- Output Power:Max. 12W
- Input Voltage: AC100-240V
- Output Channel: 2
- Efficiency: 80%
- Frequency Range:50/60Hz
CC led smart AC-DC driver PB-12A-2(WT) is the upgrade version of PB-12A-2. Tuya smart APP cloud control, support on/off, color temperature and brightness adjust, delay turn on/off light, timer run, scene edit and music play function. Support Voice control, can connect to Amazon Alexa, Google Assistant, Tmall Genie and Xiaodu voice assistant. Features ● Dimming interface: WiFi...
.jpg "9-45VDC 1CH*(100-450mA) 12W Zigbee Constant Current Dimable LED Driver PB-12A-L(WZS)")
(0)Model:PB-12A-L(WZS)
9-45VDC 1CH*(100-450mA) 12W Zigbee Constant Current Dimable LED Driver PB-12A-L(WZS)
- Input Voltage: 100~240VAC
- Output Voltage: 9-45VDC
- Alternating Current: 0.3A/0.15A
- Output Current: 100~450mA
- Output Power: Max.12W
- Max Output Voltage: 48VDC
- Dimming Range: 0~100％
- PWM Frequency: 4000Hz
Zigbee 3.0 or WiFi Constant Current LED Driver for smart lighting applications. Unlike traditional LED drivers, smart LED drivers have integrated smart features - wireless connectivity, allowing for remote control and management of the LED lights. This Smart LED Driver uses Zigbee 3.0 wireless communication technology and can be controlled by a smartphone or other compatible devices. It also...
+RC1-3-Button-Tuya-IR-&-WiFi-Controlled-Light-Dimmer.jpg "F1-D(WT)+RC1 3 Button Tuya IR & WiFi Controlled Light Dimmer")
(0)Model:F1-D(WT)+RC1
F1-D(WT)+RC1 3 Button Tuya IR & WiFi Controlled Light Dimmer
- Input Voltage: 5-24VDC
- Output voltage: 5-24VDC
- Input signal: Tuya APP + IR + 3 button
- Output current: Max. 5A
- Control distance: 10m(Barrier-free space)
- Dimming gray scale: 4096 level
- Dimming range: 0-100%
- Gross weight: 0.086kg
F1-D(WT)+RC1 is a set including an infrared and WiFi light dimmer controller and an IR remote for single color LED strips. This WiFi & infrared LED remote control can connect to up to 5 meters of RGB LED strip with 5A output. Our IR & WiFi LED strip light controller not only supports light control and brightness adjustment through button, but also allows Tuya app cloud control to realize...
+RC1-1CH-Tuya-WiFi-&-Infrared-Remote-Control-Light-Dimmer.jpg "F1-M(WT)+RC1 1CH Tuya WiFi & Infrared Remote Control Light Dimmer")
(0)Model:F1-M(WT)+RC1
F1-M(WT)+RC1 1CH Tuya WiFi & Infrared Remote Control Light Dimmer
- Input Voltage: 5-24VDC
- Output voltage: 5-24VDC
- Input signal: WiFi + IR + key
- Output current: Max. 5A
- Dimming gray scale: 4096 level
- Dimming range: 10-100%
- Size: L110x W57x H32mm
- Gross weight: 0.090kg
F1-M(WT)+RC1 is a WiFi & Infrared remote LED dimmer controller with an IR remote for single color LED lights. Offering constant voltage operation with a 5A output, this WiFi & infrared led controller can connect to up to 5 meters of RGB LED strip. Through Tuya app cloud control, this smart WiFi & IR remote control allows for functions like scene editing, timer settings, brightness...
.jpg "0/1-10V WiFi + RF + Push Dimmer L1(WT)")
(0)Model:L1(WT)
0/1-10V WiFi + RF + Push Dimmer L1(WT)
- Input Voltage: AC100-240V
- Output signal: 0/1-10V (20mA)
- Dimming level: 256 levels
- Dimming range: 0 -100%
- Warranty: 5 years
- IP rating: IP20
Features ● WiFi + RF + AC push 0/1-10V dimmer, 1 channel output. ● Output 1 channel 0/1-10V signal, connect with 0/1-10V dimmable driver. ● Tuya APP cloud control, support on/off, brightness adjust, delay turn on/off light, timer run, scene function. ● Voice control, support amazon ECHO and TmallGenie smart speaker. ● 0-10V or 1-10V output selectable by DIP switch. ● 256 levels 0-100%...
(0)Model:VD1-WT
VD1 (WT) WiFi Tuya And RF Push Button Dimmer Switch 5A
- Input Voltage: DC5-24V
- Output Current: Max 5A
- Output Power: 25W/60W/120W
- Control Mode: 3 buttons+RF+APP
- Dimming Curve: Logarithmic
- PWM Frequency: 2KHz
- Size: L73xW35xH14mm
- Warranty: 5 years
This VD1(WT) push button dimmer switch combines push button control with wireless remote control, you can dim the white LED strip lights in a variety of ways. The led dimmer body comes with three buttons, with functions 1) Turn on or off light; 2) Brightness +; 3) Brightness -. DC input and output interfaces for easy wiring. 10 light brightness levels, long press the brightness+/- button...
(0)Model:WT1+R11
12-36VDC 2CH*5A WiFi Tuya APP & RF Remote LED Dimmer Set WT1+R11
- Input voltage: 12-36VDC
- Output current: 2CH,5A/CH
- PWM Frequency: 2000Hz
- Output power: 2x(60-180W)
- Dimming signal: Tuya APP+RF+Push Dim
- Remote distance: 30m
This is a LED Dimmer Kit, includes a LED controller and a RF remote. WT1+R11 is a smart lighting control solution from Skydance that offers convenient and flexible control over single-color LED strip lights. The WT1 is a WiFi & RF LED Dimmer Controller that can be operated through the Tuya app, voice commands, or the R11 RF remote control, to provide constant voltage output for LED...
.jpg "3-24VDC 1CH*(350-700mA) 12W Zigbee Dimmable Constant Current LED Driver PB-12A-H(WZS)")
(0)Model:PB-12A-H(WZS)
3-24VDC 1CH*(350-700mA) 12W Zigbee Dimmable Constant Current LED Driver PB-12A-H(WZS)
- Input Voltage: 100~240VAC
- Output Voltage: 3-24VDC
- Alternating Current: 0.3A/0.15A
- Output Current: 350~700mA
- Output Power: Max.12W
- Max Output Voltage: 33VDC
- Dimming Range: 0~100％
- PWM Frequency: 4000Hz
This Intelligent Dimmable Constant Current LED Driver integrates with a Zigbee 3.0 or WiFi network, to dim LED lights through a smart device - a smartphone, a smart speaker, a remote control, or a smart home lighting center. The use of the Zigbee protocol ensures low-power, reliable wireless communication between the LED lights and the controlling device, offering a convenient and versatile...
 100-240VAC 01-10V Tuya WiFi & RF Tunable White Push LED Dimmer.jpg "L2(WT) 100-240VAC 0/1-10V Tuya WiFi & RF Tunable White Push LED Dimmer")
(0)Model:L2(WT)
L2(WT) 100-240VAC 0/1-10V Tuya WiFi & RF Tunable White Push LED Dimmer
- Input Voltage: AC100-240V
- Output signal: 2 x 0/1-10V
- Output current: -10-40°C
- RF: 20mA/CH; AC: Max 3A
- Input signal: Tuya APP+RF+Push Dim
- Dimming range: 0 -100%
- RF Control distance: 30m
- Warranty: 5 years
Product Feature ● WiFi + RF + AC push 0/1-10V dimmer, output 2 channel 0/1-10V signal. ● High voltage AC input, High voltage AC relay output. ● Dimming or dual color control selectable by DIP switch. ● For dual color control, the two channel output can be set as warm white and cool white respectively, or one for brightness adjust and the other for color temperature adjust. ● 0-10V or...
(0)Model:V5-L(WT)
V5-L(WT) WiFi & RF Tuya Push Dimming 5 in1 LED Controller Amazon ECHO Voice Control
- Input voltage: 12-48VDC
- Output voltage: 5*DC12-48V
- Input current: 30.5A
- Output type: Constant voltage
- Input signal: Tuya APP + RF 2.4GHz + Push Dim
- Control distance: 30m
- Dimming range: 0-100%
- Operation temperature: -30~+55"C
WiFi & RF 5 in1 LED Controller, Tuya APP cloud control /Voice control /5 Channels output /DC12-48V input /Four PWM frequency (500/2000/8000/16000Hz) /Push Dim. ● 5 in 1 function, used for control RGB, RGBW, RGB+CCT, color temperature, or single color LED strip. ● DC12-48V input, 5-channel constant voltage output. ● Tuya APP cloud control, support on/off, RGB color, color...
(0)Model:F3-D(WT)
3 Buttons IR Tuya RGB LED Controller F3-D(WT)
- Input Voltage: DC5-24V
- Output Current: 3CH, 1.5A/CH
- Output Power: 22.5W/54W/108W
- Control Mode: Tuya APP+IR+3 button
- Dimming Curve: Logarithmic
- PWM Frequency: 2KHz
- Size: W130 x L60 x H26mm
- Warranty: 5 years
It appears you're describing a WiFi and infrared remote-controlled RGB LED controller with specific features and capabilities. Here's a breakdown of the key features and functionalities: Channels and Voltage: This LED RGB controller has three channels, which means it can control RGB LED strips with separate control of red, green, and blue channels. It operates at a constant voltage. Tuya...
+RC3-WiFi-&-IR-Dimmable-RGB-LED-Controller-with-IR-Remote.jpg "F3-D(WT)+RC3 WiFi & IR Dimmable RGB LED Controller with IR Remote")
(0)Model:F3-D(WT)+RC3
F3-D(WT)+RC3 WiFi & IR Dimmable RGB LED Controller with IR Remote
- Input Voltage: 5-24VDC
- Output voltage: 5-24VDC
- Input signal: WiFi + IR + 3 button
- Output current: 3CH, 1.5A/CH
- Dimming gray scale: 4096 level
- Dimming range: 0-100%
- Size: L110 x W57 x H28mm
- Gross weight: 0.093kg
With the ability to connect with RGB LED strips up to 5 meters long, the F3-D(WT)+RC3 is a WiFi and Infrared Remote RGB LED Controller with an IR remote that offers three channels of constant voltage operation with a 1.5A per channel output. Three buttons on this RGB LED lighting controller provide for easy on/off control, mode selection, and color adjustment. The 4096 levels of dimming offered...
+RC3-3CH-LED-RGB-WiFi-IR-Controller-with-Infrared-Remote.jpg "F3-M(WT)+RC3 3CH LED RGB WiFi IR Controller with Infrared Remote")
(0)Model:F3-M(WT)+RC3
F3-M(WT)+RC3 3CH LED RGB WiFi IR Controller with Infrared Remote
- Input Voltage: 5-24VDC
- Output voltage: 5-24VDC
- Input signal: WiFi + IR + key
- Output current: 3CH, 1.5A/CH
- Dimming gray scale: 4096 level
- Dimming range: 10-100%
- Dimming curve: Logarithmic
- Gross weight: 0.090kg
F3-M(WT)+RC3 is set containing a 3 channel LED RGB dimmer controller and an IR remote support users to remote control RGB LED strips through Tuya app or IR remote. Though Tuya app cloud control, this RGB LED strip controller supports users to control the light with the function including the light on/off control, color and brightness adjustment, delay turn on/off setting, even the scene editing...
(0)Model:VD3(WT)
Mini 3 Button Tuya RF RGB LED Controller VD3(WT)
- Input Voltage: 5-24VDC
- Output Current: 3CH, 1.5A/CH
- Output Power: 22.5W/54W/108W
- Control Mode: Tuya APP+RF 2.4GHz+3 button
- PWM Frequency: 2KHz
- Size: W120 x L43 x H27mm
1. RGB LED Controller: The controller is designed to control RGB LED lighting, allowing you to adjust the color, brightness, and modes of the lights. 2. WiFi & RF Connectivity: It supports both WiFi (Tuya APP cloud control) and RF (Radio Frequency) communication. This means you can control the LEDs remotely using a mobile app and also through RF signals. 3. Tuya APP Integration: The Tuya app...
