Special Price: $92.98 $82.9811% off
82ft high voltage AC110V AC220V COB led strip lights with different white light color temperatures, 3000K warm white, 4000K natural white, and 6000K pure white. 110V or 220V AC directly input, no need led transformer or LED driver. No voltage drop for long distance operation, suitable for outdoor buliding outlet lighting, indoor lighting, etc.
Note: Due to the limited power of the ballast on the AC plug, one AC plug just can run max 20-30 meters, so we delete the 50 meters length option. Please follow this rule to use your high voltage COB strips, otherwise overload will cause high voltage fire, very dangerous!
Chip on board ac led strip lights vs SMD led ac light strips: The biggest difference is that this COB strip has no light spot and presents a continuous spotless light, which is perfect for linear lighting.
-
Adopt high-brightness flip-chip LED chip package, the light-emitting angle can reach 180 degrees, high chip density and good uniform light effect.
-
Linear light, no light spot, good color consistency.
-
Good heat dissipation, low heat, long life, can be twisted at will without dying lights.
-
At normal current, attenuation is minimal. Since the COB chip is directly solidified on the PCB, the heat of the chip can be quickly transferred to the PCB. Therefore, the heat dissipation speed of the COB light strip is faster than that of the lamp bead type lamp, the light decay of the COB light strip is smaller and the life is longer.
Notice: Because the COB strip is a little heavy, it's better to add some clip to fix the strip when install it. Please carefully connect wires and handle the installation, 220V is very dangerous!
Product Specifications
LED Strip Type: | Dotless High Voltage COB LED Strip |
Input Voltage: | AC110V, AC220V |
Strip Length: | 25m/82ft |
Power: | 10W/m, 500W/Roll |
Working Temperature: | -20℃~+45℃ |
Storage Temperature: | -20℃~+60℃ |
LED Color Temperature: | Warm White(2700-3200k), Daylight White(4000-5000k), Daylight White(5500-6500k) |
PCB Width: | 10mm/0.4", 12mm/0.47" |
LED Quantity: | 288 Chips/m |
Waterproof Rating: | Outdoor Waterproof IP67 |
Cut Length: | 250mm/9.84" |
Lumen: | 900lm/m, 90lm/W |
Color Rendering Index: | Ra>80 |
Beam Angle: | 180° |
Lifespan: | 50,000+hours |
Applications
High voltage led strip lights are very suitable for outdoor lighting and home lighting:
-
Patio lighting, Deck lighting (outline and embody the boundary)
-
Landscape accent lighting
