SE-12-350-700-W1R DC10-24V CC LED Intelligent Driver
Wireless dimmingRF 2.4GHz
T-PWM digital dimming, present a perfect visual experience.D
Dimming range: 0~100%,LED start at 0.01% possible.
Flicker-free (IEEE 1789), achieve the level of exemption assessment.
Innovative thermal management technology, intelligent power life protection.
Over-heat / Over voltage / Over load / Short circuit protection, recover automatically
Class2powersupply. Full protective plastic housing.
Compliant with Safety Extra Low Voltage standard.
Suitable for internal lights application for I/II/III
Output Voltage: DC10-24V
Max Output Voltage: DC35V
Output Current: 350-700mA
Output Power Range: 3.5W~12W
Strobe Level: High frequency exemption assessment level
Dimming Range: 0~100%, LED start at 0.01% possible.
PWM Dimming Frequency: ≤3600Hz
Wireless Frequency: 2.4GHz
Input Voltage: 100-240Vac
Input Current: 0.25A@115Vac, 0.15A@230Vac
Leakage Current: <0.5mA/230Vac
Working Temperature: ta: -30°C ~ 50°C tc: 75°C
Working Humidity: 20 ~ 95%RH, non-condensing
Storage Temp., Humidity: -40°C ~ 80°C, 10~95%RH
Temp. Coefficient: ±0.03%/°C (0-50°C)
