Product Information
Achieve a sophisticated and modern aesthetic with the 12x25mm Black Silicone LED Strip Diffuser. This side-emitting, dome-shaped sleeve is engineered for lighting professionals and enthusiasts seeking to create custom 'black neon lights'. Unlike pre-made neon rope lights, this high-performance led light strip diffuser allows you to use your own high-output LED strip (up to 12mm wide), giving you complete control over color, brightness, and quality. The unique black silicone body provides a sleek, discreet look when unlit and creates stunning contrast when illuminated. It's the ideal solution for transforming standard linear lighting into a seamless, dot-free neon-style fixture for architectural accents, signage, and high-end installations. Pair it with our high-performance RGB+CCT LED strips for ultimate creative control.
Key Features
Unique Black Body Design
The black silicone housing offers a striking, minimalist appearance when off, blending seamlessly into dark surfaces and providing high-contrast definition when lit.
Side-Emitting Dome Profile
Directs light horizontally from the side of the profile, perfect for architectural outlining, wall grazing, and creating crisp lines of light.
Broad Strip Compatibility
Features a spacious 13.5mm internal channel designed to accommodate a wide range of LED strips with a PCB width of up to 12mm.
Premium, Durable Silicone
Constructed from high-grade, UV-stable silicone that resists yellowing and cracking, with an extreme operating temperature range of -30°C to 200°C.
Technical Highlights
- High-Contrast Aesthetics: The black neon light effect is highly sought after in modern design. This diffuser provides the perfect canvas, ensuring the focus is on the light output itself, not the fixture.
- Weatherproof for Outdoor Use: When properly sealed with our compatible LED neon flex light accessories and silicone adhesive, the entire assembly achieves an IP67 rating, making it suitable for outdoor facades, signage, and landscape lighting.
Product Specifications
| Parameter | Details |
|---|---|
| Product Model | FLNLT-YT1225B |
| Material | High-Grade Black Silicone Rubber |
| External Dimensions | 12mm (Width) x 25mm (Height) |
| Internal Channel Width | 13.5mm |
| Compatible LED Strip Width | ≤12mm PCB |
| Light Emitting Direction | Side Emitting (Side View) |
| Profile Shape | Dome Top |
| Length | 1m (3.28ft), 2m (6.56ft), 5m (16.4ft) or uncut roll up to 50m (164ft) |
| IP Rating | IP67 (with proper sealing) |
| Operating Temperature | -30°C to 200°C (-22°F to 392°F) |
| UV Resistance | Excellent |
| Color | Black (Unlit) |
| Warranty | 1 Year |
| Weight | 300g/m |
Application Scenarios
How to Insert an LED Strip Into This Neon Sleeve
- Select a compatible LED strip with a PCB width of 12mm or less. Ensure its voltage and color type match your project requirements.
- Cut the silicone sleeve to your desired length. Use a sharp utility knife for a clean, straight cut.
- Attach a thin, strong string or guide wire to the end of your LED strip using tape. This will act as a pulling lead.
- Feed the string through the silicone sleeve from one end to the other. Gently pull the string, guiding the LED strip into the channel. Keep the strip flat to prevent twisting.
- Once the strip is in position, trim any excess. Install end caps, using a neutral silicone adhesive to seal both ends completely for IP67 water resistance.
- Do not bend the diffuser tighter than its specified minimum bend radius to avoid damaging the silicone or the internal LED strip.
- Always confirm your LED strip's width before purchase. A strip wider than 12mm will not fit inside the channel.
- For outdoor or wet location installations, sealing both ends with silicone adhesive is mandatory to maintain the IP67 rating.
- The LED strip, power supply, controller, and mounting accessories are sold separately.
What's in the Box
- ✓1 x 12x25mm Black Silicone LED Neon Diffuser (in your selected length)
- ✓End caps, and mounting clips (optional)
Frequently Asked Questions
Q: What is a 'black neon light'? Is black a neon color?
A:A 'black neon light' refers to the aesthetic created by this diffuser. The housing itself is black, providing a sleek, invisible look when off. When the internal LED strip is on, the light emits from the black body, creating a striking, high-contrast effect. The light color is determined by your LED strip.
Q: What's the difference between this silicone diffuser and a cheaper plexiglass led diffuser strip?
A:Silicone is highly flexible, UV-resistant, and withstands extreme temperatures without cracking or yellowing. Cheaper rigid plastic or plexiglass diffusers are brittle, can't be bent into shapes, and often degrade under sun exposure.
