CC Power Repeater LT-3030-CC
LT-3030-CC CC Power Repeater
Input signal: PWM
Input voltage: DC12V~DC48V
Output voltage: DC3V~DC46V
Max load current: CC 350/700/1050mA 3 in 1×3CH
Output power: 1.05W~48.3W ×3CH Max 144.9W
Output signal: CC PWM
working temperature: -30℃~55℃
Package Size: L178×W48×H33(mm)
Weight (G.W): 110g
