EC4 4CH*350mA/700mA DC12-48V CC Power Repeater
● 12-48V constant current power repeater.
● 4 channel, 350mA/750mA per channel.
● To receive PWM signal control.
● Power repeater in parallel to expand output unlimitedly.
● Apply to single color, dual color, RGB or RGBW constant current LED lamps.
Safety & Warnings
1. The product shall be installed and serviced by a qualified person.
2. This product is non-waterproof. Please avoid the sun and rain.
3. Good heat dissipation will prolong the working life of the controller,Please ensure good ventilation.
4. Please check if the output voltage of any power supplies used comply with the working voltage of the product.
5. Ensure all wire connections and polarities are correct and secure before applying power to avoid any damages to the LED lights.
6. If a fault occurs please return the product to your supplier. Do not attempt to fix this product by yourself.
Input and Output
Input Voltage: DC12-48V
Output Current: 4CH, 350mA or 750mA/CH
Output Power: 4 x (1.05-16.1)W (350mA), 4 x (2.1-32.2)W (700mA)
Input Signal: PWM, 4CH
Output Type: Constant voltage
Warranty and Protection
Warranty: 5 years
Protection: Reverse Polarity/short circuit
Safety and EMC
EMC standard (EMC): EN301 489,EN 62479
Safety standard(LVD): EN60950
