DC24V 18W 18LEDs Single Color SMD3030 DMX512 3 Channels External Control LED Wall Wash Light
1. This product is DC24V 18W single color DMX512 3 channels external control LED wall wash light, the LED adopts 3030SMD, has good light mixing effect, large luminous angle, uniform luminescence, and no spot, which is applicably Installed indoors and outdoors, DC24V low voltage power supply, safe and efficient, harmless to the human body. 18W low power operation, power saving.
2. Environmentally friendly aluminum lamp body: Fast heat dissipation, wear, and corrosion resistance, hidden bottom line.
3. Triple waterproof design: The inside of LED Wall Wash Lighting is completely filled with glue and waterproof treatment, waterproof rubber seal, integrated seal design.
4. Thickened tempered glass panel: Strong hardness, high light transmittance, waterproof, and explosion-proof.
5. Thickened aluminum bracket: Simple installation and easy to use.
Standards and Certifications
Input Voltage: DC24 (V)
Luminous Flux: 1260 (LM)
Color Temperature: 2700-3000 (K)
LED Quantity: 18LEDs
Shell Material: Aluminum
Beam Angle: 25°, 45°, 10*45 (degrees)
Control Type: External Control
Default Wire Length: 20cm
Size: L 1005 * W 50 * H 80mm
Operating Temperature: -20℃-50℃
IP Rating: IP65
Light color: warm white, white, yellow, blue, green
LED chip: SMD3030
Power wiring diagram
Color Temperature And CRI
Choosing the correct color temperature lights for your project is very important, and as important as the brightness you choose.
Consider the look and feel you want your project to have.
What other color lights will be present? What material and color are the materials you wish to light?
CRI (Color Rendering Index) is a measure of how well a particular light source renders vivid, natural color. Lamps, led tubes, or led bulbs with an index of greater than 90 are generally considered High CRI light sources, and will make food, jewels, or any other product come alive with bright, natural color.
