395nm 365nm UV Lights 2835 LED Blacklights Strip 12V

Name: 395nm 365nm UV Lights 2835 LED Blacklights Strip 12V
Brand: SuperLightingLED
SKU: FSLSR-12V-2835X600UV
Price: 19.98 USD
Availability: InStock

Model: FSLSR-12V-2835X600UV Review stars

0.0 (0 Reviews) Various options in stock

Starting at: $28.98 $19.9831% off

Qty Discounts Off Price
1-19 $19.98	20-49 $19.58	50-99 $19.18	100+ $18.78
* Discounts may vary based on options below

Select Specifications:

Select Power:

0.5W per LED ( +$1.00 )

Select PCB Width:

Select Connector:

Select Input Voltage:

Select Length:

16.4ft (5 meters)

Select Waterproof Rating:

Wavelength:

Qty: -+

Free shipping over $299Ships via DHL / UPSWarranty covered

Accept the project customization, please contact us for commercial offers and technical support.

Product Information

395nm / 365nm UV-A Light Flexible Blacklight LED Strip With High Density 120LEDs/m, made by 600pcs high efficiency 2835SMD LED chips, with adhesive 3M backing tape, easy and convenient to install. Low voltage DC12V power, every 3 LED UV lights can be cut, able to get your desired length.

0.2W/LED vs 0.5W/LED: Although this UV light strip uses 0.2W and 0.5W UV LED beads, the total power of the 5-meter light strip is not simply 0.2W / 0.5W multiplied by the number of LEDs.

Due to resistance limitations and the inevitable voltage drop in LED series connections, the actual power of the entire light strip is around 40W per roll (single-sided power input). Please contact us for customization if you have specified power output.

365nm LED Strip Lighting

Standards and Certifications

LED Strip Type:	12V UV Blacklight LED Strip
Input Voltage(V):	12V DC
Working Power:	40W/Roll, 12W/m max
Light Color:	Ultraviolet /Purple / Blacklight
Wavelength NM(RGBY):	UV-A Light (395nm / 365nm)
Strip Length:	16.4ft/roll, every 3 PCS LED can be cut
LED Quantity:	120 LEDs per meter (3.28 ft)
Lifespan:	50,000+hours
Dimensions:	L500cm(196.8 in ) x W0.8cm(0.3in) / W0.5cm(0.2in) x H0.25cm(0.10 in )
Cut Length:	25mm (1 inch)
Beam Pattern:	120 degree
Waterproof Rating:	Non-Waterproof IP20, Waterproof IP65, IP67, IP68 optional

Reviews

Customer Experience

Your feedback is important to us! Share your thoughts and photos with other customers.

Write a Review & Upload Photos

Downloads

Files for FSLSR-12V-2835X600UV

PDFFSLSR-12V-2835X600UV product data sheetFull specifications, dimensions, cut points, wiring and IP options — the same details shown on this page, laid out for printing and engineering review.PDF · generated from the current product page · opens in a new tabOpen PDF

Need this page for a project file or an engineering check? Click Open PDF, then save or print it from your browser. For CAD drawings, IES files or a signed test report, contact our engineers and quote the model number.

Images

These images were taken with Canon EOS 5D Mark IV and the studio light source is provided by Ra 98's full spectrum LED strip to realistically reproduce the colors of the item itself. All copyrights are created by the superlightingled team, please feel free to browse and download if you are a registered user!

LED Strip Light Guide

Common questions about this type of product, answered against this model’s own options. For full figures see the specification above or the spec sheet for this model.

What voltage does this LED strip light run on?

This model is offered in DC24V · DC12V. Lower voltage means a shorter run per feed: at 12 V feed power roughly every 5 m, at 24 V roughly every 10 m. Longer runs get power injected at both ends. Connecting to the power supply

Which waterproof rating should I choose?

Available on this model: Underwater IP68 - Adhesive Back · Outdoor Silicone Tube IP67 - Adhesive Back · Surface Glued IP65 - Adhesive Back · Non-Waterproof IP20 - Adhesive Back. IP20 is for dry indoor use, IP65 handles splashes, IP67 suits outdoor and wet areas, IP68 is for continuous submersion. Choosing a waterproof rating

Can I cut it to length?

Yes. Cut only on the marked cut lines between the copper pads — the cut interval for this model is on its spec sheet. Rejoin with solder or a solderless connector. Connector options on this model: DC Female Connector (Black) · 2-Pin Wire + DC Female Connector (Black) · 2-Pin (V+, GND). Cutting LED strip lights · we can also cut to length and fit your connector before shipping: custom LED strip light assembly.

What size power supply do I need?

Take the watts per metre from the specification above, multiply by the length you are running, then add about 25% headroom. Power calculation guide · Choosing a power supply

Will it fit an aluminium profile, and how dense are the LEDs?

PCB width 10mm (0.39in) · 5mm (0.2in) · 8mm (0.31in). Choose a profile whose inner width is at least the PCB width; denser LEDs give a smoother line close to a diffuser. LED aluminium profiles
