4CH*15A 12-24VDC CV DALI Dimmer DA4-D(Din Rail)
1-4 DALI address selectable/4 Channel/Constant voltage/PMW dimming/Numeric display/Din Rail
● 4 channel constant voltage DALI LED Dimmer with digital display, 5A per channel.
● 1-4 DALI address quantity is selectable, 4 channel work separately.
● In accordance with DALI standard protocol IEC 62386-102, IEC 62386-207 and in compliance with DALI products from other international incorporation.
● DALI address can be manually assigned and shown in the digital display or automatically assigned by DALI master.
● PWM digital dimming, standard DALI logarithmic dimming curve.
● Over-heat / Over-load / Short circuit protection, recover automatically.
● With fast self-testing function.
Input and Output
Input voltage: 12-24VDC
Input current: 20.5A
Output voltage: 12-24VDC
Output current: 4CH,5A/CH
Output power: 4 x (60-120)W
Output type: Constant voltage
Input signal: DALI
Dimming range: 0 -100%
Dimming curve: Logarithmic
PWM Frequency: 500Hz
Warranty and Protection
Warranty: 5 years
Protection: Reverse Polarity
