Special Price: $28.98
940 nanometers is an invisible wavelength, located in the realm of near-infrared light, so 940nm red light is invisible to the naked eye. Compared to 850nm infrared LEDs, 940nm IR LEDs produce almost no visible red light (red bursts). This characteristic makes 940nm IR led strip very suitable in scenarios where covert lighting is required. For example, in security surveillance, the use of IR 940nm led strip can avoid attracting attention while providing sufficient illumination for surveillance cameras. The black PCB can better hide the strip, making it more invisible after installation.
The 12V voltage is safe for 940nm light source and is suitable for use in IR infra-red applications in both home and commercial environments, with lower power consumption for long time running. Choose a 12-volt led power supply here.
• Tri-chip 5050 940nm LED
• Standard density 60 lights / meter, five meters of 300 LEDs in a roll
• Available in IP20 non-waterproof 940nm version, IP65 splashproof 940nm version, IP67 and IP68 waterproof 940nm version
• Cuttable and reconnectable every 50mm, every three LEDs as a separate circuit
• The 940nm IR LED connects directly to an AC DC power supply such as the 12V 6A power adapter or the LRS-75-12 hardwired power supply included in the kit
• Optional WT1 controller is available to intelligently control the 940nm IR light
How to check if the 940nm invisible infrared light is working properly?
Professional infrared detection equipment and most cell phone cameras have light-sensitive elements (such as CMOS or CCD) that are sensitive to infrared light. Although the human eye cannot see 940nm light, cell phone cameras can capture this light.
Aim your cell phone camera at the 940nm LED light. If the LED light is working properly, you may see a purple or white bright spot.
Different cell phone camera sensors may have different sensitivities to infrared light. Some cell phones may display it better, while others may be less visible.
Infrared 940 nm LED Spectrum Download
Product Specifications
| LED Strip Type: | 12 Volt 940 nm Infrared Strip Lighting |
| LED Chip: | SMD5050 |
| Light Wavelength: | 940 nm |
| Light Color: | Invisible |
| Input Voltage: | 12V DC |
| Roll Length: | 5m (16.4ft) |
| LED Quantity: | 60 LEDs/m, 300 LEDs/roll |
| PCB Width: | 10mm for IP20/65, 12mm for IP67/68 |
| Working Power: | 60W roll max |
| Cut Unit: | 3-LED, 50mm (1.97") |
| Beam Pattern: | 120 degree |
| Outlet: | 2-pin power wires (red V+, black V-) |
| IP Rating: | Non-Waterproof IP20, Waterproof IP65 IP67 IP68 |
| Installation: | Stick on |
These images were taken with Canon EOS 5D Mark IV and the studio light source is provided by Ra 98's full spectrum LED strip to realistically reproduce the colors of the item itself. All copyrights are created by the superlightingled team, please feel free to browse and download if you are a registered user!
