Product Information
Key Features
Seamless Smart Home Integration
Connects to your home WiFi and integrates with the Tuya Smart app for comprehensive control.
Voice Control Enabled
Works with Amazon Alexa and Google Assistant for hands-free voice commands to manage your lights.
Wide System Compatibility
Designed to control the entire range of Mi-Light and MiBoxer 2.4GHz RF series products.
Remote Access
Manage your lighting schedules, colors, and brightness from anywhere with an internet connection via the app.
Modern & Simple Setup
Features a modern USB Type-C power input and a straightforward pairing process for quick installation.
Upgraded Performance
As the successor to the WL-Box1, the WL-Box2 offers enhanced stability and a more robust connection.
Technical Highlights
- Utilizes standard WiFi-IEEE 802.11b/g/n 2.4GHz communication for broad router compatibility.
- Low power consumption with a DC5V/500mA input.
- Stable 6dBm transmitting power ensures reliable signal to your RF devices.
Product Specifications
| Parameter | Details |
|---|---|
| Product Name | 2.4GHz Gateway |
| Model No. | WL-Box2 |
| Input | DC5V/500mA (Type-C) |
| Communication Mode | WiFi-IEEE 802.11b/g/n 2.4GHz |
| RF Frequency | 2.4GHz |
| Transmitting Power | 6dBm |
| Operating Temperature | -10~40℃ |
| Supported App | Tuya Smart |
| Voice Control Support | Amazon Alexa, Google Assistant |
Application Scenarios
How to Set Up and Use Your WL-Box2 Gateway
- Power the WL-Box2 gateway using a standard 5V USB adapter and the included Type-C cable.
- Download the 'Tuya Smart' app from the Google Play Store or Apple App Store and register an account.
- In the app, tap 'Add Device' and select the appropriate gateway or socket (WiFi) category.
- Press and hold the 'RST' button on the WL-Box2 for 5 seconds until the indicator light blinks rapidly, putting it in pairing mode.
- Follow the on-screen prompts in the app to connect the gateway to your 2.4GHz home WiFi network.
- Once the gateway is added, you can link your MiBoxer 2.4GHz RF series lights to it through the app.
- To enable voice control, link your Tuya Smart account within the Amazon Alexa or Google Home app.
- This device requires a 2.4GHz WiFi network and will not connect to 5GHz networks.
- The gateway must remain powered on and connected to your WiFi router to enable smart functionality.
- For best performance, place the gateway in a central location with good signal reception to both your router and the lights it will control.
What's in the Box
- ✓1 x WL-Box2 2.4GHz Gateway
- ✓1 x Type-C USB Cable
- ✓1 x User Manual
Frequently Asked Questions
Q: Is the WL-Box2 a standalone LED controller?
A:No, it is a WiFi gateway, or bridge. Its purpose is to connect your existing Mi-Light/MiBoxer 2.4GHz RF-only products to your WiFi network for app and voice control.
Q: What is the main upgrade from the older WL-Box1?
A:The WL-Box2 is the modern replacement, offering improved stability, a Type-C port, and native integration with the widely supported Tuya Smart platform for a better user experience.
Q: If my MiBoxer controller already has WiFi, do I need this?
A:No. This gateway is specifically for adding WiFi and smart capabilities to MiBoxer's 2.4GHz RF-only products. If your controller is already a WiFi model, you do not need this.
Q: Can I control my lights when I'm not at home?
A:Yes. Once the WL-Box2 is set up on your home WiFi, you can control your connected lights from anywhere in the world using the Tuya Smart app on your phone.
Q: Will this gateway work with Zigbee or Bluetooth lights?
A:No, the WL-Box2 is designed exclusively for the MiBoxer/Mi-Light 2.4GHz RF protocol. For other protocols, you would need a different, corresponding gateway.
Q: Does this gateway allow me to control multiple lights or zones?
A:Yes, you can link and control multiple compatible MiBoxer lights and controllers through the gateway, managing them as individual devices or in groups within the Tuya app.
