DC24V 200W TRIAC 0/1-10V PWM Dimmable 5 in 1 Dimming LED Intelligent Driver (CV PF>0.95)
TRIAC/ 0-10V/1-10V/10V PWM/RESISTANCE DIM
With soft-on and fade in function, visual more comfortable.
Dimming range: 0~100%, LED start at 1% possible.
0-100% flicker-free, High-frequency exemption level.
High Efficient driver: efficiency 90%, PF>0.95, THD<10%
Over load / Over temp. / Short circuit / Over voltage protection, recover automatically.
Suitable for internal lights application for Ⅰ/Ⅱ/Ⅲ.
Up to 50000-hour lifetime.
Output voltage range：12VD 0 ± .5VDC
Output сurrent：Max 8.4A
Output power：Max 200W
Output power range：0~200W
With or without strobe：No strobe
Dimming range：0~100%, dimming depth: Max. 1%
Ripple & Noise：≤400mV
Dimming interface：TRIAC/ 0-10V/1-10V/10V PWM/RESISTANCE DIM
Input сurrent：2 36. ~0.85A
Power factor：PF>0.95/230Vac, at full load
THD：≤10% at 230Vac, at full load
Inrush current(Typ.)：Cold start 60A
Control surge capability：L-N:2KV
Leakage сurrent：Max. 0.5mA
Working temperature: ta: -30 C ~ 50 C tc: 80 C
Working humidity: 20 ~ 95%RH, non-condensing
Storage temp., humidity: -40 C ~ 80 C, 10~95%RH
Vibration: 10~500Hz, 2G 12min./1cycle, the period for 72min. each along X, Y, Z axes.
Overtemperature: Protection type: Shut down o/p voltage, re--power on to recover
Overvoltage protection: Shut down the output when non-load voltage≥26V, re-power on to recover after fault condition is removed.
Overload protection: Shut down the output when current load ≥110%, auto recovers
Short circuit protection: Protection type: 1. When the first-level short-circuit protection is triggered, the fault can be automatically recovered;
2. When the second-level short-circuit protection is triggered, the power needs to be turned on again after the fault is eliminated
Withstand voltage: I/P-O/P: 3750Vac
Isolation resistance: I/P-O/P: 100MΩ/500VDC/25°C/70%RH
Safety standards: IEC/EN61347-1, IEC/EN61347-2-13
EMC emission: EN55015, EN61000-3-2 Class C, IEC61000-3-3
EMC immunity: EN61000-4-2,3,4,5,6,8,11 EN61547
Strobe test standard: IEEE 1789
warranty：5 years，Connect the wrong line or man-made damage is not within the warranty。
