12V Individually Addressable DMX LED RGBW Strip Lights 40LEDs/m
Check our new 12V individually addressable DMX led strip RGBW with external 10-pin UCS512H4L DMX512 RGBW IC control, 40 5050 LEDs per meter. Each LED of this DMX RGBW strip is separately addressable, giving you individual control over its color and brightness for a high degree of lighting customization.
Individually Addressable DMX LED Strip Versus
Compared to the other individual addressable DMX RGBW led tape DCFLS-DMX512-5VX160, this one is upgraded to 12VDC, making it compatible with more DMX lighting projects. And compared to the individual addressable RGB DMX led tape DCFLS-DMX512-12VX300, this strip with 4-in-1 RGBW LEDs offers better color mixing and more color options.
|Item Type:||12V Individually Addressable DMX LED RGBW Strip Lights|
|LED Chip:||SMD5050 + 10-pin UCS512H4L IC|
|LED Color Temperature:||Addressable RGB+3000K/4000K/6000K|
|LED Quantity:||40 LEDs/m, 200 LEDs per roll|
|IC Quantity:||40 ICs/m, 200 ICs/roll (1 pixel controls 1 LED)|
|Cut Unit:||25mm/1in - 1 LED can be cut|
|Waterproof Rating:||Non-waterproof IP20, Indoor Waterproof IP65, Outdoor Waterproof IP67 IP68|
1. Through ArtNet controller to control DMX led strips:
2. Through programmable led controller to control DMX led strip:
These images were taken with Canon EOS 5D Mark IV and the studio light source is provided by Ra 98's full spectrum LED strip to realistically reproduce the colors of the item itself. All copyrights are created by the superlightingled team, please feel free to browse and download if you are a registered user!
