Gain effortless and precise control over your tunable white LED lighting with the SkyDance V2-L+R7-1 Color Temperature Controller Kit. This complete set pairs the high-capacity V2-L receiver with the intuitive R7-1 RF remote, providing a reliable, out-of-the-box solution for managing CCT LED strips.
With a powerful 8A per channel output, this kit is perfectly suited for both extensive residential installations and demanding commercial applications. The stable 2.4GHz RF signal ensures responsive dimming and color temperature adjustments from warm white to cool white, allowing you to create the perfect lighting ambiance for any occasion without needing a direct line of sight.
Key Features
Complete CCT Control Kit
Includes both the V2-L receiver and the matching R7-1 RF remote for immediate, hassle-free operation.
High Power Output
Delivers a robust 8A per channel across two channels (16A total), ideal for longer or high-density tunable white LED strips.
Precise CCT & Dimming
Smoothly adjust brightness from 0-100% and seamlessly blend warm white to cool white for the perfect ambiance.
Reliable RF Wireless
Utilizes a stable 2.4GHz RF signal for responsive control up to 30 meters away without line-of-sight requirements.
Easy Pairing & Use
Features a simple one-to-one pairing process and an intuitive button remote for straightforward, user-friendly operation.
Technical Highlights
- Constant voltage PWM output ensures smooth, flicker-free dimming performance.
- Auto-transmitting function allows one receiver to pass signals to another within 30m, extending control range.
- A single receiver can be paired with and controlled by up to 10 compatible remotes.
- Logarithmic dimming curve provides a natural and comfortable brightness adjustment for the human eye.
Product Specifications
| Parameter | Details |
|---|---|
| Product Model | V2-L+R7-1 |
| Receiver Model | V2-L |
| Remote Model | R7-1 |
| Input Voltage | 5-36V DC |
| Output Current | 8A × 2 Channels |
| Max Total Current | 16A |
| Output Power | 80-576W |
| Output Type | Constant Voltage (CV) |
| Control Technology | RF 2.4GHz |
| Remote Control Distance | 30m (98ft) in open area |
| Remote Power Supply | 3VDC (CR2032 battery) |
| Dimming Range | 0 - 100% |
| Dimming Curve | Logarithmic |
| PWM Frequency | 500Hz (Default) |
| Operating Temperature | -30°C ~ +55°C |
| Certifications | CE, EMC, LVD, RoHS |
Application Scenarios
How to Control & Use This Controller
- Wiring: Connect your DC power supply (5-36V) to the V2-L receiver's INPUT terminals, ensuring correct polarity (+ to +, - to -). Connect your CCT LED strip's wires to the OUTPUT terminals (V+, CW for Cool White, WW for Warm White).
- Pairing the Remote: Power on the receiver. Within 5 seconds, press the 'On/Off' key on the R7-1 remote. The connected LED strip will flash to confirm successful pairing.
- Operation: Use the remote buttons to control the lights. Use the brightness buttons for dimming and the CCT buttons to adjust the color temperature between warm and cool white.
- Unpairing/Re-pairing: To unpair, power on the receiver and hold the 'On/Off' key for 5 seconds until the light flashes. To pair a new remote, simply repeat the initial pairing step.
- Always use a power supply with a voltage that matches your LED strip (e.g., a 24V power supply for a 24V strip).
- Ensure the total load (wattage) of your LED strip does not exceed the controller's maximum power rating (16A x Voltage).
- This controller is designed for constant voltage (CV) CCT LED strips only.
- Ensure all wiring connections are secure and insulated before applying power.
What's in the Box
- ✓1 x V2-L CCT LED Receiver
- ✓1 x R7-1 RF Remote Control
- ✓1 x User Manual
🚚 Shipping & Warranty
Shipping: Ships worldwide. Standard and expedited options available at checkout.
Warranty: 5-year manufacturer's warranty covering defects in materials and workmanship.
Return Policy: 30-day return policy for a hassle-free experience. Please see our full return policy for details.
Frequently Asked Questions
Q: What is included in the V2-L+R7-1 kit?
A:The kit includes one V2-L two-channel receiver and one R7-1 RF remote control, providing a complete solution for controlling your CCT LED strips.
Q: What type of LED strip is this controller for?
A:This controller is specifically designed for dual white / color temperature (CCT) / tunable white LED strips that have three wires (typically V+, WW, CW).
Q: Can I control multiple receivers with one remote?
A:Yes, you can pair one R7-1 remote to control multiple V2-L receivers simultaneously. Simply perform the pairing process for each receiver you wish to control together.
Q: What is the maximum length of LED strip I can control?
A:This depends on the strip's wattage per meter. The controller supports a maximum of 16A total. For a 24V strip, this is 384W total. Divide 384 by your strip's W/m to find the maximum length.
Q: Is a power supply included?
A:No, a DC power supply is not included. You must purchase a 5-36V power supply separately that matches your LED strip's voltage and has enough wattage for your total load.
Q: What is the difference between this V2-L+R7-1 kit and other CCT controllers?
A:This kit combines the high-capacity 8A*2CH V2-L receiver with the simple, user-friendly R7-1 button remote, making it ideal for straightforward, reliable control of large CCT lighting setups.
Q: Does the remote require a direct line of sight to the receiver?
A:No, it uses a 2.4GHz RF signal, which can pass through walls and obstacles. The effective control range is approximately 30 meters (98 feet) in an open area.
