164ft High Voltage AC COB White LED Strip Lights Outdoor Waterproof

Name: 164ft High Voltage AC COB White LED Strip Lights Outdoor Waterproof
Brand: SuperLightingLED
SKU: FSLCOB-HV-280W12
Price: 82.98 AUD
Availability: InStock

Model: FSLCOB-HV-280W12 Review stars

0.0 (0 Reviews) Various options in stock

Starting at: A$133.61 A$119.2411% off

Select Specifications:

Select Light Color :

Select Size:

Select Plug Type:

Select Length:

Select Installation:

Qty: -+

Free shipping over $299Ships via DHL / UPSWarranty covered

Accept the project customization, please contact us for commercial offers and technical support.

Product Information

82ft high voltage AC110V AC220V COB led strip lights with different white light color temperatures, 3000K warm white, 4000K natural white, and 6000K pure white. 110V or 220V AC directly input, no need led transformer or LED driver. No voltage drop for long distance operation, suitable for outdoor buliding outlet lighting, indoor lighting, etc.

Note: Due to the limited power of the ballast on the AC plug, one AC plug just can run max 20-30 meters, so we delete the 50 meters length option. Please follow this rule to use your high voltage COB strips, otherwise overload will cause high voltage fire, very dangerous!

LED strip inputs must be equipped with a ballast and cannot be directly connected to high-voltage circuits via cables.

Chip on board ac led strip lights vs SMD led ac light strips: The biggest difference is that this COB strip has no light spot and presents a continuous spotless light, which is perfect for linear lighting.

Adopt high-brightness flip-chip LED chip package, the light-emitting angle can reach 180 degrees, high chip density and good uniform light effect.
Linear light, no light spot, good color consistency.

Good heat dissipation, low heat, long life, can be twisted at will without dying lights.
At normal current, attenuation is minimal. Since the COB chip is directly solidified on the PCB, the heat of the chip can be quickly transferred to the PCB. Therefore, the heat dissipation speed of the COB light strip is faster than that of the lamp bead type lamp, the light decay of the COB light strip is smaller and the life is longer.

Notice: Because the COB strip is a little heavy, it's better to add some clip to fix the strip when install it. Please carefully connect wires and handle the installation, 220V is very dangerous!

Product Specifications

LED Strip Type:	Dotless High Voltage COB LED Strip
Input Voltage:	AC110V, AC220V
Strip Length:	25m/82ft
Power:	10W/m, 500W/Roll
Working Temperature:	-20℃~+45℃
Storage Temperature:	-20℃~+60℃
LED Color Temperature:	Warm White(2700-3200k), Daylight White(4000-5000k), Daylight White(5500-6500k)
PCB Width:	10mm/0.4", 12mm/0.47"
LED Quantity:	288 Chips/m
Waterproof Rating:	Outdoor Waterproof IP67
Cut Length:	250mm/9.84"
Lumen:	900lm/m, 90lm/W
Color Rendering Index:	Ra>80
Beam Angle:	180°
Lifespan:	50,000+hours

Applications

High voltage led strip lights are very suitable for outdoor lighting and home lighting:

Patio lighting, Deck lighting (outline and embody the boundary)
Landscape accent lighting

High Voltage 220V AC COB LED Strip Light White Color

High Voltage 220V AC COB LED Strip Light White Color - photo 7

High Voltage 220V AC COB LED Strip Light White Color - photo 8

Reviews

Customer Experience

Your feedback is important to us! Share your thoughts and photos with other customers.

Write a Review & Upload Photos

Downloads

Files for FSLCOB-HV-280W12

PDFFSLCOB-HV-280W12 product data sheetFull specifications, dimensions, cut points, wiring and IP options — the same details shown on this page, laid out for printing and engineering review.PDF · generated from the current product page · opens in a new tabOpen PDF

Need this page for a project file or an engineering check? Click Open PDF, then save or print it from your browser. For CAD drawings, IES files or a signed test report, contact our engineers and quote the model number.

Images

These images were taken with Canon EOS 5D Mark IV and the studio light source is provided by Ra 98's full spectrum LED strip to realistically reproduce the colors of the item itself. All copyrights are created by the superlightingled team, please feel free to browse and download if you are a registered user!

LED Strip Light Guide

Common questions about this type of product, answered against this model’s own options. For full figures see the specification above or the spec sheet for this model.

Can I cut it to length?

Yes. Cut only on the marked cut lines between the copper pads — the cut interval for this model is on its spec sheet. Rejoin with solder or a solderless connector. Cutting LED strip lights · we can also cut to length and fit your connector before shipping: custom LED strip light assembly.

What size power supply do I need?

Take the watts per metre from the specification above, multiply by the length you are running, then add about 25% headroom. Power calculation guide · Choosing a power supply

Which colour is right?

This model comes in Natural White(4000K) · Warm White(3000K) · Daylight White(6000K). Warmer whites suit living spaces, cooler whites suit task and display lighting. Screens do not show colour temperature accurately — order a sample if the room matters. Warm white vs cool white
