DC24V GS8206 DUALSIDE 5050SMD RGB Neon LED Tube Light Dream Color Programmable Flexible LED Strip Lights, 20m/65.6ft for sale
Universal single row DC24V Flexible LED Neon Tube Light Dream Color Programmable Flex LED Strip Lights For luminous characters dynamic color chasing, sequencing, changing, and also static color modes available on the Full-Color Controller and dream color Strip. addressable LEDs (1 IC drives 6 led chip) allow for sequencing modes. Silicone Encased waterproof optional flexible LED light strip with 300 LEDs high power 5050SMD(Surface Mounted Devices) RGB LEDs programmable for chasing patterns. GS8206 IC chip control. 20meter(65.6') Per Reel By Sale. No drop voltage.
Standards and Certifications
LED Strip Type: SMD 5050 DreamColor
LED Chip: GS8206 IC super brights Chip
Working Temperature: -4°F (-20°C) ~ 122°F (50°C)
Storage Temperature: -40°F (-40°C) ~ 176°F (80°C)
LED Quantity: 60 LEDs per 1meter (GS8206) ,
IC Quantity: 6 LEDs/IC (GS8206)
Dimensions: L2000cm(787 in ) x W1.3cm(0.51 in ) x H2.4cm(0.94 in )
Input Voltage(V): 24VDC
Working Power: 14.4W/3.28ft
Lumen Per LED: 20-22Lumen 402lm Max /ft
Wavelength NM(RGBY): 2000-2500mcd
Beam Pattern: 160 degree
Water Proof: Waterproof IP68
Warantty: 3 years
LED programmable digital display
Hotels decoration use
Concealed lighting, Cove decoration
Theaters, clubs, shopping malls lighting
Architectural decorative lighting
Boutique atmosphere lighting
Auditorium walk stairway lighting
Hidden groove, Wine cabinet decoration
Show exhibition decoration
