LT-898 has been discontinued, but we have replacement. You can use the LT-912 or LT-924 for replacing.
LT-898 DMX CV decoder converts the universal standard DMX512 signal into PWM signal to drive LEDs. Works with DMX512 console, 256 grayscale output per channel, 0-100% dimming range with various changing effects. Equipped with DMX standard XLR-3, RJ45 interface, controls single color, two color, RGB, RGBW LED Lights.
LT-898 8CH DMX-PWM Decoder
Input Signal: DMX512
Input Voltage: DC5V～DC24V
Max Load Current: 6A ×8CH Max 48A
Max Output Power: 240W/576W/1152W(5V/12V/24V)
DMX512 Socket: RJ45, XLR-3
Dimming Range: 0～100%
Operating Temp. : -30℃～65℃
Product Size: L222×W108×H42(mm)
Package Size: L242×W113×H46(mm)
Weight (G.W.) : 740g
