Original DC12-24V Max 12A, Universal Hot sale Wireless Remote Control dimmer controllers For Single color Led Strips lights
we combined the mini controller with RF remote, a more convenient way to realize the best visual effect of your LED strip. This mini dimmer is tiny in its size, make it easy to be concealed .Through connecting with LED strips, the accompanied RF remote will be able to control strip to achieve different functions such as dynamic mode, dynamic speed level and brightness adjustment. This LED Dimmer you can change the brightness of your LED Lighting. There are controls on the dimmer itself, as well as on the included remote. Connect the LED Dimmer between the power supply and the LED Strip. The dimmer is not suitable for use with RGB Strips. This dimmer can connect to max. 72 Watts of LED Strip. If you want to be able to dim more LED Strip with one remote, you need to use amplifiers. Please do not hesitate to contact us for advice.
Working temperature: -20-60℃
Supply voltage: 12 - 24 Volt DC
Output: 3 channels, common anode connection
Static power consumption: <1W
Working current : 12A
Max. power output: 72W (12V) or 144W (24V)
Connector: Female and male connector on both end for strip and power connecting
Net weight: 130g
About the RF Remote
the RF wireless remote signal can pass through barrier, it gets a longer control distance(about 15 meters at open area) and range since it is not necessary to aim at the main unit when operating. Total 8 dynamic modes,
10 level of dynamic speed , and 10 level of brightness adjustment.
Function buttons on the RF remote:
-ON / Standby: to turn ON or switch to standby mode. LED strip will turn on and restore to previous status at powering on moment.
-LIGHT: switch to static lighting mode from dynamic mode.
-25% / 50% / 100% : switch to 100% , 50% or 25% brightness lightness mode.
-MODE+ / MODE- : switch to dynamic mode from static lighting mode, or switch between different dynamic modes.
-SPEED+ / SPEED- : adjust dynamic mode lighting speed.
-BRIGHT+ / BRIGHT- : adjust lighting mode brightness.
Caution: RF remote is driven by 3V CR2025 button battery. Please try to replace with the same type battery.
1×mini inline dimmer
1×RF wireless remote.
