Intelligent Tunable White LED Driver，20W CC Tunable White LED Driver SE-20-250-1000-W2B2
Intelligent Tunable White LED Driver (Constant Current)
Adopt SAMSUNG/COVESTRO V0 flame-resistant polycarbonate protective housings with small size and lightweight.
Bluetooth 5.0 Mesh with high networking capability is reliable and stable.
Adjust brightness levels when lights are turned on or go to the brightness level adjusted last time.
T-PWM dimming technology allows continuous and flicker-free images under high-speed shooting.
0-100% flicker-free dimming with high-frequency exemption level.
Dimming from 0~100%, down to 0.01%.
Innovative thermal management technology protects the power of life intelligently.
Overheat, overvoltage, overload, short circuit protection, and automatic recovery.
Suitable for indoor light applications ofⅠ/Ⅱ/Ⅲ type.
Up to 50000-hour lifetime.
5 -year warranty (Rubycon capacitor).
