Receiving controller T3-CV
T3 is the 2.4 GHZ RF wireless synchronization RGB controller which adopts multiple global initiate technology. The control system consists of two parts, The RF remote control and receiver; realize the signal synchronization on Unlimited touch wheel for color selection, unique LED state light for sync change indicated, user can simply know the LED working state from distance by checking the remote control. Can RF remote control the functions of switch, pause, changing speed and the brightness and so on. Built-in 32 changing modes, you can save the changing modes in the shortcut key as you like, which not only can call at any time, but also can combine into a program to play in loop.
Adopt RF 2.4GHZ wireless transmission technology, the frequency of free license, in the international patent free use;
The kernel for the dual core driver to bring 10 times fast processing speed, can be multi level wireless data transmission processing complex;
The leading RF wireless sync control technology, receiving no sync signal wire between receivers, synchronization performance is stable and reliable;
The full color touch mode capacitive loop - remote control, LED color selection more user-friendly;
The operation of the remote control or any controller can command all wireless synchronization controller;
The color and light change mode and preset storage function;
The USB charging port.
Building decoration: commercial premises, airport, subway station;
Interior decoration: hotels, shopping malls, squares, restaurants, bars, home, etc.;
Advertising signs and billboards;
Other places can be used LED RGB lights.
T3-CV Receiving controller
Input voltage: DC5V-DC24V
Max current load: 6A×3CH Max 18A
Max output power: 90W/216W/432W(5V/12V/24V)
Compatible remote control: T1/T2/T2M/T3/T3M/T3X remote control
Working temperature: -30℃～55℃
Package size: L178×W48×H33mm
Weight (G.W.): 150g
