Product Information
Super Lighting LED, Your Reliable FCOB Light Strip Supplier
Our newly launched RGBWW COB LED strip features an upgraded LED density—increasing from an already high 840 LEDs per meter to a denser 960 LEDs, with more RGBCCT LED groups to deliver ample brightness and vibrant colors for both indoor and outdoor applications. The 3mm light-emitting width on a 12mm wide FPCB ensures focused light output and efficient heat dissipation.
This 5-in-1 RGB tunable white led strip COB iteration adopts a 12V voltage design, ensuring broad compatibility with basic lighting and decorative needs, such as residential use and DIY projects. With full RGB CCT color control, LED hues and white temperatures 2700K-6500K can be adjusted via smart controllers like C05W in the kit. LRS-150-12 power supply is available if you choose the kit.
With a cutting interval of 41.66mm (1.64inch), each segment includes 6 solder pads (3 on each side of the emitting area) for easy connectivity via 12mm COB connectors with quick installation. The strip back with pre-installed double-sided adhesive tape for effortless mounting.
Note for diffuser compatibility: The COB tunable white RGBW strip light’s 2.2mm height requires attention when selecting silicone diffusers to ensure proper internal clearance.
|
Testing has shown that the 2.2mm-height light strips with IP68 waterproofing exhibit an excessively high failure rate. It is recommended to opt for IP67 waterproofing or select a 3.4mm-height RGBCW alternative. |
Product Specifications
| LED Strip Type: | 12V FCOB 5-in-1 Led Rgbw Tunable White Light Strip |
| LED Type: | Chip-on-board |
| Input Voltage: | DC12V |
| PCB Width: | 12mm (0.47in) |
| PCB Height: | 2.2mm |
| Strip Length: | 5m (16.4ft) |
| Power: | 18 W/m, 90 watts /roll |
| Lumen: | 1980lm/m, 110lm/w |
| LED Quantity: | 960/m, 4800/roll |
| LED Color: | RGBCW 2700K-6500K |
| CRI: | Ra>90 |
| PCB color: | White |
| Cut Length: | 41.66mm (1.64in) |
| Beam Angle: | 180° |
| Connector: | 6 wires at both ends (black-V+, red-R, green-G, blue-B, white-6500K, yellow-2700K) |
| Connector Length: | 150mm (5.9in) |
| Waterproof Rating: | IP20 bare board, IP67 silicone tube coated |
| Working Temperature: | -20℃ ~ +45℃ |
