RGB Intelligent LED Driver ST-75-24-W3W2
Intelligent LED driver is suitable for home lighting, enable to adjust the brightness/color of light and stepless dimming without flicker. It also supports a variety of control modes: intelligent audio voice control and timing control. Also, it can be controlled by remote and wireless dimmer panel, which meets the application of different scenes to make life more intelligent.
Wireless signal: WiFi, RF 2.4GHz.
Support 3G/4G signal controlling driver.
Support wireless panel, remote controlling driver.
Dimming range from 0-100%, LED start at 0.1% possible.
0~100% flicker-free, achieve the level of exemption assessment.
Active PFC function.
100~240Vac wide voltage input.
Over-heat / Over voltage / Over load / Short circuit protection, recover automatically.
Class 2 power supply. Full protective plastic housing.
Compliant with Safety Extra Low Voltage standard.
Suitable for indoor application forⅠ/Ⅱ/Ⅲ.
Amazon Alexa work with LED driver:
Please find “skills” L-Home in Amazon Alexa and bind with LHome’s account, speaker control can be realized immediately.
