WS2815 RGB 5050SMD Digital Intelligent Addressable LED Chip, DIY LED Chip, 100PCS By Sale

Name: WS2815 RGB 5050SMD Digital Intelligent Addressable LED Chip, DIY LED Chip, 100PCS By Sale
Brand: SuperLightingLED
SKU: WS2815-5050-RGBCHIP
Price: 14.98 USD
Availability: InStock

Model: WS2815-5050-RGB CHIP Review stars

0.0 (0 Reviews) Various options in stock

Price$14.98

Qty Discounts Off Price
10-4 $14.98	5-9 $14.68	10-14 $14.23	15+ $13.63
* Discounts may vary based on options below

Select Specifications:

Select Quantity:

100pcs

Qty: -+Min: 10
*Mixed OFF

Free shipping over $299Ships via DHL / UPSWarranty covered

Accept the project customization, please contact us for commercial offers and technical support.

Product Information

The control circuit and the RGB LED chip are integrated into a 5050 packaged component to form a complete external control pixel. The 12V power supply voltage effectively reduces the working current of the entire pixel, reduces the voltage drop of the circuit board, and maximizes the consistency of the pixel when it is transmitted over a long distance.

Built-in signal shaping circuit, any pixel point receives the signal after waveform shaping and then output, to ensure that the line waveform distortion will not accumulate. The three primary colors of each pixel can achieve 256 levels of brightness display, complete the full true color display of 16,777,216 colors, and the port scanning frequency is 2KHz/s.

The serial cascade interface can receive and decode data through a signal line. Resumable transmission at breakpoints, additional ┌ signal lines are added to realize dual-channel signal transmission. When a single pixel is damaged, it does not affect the overall display effect. Any two-point transmission distance does not need to add any circuit when the transmission distance is less than 5 meters.

When the refresh rate is 30 frames per second, the number of cascades is not less than 1024 points. The data transmission speed can reach 800Kbps. The color of the light is highly consistent and cost-effective.

WS2815 Chips Specifications Download

Standards and Certifications

12VDC

Specifications

LED Chip Model: SMD 5050

LED Resource: WS2815 LED

IC Type: WS2815 IC (1 IC drives 1 led chip)

Chip Color: White Available

Protection Rate: Non-waterproof

Size: 5.5*5.0*1.6mm

Power: 0.2Watt/pcs

Input Voltage: DC12V

Working Temperature: -20~50°C

Lifespan: 50000 hours

Beam Angle: 120°

LED Quantity: 1000pcs/pack
