T3X, 2.4G LED Multi-color Controller, High-end Synchronization RGB Touch Remote Controller for Led Light Strips at Home, 5 Years Warranty
T3X is the 2.4GHZ RF wireless synchronization RGB controller which adopts LTECH multiple global initiate technology. The control system consists of two parts, the RF remote control and receiver, realize the signal synchronization on unlimited receivers within effective distance. a very good solution for the LED project needs sync control wirelessly. User-friendly full-color touch wheel for color selection, unique LED state light for sync change indicated, user can simply know the LED working state from distance by checking the remote control.
RF remote can achieve the functions by remote control the on/off, pause, mode, speed and LED brightness, more proudly, the T3X has the brand-new programmable function, add new concept program function, only 10 seconds can DIY a new change effect easily. How easy to program is !
● Adopt 2.4GHZ RF wireless transmission technology, which is applicable for license and patent free worldwide.
● Built-in with dual core driver, make it 10 times of processing speed. can process the wireless data transmission in complicated and multiple levels.
● Advanced RF wireless sync control technology, no sync signal wire between receiving controller, sync capability is stable and reliable.
● Remote controller adopts the capacitive touch control technology on the full color wheel, make the LED color selection more user-friendly.
● With the unique and creative programming function in the Remote control, how easy to program is !
● Built-in sync state light, can display the LED color in static or changing state synchronously.
● Any operation on the remote control or any receiver can command all receivers to work wirelessly and synchronously, Our products has this capability.
● Color changing scene mode and preset storage function.
● USB charging port.
1. Architectural decorations: Commercial center, airport, Metro station.
2. Indoor decorations: Hotel, Plaza, Restaurant, Bar and home decoration.
3. Commercial sign and billboard
4. Other places that uses RGB LED light.
T3X Remote Control
Input voltage : DC5V(Built-in Lithium battery)
Working current : ≤30mA
Working frequency : 2.4GHZ
transmitting distance : 30m
Remote option : sync control unlimited receivers
Change mode :32 Fantastic modes
Scale levels :4096×4096×4096
Battery capacity : 1000mAh
Standby time: ≤6 months
Package Size : L168×W102×H28mm
Weight (G.W) : 200g
RGB LED Controller T3X
