DMX512 to 4CH 0-10V Decoder DL For LED strip lights indoor
Input voltage: 5-24VDC
Input signal: DMX512
Output signal: 0-10V
Dimming range: 0~100％
Working temperature: -30℃~55℃
Compatible with a variety of DMX512 masters.
0-10V LED driver which receives and converts DMX512 signal to 0-10V signal.
DMX512 compliant control interface, DMX address can be set easily and shown on the digital numeric display.
It can also work as stand-alone RGB/RGBW controller, have 30 kinds dynamic mode,adjustable speed and brightness.
It can also work as stand-alone 4 channel dimmer, each channel adjust brightness independently, and save up to 8 groups brightness.
Connect with 0-10V input dimming driver, such as 0-10V dimmable power supply,realize fine and smooth dimming.
Standards and Certifications
