Product Information
16.4ft DC24V DMX512 RGBW addressable led strip for sale, it adapts SMD5050 4in1 RGBW LEDs as light sources, high light brightness. 48 LED 5050 lights per meter, a total of 240 lights per roll. DMX LED light strips are low power consumption, it only consumes 13W per meter, and 65W per roll. You just need a DC power supply that has a capacity of at least 78W to run this DMX controlled led tape light. Low-voltage 24V DC input, more secure to use.
This programmable DMX light strip has 4/8 ICs per meter, and 20/40 ICs per roll. One DMX512 IC controls 6/12 RGBW lights. 6/12 LED lights as a loop (125mm/250mm cut length), easy to cut and connect! You can use dmx lighting controller, Artnet pixel controller, Madrix console, or GPS signal control to realize the design of large-scale lighting, such as light shows, stage lighting, and other decorative lighting.
| Light Type | IC Chip | PCB Width | IC Quantity | Power |
| 12 LEDs can be cut (250mm) | 16pin UCS512C4 | 12mm | 4/m, 20/roll | 12W/m, 60W/roll |
| 6 LEDs can be cut (125mm) | 16pin UCS512C4 | 10mm | 8/m, 40/roll | 13W/m, 65W/roll |
| 24 LEDs can be cut (500mm) | 10pin UCS512B4L | 12mm | 2/m, 10/roll | 13W/m, 65W/roll |
DMX512 Chips Specifications Download
Standards and Certifications
Product Specification
| LED Strip Type: | DMX512 RGBW Addressable LED Strip Light |
| LED Chip: | SMD5050 + 16-Pin UCS512C4/TM512AC4 IC |
| Input Voltage: | DC24V |
| Power: | 13W/m, 65W/16.4ft |
| Working Temperature: | -20℃~+45℃ |
| Storage Temperature: | -20℃~+60℃ |
| LED Color Temperature: | RGBW Dream Color |
| PCB Width: | 10mm/12mm |
| LED Quantity: | 48 LEDs/m, 240 LEDs per roll |
| IC Quantity: | 4/8 ICs/m |
| Cut Unit: | 125mm - 6 LEDs can be cut, 250mm - 12 LEDs can be cut |
| Waterproof Rating: | Non-waterproof IP20, Indoor Waterproof IP65, Outdoor Waterproof IP67 IP68 |
| Strip Length: | 5m/16.4ft |
| LED Chip: | Epistar |
| Lifespan: | 30,000+hours |
| Beam Angle: | 120° |
| Lumen: | 22 lm/LED |
How To Wire DMX LED Strip Lights?
DMX Lights Wiring Diagram:
Available LED Strip Lighting Fixtures:
Silicone LED channel is flexible and IP67 outdoor waterproof, there are different internal structures, allowing you to change the light-emitting angle and luminous type.
Aluminum LED profile is also available with multiple types to create various linear lighting. And they all evenly diffuse the LED lighting and protect the light strips.
