HD107S( Update APA107) RGB 3535SMD Digital Intelligent Addressable LED Chip, DIY LED Chip, 1000PCS By Sale
HD107S RGB pixel 3535 led is the upgraded version of APA102, PWM refresh rate >26kHz, Oscillator Frequency is 40MHz
HD107S 3535 RGB LED chip is same with APA102 with one IC for the three-colors RGB diming control strip and string, this ic use the CMOS process to provide three-colors RGB LED output driver to adjust the output with 256 grey scale and 32 brightness adjustment, HD107S RGB LED diodes with 2 signal output way, one is clock , another is data, the clock and data are synchronized, so that the crystal cascade piece of output movement is synchronized.
PWM refresh rate: >26kHz, Oscillator frequency: 40Mhz(transmission rate)
CMOS process, low voltage, low consumption
Synchronization of two-way
Choose positive output or negative RGB three-color LED output
8 bit(256 level) color set, 5bit(32 level) brightness adjustment
Build-20ma constant current output
With self-detection signal build in support for continuous oscillation PWM
output, can be maintained static screen
Standards and Certifications
Take attentions as follow
HD107s pixel led chip with PWM refresh Rate 27KHZ and transmission rate 40MHZ
Apa107 pixel led chip with PWM refresh rate 9KHZ and transmission rate 30MHZ
original apa102 pixel led chip with PWM refresh rate 20KHZ and transmission rate 30MHZ (Gone)
app102C (made in china ) (fake apa102)
sk9822 pixel led chip with PWM refresh rate 4.7KHZ and transmission rate 15MHZ (fake apa102)
LED Type: SMD LED 3535
LED Chip Type: HD107S-3535
Emitting Color: Addressable RGB
Working Voltage: DC 5V
Beam Angle: 120degrees
Waterproof Rating: non-waterproof
1* 1000pcs HD107S-3535 LED chip
