Product Information
Key Features
Selectable Constant Current
Offers multiple output current settings from 350mA to 700mA, allowing you to precisely match the power requirements of your LED fixtures.
Seamless 0-10V Dimming
Automatically recognizes 0-10V and 1-10V signals to provide ultra-smooth, continuous, and flicker-free dimming performance for a superior lighting experience.
Optimized for Magnetic & Linear Lights
Specifically designed for quiet magnetic installation and compatibility with STUCCHI standard housings, making it perfect for modern track and linear lighting systems.
Comprehensive Safety Protections
Features built-in protection against short circuits, overloads, no-load conditions, and reverse polarity connections to ensure longevity and safe operation.
Installer-Friendly Design
Simplifies installation with non-polarized inputs and hot-pluggable input/output terminals, saving time and preventing wiring errors on site.
DC-to-DC Conversion
Functions as a high-efficiency DC-to-DC switching driver, stepping down voltage from a main power supply to deliver precise constant current to your LEDs.
Technical Specifications
| Parameter | Details |
|---|---|
| Product Model | MT-350-700-D1A1 |
| Product Type | 0-10V Constant Current LED Driver |
| Input Type | DC Voltage (DC-to-DC) |
| Input Polarity | Non-polarized |
| Dimming Interface | 0-10V, 1-10V (Active Signal) |
| Output Type | Constant Current (CC) |
| Selectable Output Current | 350mA / 400mA / 450mA / 500mA / 550mA / 600mA / 650mA / 700mA |
| Dimming Performance | Smooth, flicker-free curve |
| Installation | Magnetic |
| Housing Compatibility | STUCCHI standard housings |
| Acoustics | Silent operation, no high-frequency noise |
| Hot-Plug Support | Input and Output |
| Short Circuit Protection | Yes, auto-recovery |
| Overload Protection | Yes |
| No-Load Protection | Yes |
| Reverse Connection Protection | Yes |
Ideal Applications
Installation & Setup Guide
- Ensure the main DC power supply is turned off before wiring.
- Connect the output of your main constant voltage power supply to the DC input terminals of the driver. Polarity is not critical for the input.
- Select the desired output current for your LED fixture using the DIP switches on the driver. Refer to the product datasheet for the switch configuration chart.
- Connect the positive (+) and negative (-) wires from your constant current LED fixture to the corresponding output terminals on the driver.
- Connect the two signal wires from your 0-10V dimmer or control system to the DIM+ and DIM- terminals.
- Double-check all connections for security. Turn on the main power supply and test the dimming functionality.
- This is a DC-to-DC driver and requires a separate DC power supply. Do not connect directly to AC mains power.
- Ensure the voltage and current ratings of your LED fixture are compatible with the driver's output.
- Do not exceed the maximum load capacity of the driver.
What's in the Box
- ✓1 x Ltech MT-350-700-D1A1 0-10V CC LED Driver
⇩ Downloads & Documents
Frequently Asked Questions
Q: What type of LED lights can I use with this driver?
A:This is a constant current driver designed for LED fixtures that require a specific, stable current, such as those found in magnetic track and linear lighting systems. It is not for constant voltage LED strips.
Q: How do I set the output current?
A:The output current is selected using a set of DIP switches on the driver's housing. Please consult the product datasheet for the correct switch positions for each current level.
Q: Is this driver a complete power supply?
A:No, this is a DC-to-DC driver. It must be powered by a separate DC power supply that provides a stable voltage input.
Q: Can I use a standard TRIAC wall dimmer with this device?
A:No, this driver is not compatible with TRIAC (leading/trailing edge) dimmers. It requires a dedicated 0-10V dimmer or a lighting control system that outputs a 0-10V analog signal.
Q: What does 'no input polarity' mean?
A:It means you can connect the positive and negative wires from your main DC power supply to either of the driver's input terminals, simplifying the wiring process and reducing the chance of error.
Q: Is this driver noisy when installed?
A:No, it is engineered for silent operation with no high-frequency audible noise, making it ideal for quiet environments like homes, offices, and galleries.
Q: What are the benefits of a Constant Current vs Constant Voltage LED driver?
A:Constant current drivers provide a stable current, which is ideal for high-power LEDs to ensure consistent brightness and color. For a detailed explanation, see our guide on Constant Current VS Constant Voltage LED Drivers.
