AC/DC 12V 4W RGB+ Color Temperature MR16 LED Bulb TK05
Match with Skydance’s 2.4G RGB+CCT remote control, One spotlight accepts up to 10 remote control.
Match with WiFi-relay device for smartphone control.
16 million colors and 10 dynamic modes, adjustable color temperature and saturation.
Auto-transmitting function: spotlight automatically transmit the signal to another spotlight with 30m control distance.
Synchronize on the multiple numbers of spotlights.
Use SAMSUNG LED.
50,000 hours lifespan.
Standards and Certifications
Voltage: AC/DC 12V
Color Temperature: 2700-6500K
Luminous Efficiency: 60LM/W
Luminous Flux(lm): 200-250LM
Beam Angle: 60°
Material: Aluminum + PC cover
Input signal: RF 2.4GHz
Control distance: 30m
Dimming level: 4096 levels
Dimming range: 0 -100%
Safety and EMC
EMC standard (EMC): EN301 489,EN 62479
Safety standard(LVD): EN60950
Radio Equipment(RED): EN300 328
1. Make sure the voltage is between AC12V or DC12V.
2. Avoid using under high temperature or moisture.
