SK6812 DC5V RGB 120LEDs/m Double Row Side Emitting Individually Addressable LED Strip Lights

Name: SK6812 DC5V RGB 120LEDs/m Double Row Side Emitting Individually Addressable LED Strip Lights
Brand: SuperLightingLED
SKU: SK6812-DRSIDE-120W10
Price: 28.98 EUR
Availability: InStock

Model: SK6812-DRSIDE-120W10 Review stars

0.0 (0 Reviews) Various options in stock

Starting at: €25.59

Select Specifications:

Select Length:

Select Waterproof Rating:

Qty: -+Min: 200
*Mixed OFF

Free shipping over $299Ships via DHL / UPSWarranty covered

Accept the project customization, please contact us for commercial offers and technical support.

Product Information

What is a side emitting LED strip?

The LEDs of the side emitting LED strip emit a beam of light to the side, parallel to the surface of the light strip, which is very suitable for accent lighting. Double row side emitting LED strip can emit light beams parallel to the light strip.

This double row side emitting RGB individually addressable LED strip uses SMD4020 LED chip, which has built-in SK6812 IC, and can change multiple colors and brightness through an SPI controller under DC5V working voltage. To drive this light strip, you need to use a power supply and controller that supports 5V.

Flexible cutting, easy to adapt to the needs of different scenes (cutting length 16.67mm, one LED light can be cut).

Free paste (3M adhesive).

Easy to use (3pin JST connector).

DC5V low voltage, safer to use.

Upgraded safety resistance, higher safety level, stable current and voltage, protect chip from impact, longer life.

Different waterproof options. (Note: The width and height of the waterproof led strip light will increase by 2-3mm on the basis of the PCB width.)

A variety of scenes can be used (bar, living room, playground, hotel, KTV, restaurant, shopping mall, etc.).

SK6812 DC5V RGB 120LEDs/m Double Row Side Emitting Individually Addressable LED Strip Lights - photo 1

SK6812 Chips Specifications Download

Standards and Certifications

DC5V

Specifications

LED Type: SMD4020 Double Row Side-Emitting RGB LED Strip

IC Type: SK6812(built inside the 4020 side-emitting SMD RGB LED)

Working Voltage: DC5V

Power: 23W/m

Lumen/meter: 480lm/m

Product Dimention: L5,000mm(196.85 in ) x W10mm(0.39 in ) x H2.5mm(0.1 in )

Waterproof Rating: IP20/IP67

Lifespan: 50,000Hours+

Terminal Wire Length: 120mm

Certification: UL, CE, EMC, ISO, ROHS

Pixels: 60/meter

Density: 120 LEDs/m

Cuttable Length: 16.67mm/0.66in(Every LED is cuttable)

LED Color: Full color RGB

FPCB Color: White

Working Temperature: -25℃~60℃

Beam Angle: 120 degree

How to connect addressable LED strip?

addressable led strip wiring diagram

SK6812 DC5V RGB 120LEDs/m Double Row Side Emitting Individually Addressable LED Strip Lights - photo 3

SK6812 DC5V RGB 120LEDs/m Double Row Side Emitting Individually Addressable LED Strip Lights - photo 4

SK6812 DC5V RGB 120LEDs/m Double Row Side Emitting Individually Addressable LED Strip Lights - photo 5

Reviews

Customer Experience

Your feedback is important to us! Share your thoughts and photos with other customers.

Write a Review & Upload Photos

Downloads

Files for SK6812-DRSIDE-120W10

PDFSK6812-DRSIDE-120W10 product data sheetFull specifications, dimensions, cut points, wiring and IP options — the same details shown on this page, laid out for printing and engineering review.PDF · generated from the current product page · opens in a new tabOpen PDF

Need this page for a project file or an engineering check? Click Open PDF, then save or print it from your browser. For CAD drawings, IES files or a signed test report, contact our engineers and quote the model number.

Images

These images were taken with Canon EOS 5D Mark IV and the studio light source is provided by Ra 98's full spectrum LED strip to realistically reproduce the colors of the item itself. All copyrights are created by the superlightingled team, please feel free to browse and download if you are a registered user!

LED Strip Light Guide

Common questions about this type of product, answered against this model’s own options. For full figures see the specification above or the spec sheet for this model.

Which controller does this LED strip light need?

Addressable LED strip lights take a data signal, so they need an SPI (pixel) controller that supports this IC — an ordinary RGB controller will not drive them. Data flows one way: connect the controller to the input end marked with the arrow. Wiring addressable LED strip lights

Do I need power injection?

5 V addressable LED strip lights lose voltage fastest, so longer runs need power fed in at both ends and at intervals along the run; 12 V and 24 V versions carry further. Keep the data line short between controller and first pixel. Choosing an addressable LED strip light

Which waterproof rating should I choose?

Available on this model: Outdoor Silicone Tube IP67 - With Brackets · Non-Waterproof IP20 - Adhesive Back. IP20 is for dry indoor use, IP65 handles splashes, IP67 suits outdoor and wet areas, IP68 is for continuous submersion. Choosing a waterproof rating

Can I cut it to length?

Yes. Cut only on the marked cut lines between the copper pads — the cut interval for this model is on its spec sheet. Rejoin with solder or a solderless connector. Cutting LED strip lights · we can also cut to length and fit your connector before shipping: custom LED strip light assembly.

What size power supply do I need?

Take the watts per metre from the specification above, multiply by the length you are running, then add about 25% headroom. Power calculation guide · Choosing a power supply
