Product Information
RGB neon style LED strip can provide a continuous luminous effect without any light spots. Inside the silicone shell is an RGB COB strip with a very high density of 576 and 840 LED chips per meter. The close arrangement of LED chips and the neon silicone help minimize the dark area and disperse the light more evenly, making seamless illumination possible.
The LED strip neon flex rope light is 12mm (0.47in) wide, 6mm (0.23in) high, and comes in rolls of 5m (16.4ft). Smooth LED light strip is designed with an adhesive backing for quick installation. Every 62mm (2.44in) can be cut for length customization. After peeling off the backing, black lines are revealed to indicate where to make cuts. This COB RGB flex neon LED strip light requires a 24V power supply, with one end out of a PVC jacket waterproof power cable. (around 125mm/ 4.92in long)
During the production process, the COB RGB LED strip is tightly fixed in the silicone material under high temperatures, so you don't need to worry about the strip moving around. Silicone material and COB technology make this neon RGB LED strip very flexible and can be bent at will while avoiding sharp folding. Meanwhile, the silicone surface is treated with a special industrial oil, which is very sleek to the touch.
The color of the strip LED neon is standard RGB, which can emit thousands of colors through color mixing. But the light emitted by all the chips is uniform, and it is not possible to individually control each LED chip to emit a different light. We offer an addressable RGB version in the same size, with WS2811 IC inside to show more complex lighting effects.
Features
1. Neon effect LED strips, a chip on board LED strip securely encapsulated within a silicone shell.
2. No light spots, seamless and continuous illumination.
3. Vivid RGB color, with high CRI 90+.
4. High density of 576 LED chips per meter, 2880 LED chips per roll. (5m/16.4ft)
5. The size is 12mm (0.47in) wide and 6mm (0.23in) high.
6. Flexible and bendable, with an adhesive backing, easy to install.
7. The cutting segment is 62mm (2.44in) or 50mm (2in). Please remove adhesive backing to see cutting guide lines.
8. IP67 waterproof, suitable for outdoor use.
Standards and Certifications
Product Specification
|
LED Strip Type:
|
24V Flexible Smooth RGB COB Neon Like LED Strip Lights
|
|
LED Chip:
|
COB LED Chip
 |
|
Input Voltage:
|
24V DC
|
|
Size:
|
W12mm x H6mm (0.47in x 0.23in)
|
|
Working Temperature:
|
-20℃~+45℃
|
|
Lumen:
|
1152 lm/m
|
|
Power:
|
50watt/16.4Ft
|
|
Length:
|
5m/16.4Ft
|
|
LED Quantity:
|
576 Chips/m, 2880 Chips/roll
840 Chips/m, 4200 Chips/roll
|
|
LED Color:
|
Color Change RGB
|
|
Cut Length:
|
576 - 62mm/2.44in
840 - 50mm/2in
|
|
PCB Color:
|
White
|
|
Beam Angle:
|
180°
|
|
Waterproof Rating:
|
Indoor & outdoor IP67
|
| Kit: | 24V COB RGB strip + V3-L controller with R8-1 remote control + LRS-150-24 mean well power supply (with AC plug) |
How to Wire COB RGB LED Strip Lights?
