Special Price: $49.98 $40.9818% off
WS2811 RGBCCT is a 5-channel (12V+; DO; CW; WW, GND or 5V+; DO; CW; WW, GND) addressable RGB+CCT dimmable LED strip, is one of the latest generation products on the market. It has a serial single-wire cascade interface, integrated addressable LEDs and ordinary LEDs are evenly arranged on the PCB, the LED density is 120LEDs/m.
We have newly introduced an Bluetooth RF Addressable LED Strip Controller SP63CE, it sloves the problem of the two separate controllers (RGBIC controller + PWM CCT controller). This controller allows you to control the WS2811 RGB+CCT LED lights through a mobile APP or a RF remote. Note: SP63CE cannot control the RGBIC lights and PWM CCT lights together for this WS2811 RGB+CCT strip. If you connect two individual strips, it can control together.
DC12V WS2811 addressable 5050SMD LED is an external driver IC, accepts SPI controller to read data, generates pulse width modulation signal to control 256-level grayscale adjustment, and outputs 16 million lighting colors; SMD3838 2in1 CCT LED accepts dimmable CCT LED Controller to achieve 2700-6500K white gradient.
DC5V WS2811 addressable 5050SMD LED is a built-in driver IC, each 5050SMD LED is individually addressable, while DC12V 5050SMD LED is an external IC to control three 5050SMD LEDs, they are all 6 LEDs (50mm) can be cut, and the length of the LED strip can be customized .
The back of the LED light strip is made of high-quality 3M tape, which can be installed in complex environments. The tape has good adhesion and is easy to install. For outdoor lighting work, you can choose IP67 and above waterproof LED strip light.
-
5-channel WS2811 RGBCCT
-
Addressable RGB+CCT dimmable
-
37LEDs/Ft, 120LEDs/m high density
-
DC12V external drive IC, 6 lights cut unit, 50mm cut length
-
DC5V built-in driver IC (5050SMD LED individually addressable), 6 lights cut unit, 50mm cut length
-
3M tape, easy to install
-
Multiple waterproof ratings available, IP20 for indoor lighting, IP67 for outdoor lighting
Please note, BLACK PCB version is OUT OF STOCK NOW.
12V led strip lights VS 5V led strip lights
This WS2811 addressable RGB+CCT led strip is available in two working voltages, here's the difference:
The microcontroller of the 12V WS2811 led strip is printed on the PCB, while the microcontroller of the 5V WS2811 led strip is built-in the SMD5050 RGB LED.
12V led strip has wide applications, homes, offices, cars, and more. And it's more suitable for large projects than 5V led strip.
What is the difference between WS2811 addressable RGB and WS2811 RGBCCT LED strip light?
WS2811 RGBCCT is a 5-channel addressable RGB+CCT dimmable LED strip, which can produce 16 million dynamic effects, while achieving 2700-6500K white gradation; and the white color temperature can be adjusted, it is produced by ordinary SMD3838LED and generates less heat and the color saturation is higher.
The WS2811 addressable RGB LED strip is a 3-channel addressable LED strip. It is controlled by the SPI LED controller and can generate separate white light, but the white color is not adjustable, and the white light has a high color temperature and high heat generation.
If you are looking for perfect dynamic effects and want to achieve static white light adjustment, then this RGBCCT LED strip must be the best choice.
Lighting Kit:
If you choose the LED controller in the kit, we will send you V2+R7-1 and CONFULL-SP107E
For DC5V LED strip light, if you choose the LED power supply in the kit, we will send you DC5V 100W Mean-Well UL-Listed LED power supply
For DC12V LED strip light, if you choose the LED power supply in the kit, we will send you DC12V 100W Mean-Well UL-Listed LED power supply
For DC5/12V LED strip light, you can purchase the LED power supply, which we recommend in the kit. If you use the LED strip light in the outdoor environment, you can consider our DC5V waterproof LED power supply and DC12V waterproof LED power supply
WS2811 Chips Specifications Download
Standards and Certifications
| LED Strip Type: | 5050 addressable RGB LED + 3838 CCT 2in1 LED |
| LED Chip: | Epistar Chip |
| IC Type: | WS2811 DC5V(built-in IC; 5050LED individually addressable); DC12V(external IC) |
| Pixel Quantity: | 20 pixels/m |
| Working Temperature: | -4°F (-20°C) ~ 122°F (50°C) |
| Storage Temperature: | -40°F (-40°C) ~ 176°F (80°C) |
| Light Color: | Dream Color RGB+CCT (2700K-6500K color temperature) |
| Dimension: | 16.4ft/roll, every 2/6 PCS LED can be cut |
| LED Quantity: | 120 LEDs per 1meter (3.28 ft) |
| Lifespan: | 50,000+hours |
| Strip Width: | 12mm/0.47in |
| Input Voltage(V): | 12/5 VDC |
| Working Power: | 84W/16.4ft |
| Beam Pattern: | 120 degree |
| Wavelength NM(RGBY): | 2000-2500mcd |
| Waterproof Rating: | Non-waterproof IP20, waterproof IP67 |
These images were taken with Canon EOS 5D Mark IV and the studio light source is provided by Ra 98's full spectrum LED strip to realistically reproduce the colors of the item itself. All copyrights are created by the superlightingled team, please feel free to browse and download if you are a registered user!
